CrimeStopper SV-5340 Platecam Installation Instructions

170° hide-away bracket cmos license plate camera

Download this manual

The SV-5340 is a special designed license plate metal bar back up camera with a super wide

view angle. The mounting bracket is designed to be installed behind the license plate on any

vehicle so that only the camera is visible. It's easy to install with no drilling required, requiring

minimal installation time. This uniquely designed product can be used for any passenger car,

SUV and Van. It can also be used on many large Semi Trucks, School Buses, and Transit

Buses

FEATURES:

• Revolutionary design integrates a Color rear vision camera with your rear license plate

• Enhance the look of your Car, SUV, Truck or Van.

• The 170° ultra wide-angle CMOS color camera provides rear images in real time and

eliminates the dangerous "blind-spot" directly behind your vehicle when backing.

• Parking assist lines to help the driver accurately judge distance behind the vehicle

• Simple installation: No major tools required. Video monitor required, not included

• The plate cam easily connects easily with any SecurView™ monitor or any monitor that

uses a standard RCA video connection

• The PlateCam™ is designed for vehicles in which the license plate location is centered

and above the level of the rear bumper. The PlateCam™ may not perform well on

vehicles with low or offset license plate positions

INSTALLATION INSTRUCTIONS:

170° Hide-Away

Bracket CMOS License

Plate Camera

SV-5340

Page 1: Installation Instructions
SV-5340 170° Hide-Away Bracket CMOS License Plate Camera INSTALLATION INSTRUCTIONS: The SV-5340 is a special designed license plate metal bar back up camera with a super wide view angle. The mounting bracket is designed to be installed behind the license plate on any vehicle so that only the camera is visible.
Page 2: Side View
INSTALLATION MOUNTING: 1. The PlateCam™ SV-5340 Rear Vision System uses a super wide-angle lens for best all around performance. The Camera will display the full width of most parking spaces up to 8 feet or even wider. 2. The SV-5340 is designed to work best on vehicles that have a license plate located at the center and above the rear bumper.
Page 3 WIRING: 1. Carefully choose a hidden out-of-sight location (possibly behind the plate) for drilling the cable hole. Some vehicles may have an existing hidden rubber grommet or plug available to avoid having to drill into the body. Be sure to double-check for any wiring or obstructions behind the surface where you are going to drill the cable hole.
Page 4 Federal Motor vehicle codes with regards to modifications of vehicle license plates. The manufacturer of the PlateCam™ assumes no liability or responsibility whatsoever with regards modifications of the license plate. www.crimestopper.com email@crimestopper.com Phone (800) 998-6880 FAX (805) 581-9500 © 2011 Crimestopper Security Products 4-7-2011...
