LOGIPIX IP VIDEO SURVEILLANCE SYSTEMS
INSTALLATION GUIDE
Logipix Stadium Surveillance System
Devices:
LPIX15-01-AB, LOBJ-05P, LOBJ-14, LPIX- PTZ-04, LPIX2-B, LPIX2-D, LNVR-H-16-R,
LNVR-16-8-E, LNVR-16/32
Document version: 4.0
Contact
E-mail: info@logipix.com
Technical support: support@logipix.com
Web: www.logipix.com
Advertisement
Table of Contents
Summary of Contents for Logipix LOBJ-05P
-
Page 1: Installation Guide
LOGIPIX IP VIDEO SURVEILLANCE SYSTEMS INSTALLATION GUIDE Logipix Stadium Surveillance System Devices: LPIX15-01-AB, LOBJ-05P, LOBJ-14, LPIX- PTZ-04, LPIX2-B, LPIX2-D, LNVR-H-16-R, LNVR-16-8-E, LNVR-16/32 Document version: 4.0 Contact E-mail: info@logipix.com Technical support: support@logipix.com Web: www.logipix.com... -
Page 2: Table Of Contents
Connect the CAT5 cable......................8 Connect the power cable......................8 Setting the fix cameras' final position..................9 Setup the focus and the Iris.......................12 Setup the Iris..........................13 Installation of the Logipix Full HD Box camera............15 Camera Rear Panel........................15 Lens Mounting..........................16 Mount the camera........................16 Power up the Camera........................16 Ethernet Cable Connection.......................17... - Page 3 Install the HDDs........................30 Mounting the LNVR into the rack cabinet................31 Connecting to the network......................31 Connecting the Logipix cameras and the Hybrid extenders to the LNVRs....32 Connecting the power and power on..............32 Checking LED information..................34 Checking LED information of the cameras..............35 LEDs of the Logipix multi-megapixel cameras................35...
- Page 4 Configuring PTZ Area......................68 System usage....................71 The Event.........................71 Controlling the Monitor Profile................73 Watching live pictures.......................73 Watching the archive.........................73 Controlling the Logipix Full HD PTZ..................76 Saving pictures..........................76 Printing pictures........................77 Saving the archive........................77 Using the LPlayer to watch .scv files................78 Installation of the LPlayer......................78 Associate .SCV files........................78...
-
Page 5: Hardware Installation
LNVRs by CAT6/optical cables (requires additional SFP modules). Ensure the proper power supplies for the Logipix multi-megapixel fix cameras, Logipix FullHD fix cameras, the Logipix PTZ cameras, the Logipix Hybrid extenders and the LNVRs. See the Appendix A at the end of the Hardware installation chapter... -
Page 6: Installation Of The Multi-Megapixel Fix Cameras
Installation Guide Installation of the Multi-megapixel Fix cameras Installation steps • Unpack the camera • Remove the sensor's protective cap • Mount the lens • Mount the camera on the position fine-tuning panel • Install the camera in a camera enclosure •... -
Page 7: Mount The Camera On The Position Fine-Tuning Panel
Installation Guide Mount the camera on the position fine-tuning panel Remove the protective stick from the bottom of the camera. Suit the Logipix camera to a mounting hole of the upper part of the position fine-tuning panel, depending on whether you want to install the camera in a vertical or in a horizontal position (9 or 10)! Use a M5×6 size screw to fix the camera on the... -
Page 8: Connect The Cat5 Cable
Installation Guide • It must have sun shield Mount the lower part of the positioning panel into the camera house. To install the Lower part of the panel in an enclosure, follow the steps of the enclosure's user manual! It is important to install the camera in the enclosure at the best position. -
Page 9: Setting The Fix Cameras' Final Position
Installation Guide through the cable gland of the camera enclosure and connect it to the two-pin power connector of the camera (GND and +12V phase). The spring connectors can be found at the back of the camera. Use a screwdriver to push in the orange colored plastic spring lifter, connect the wires then release the spring lifter! Setting the fix cameras' final position... - Page 10 Installation Guide you want. On the next window sign the Create shortcut on desktop checkbox, then click on Next! After you've read the installation summery, click on Install! After the installation has finished, restart your computer! • Connect the Local Network Switch to your computer and run the SCPlayer by clicking on the desktop icon! Adjust the IP address of the camera in the pop up window! The camera picture is going to be shown immediately on the video monitor surface of the software.
- Page 11 Installation Guide • Loosen the fixing screws (2), (4), (5), (6) • Set the rotation (horizon) with screws (1) and (3) • Set the pan position (height of the horizon) with screw (7) • Set the tilt (horizontal) position of the camera with screw (8) •...
-
Page 12: Setup The Focus And The Iris
3. Rotate the Iris fixing screw clockwise to tighten it and to fix the Iris position! In case of a P-iris lens Enter the camera configuration menu in the SCPlayer software by pressing C Locate the camera in the list on the left side of the window Find the “Logipix settings” node 12/80... -
Page 13: Setup The Iris
Select the “III” tab Select P-iris, and save settings The focus of the Logipix camera can be set easily with a special configuration function which you can find in the free SCPlayer software. The function utilizes the traits of the JPEG2000 compression standard, that more details - with the same compression -, results a larger image size. - Page 14 Installation Guide 3. To close the Iris rotate the ring clockwise! To open it, counter- clockwise is the right direction. 4. Rotate the Iris fixing screw clockwise to tighten it and to fix the Iris position! NOTE: The Iris controls the amount of the light passing through the lens. The smaller the aperture opening, the less light can reach the camera sensor.
-
Page 15: Installation Of The Logipix Full Hd Box Camera
Installation Guide Installation of the Logipix Full HD Box camera Camera Rear Panel DC 12V / PoE DC 12V/ AC 24V/ PoE Connector Definition LINE OUT & LINE IN Two-way audio transmission Power LED Power connection indication (green light) Reset to factory default; press the button with... -
Page 16: Lens Mounting
Installation Guide Lens Mounting If C-Mount lens is used, after removing the camera’s plastic cover, you need to mount the supplied C/CS mount adapter to the camera. Then attach the lens onto the C/CS mount adapter. Rotate it clockwise. Connect the iris cable to the rear part of the camera. -
Page 17: Ethernet Cable Connection
Installation Guide Ethernet Cable Connection • Connect one end of the CAT5 Ethernet Cable to the PoE Network Connector of the IP Camera, and the other end of the cable to the network switch or PC. NOTE: In some cases, Ethernet Crossover Cable might be needed when connecting the IP Camera directly to the PC. -
Page 18: Installation Of The Logipix Full Hd Dome Camera
Installation Guide Installation of the Logipix Full HD Dome camera Connectors of the camera Connector Definition Remarks Reset Button Restore to factory default Analog Video Output (Input － ) Alarm I/O Input＋ Alarm connection Output－ Output＋ Output (L) Output (R) -
Page 19: Dismount The Camera From The Mounting Bracket
Installation Guide Dismount the camera from the mounting bracket • Dismount the enclosure of the camera with the included tool! • Loosen the fixing bolt with a Phillips screw driver! • Push the locking tabs at the sides! • Pull out the camera module from the mounting bracket! Mount the bracket of the camera •... -
Page 20: Setup The Position And The Viewing Angle
• Set the position of the camera with the console or the housing positioning options. • Set the viewing angle and focus using the rings of the lenses! Installation of the Full HD Logipix PTZ cameras Installation steps • Unpack the camera •... -
Page 21: Drill The Holes
Installation Guide Drill the holes Locate the planned position of the Logipix PTZ camera. Drill the proper size holes in the surface according to hole positions of the drill template which you can find in the packet! Place 12×100 wall-plugs in the holes! -
Page 22: Fix The Camera On The Mounting Bracket
Installation Guide Fix the camera on the Mounting bracket • At first lead the cables of the camera through the mounting bracket! • Place the mounting bracket to the connecting part of the case on the top. The connecting part of the case is designed with an edge on it. The three tightening screws of the mounting bracket will hold tight the camera by this edge. -
Page 23: Connecting The Lan
Connect the external power supply to the power cable of the camera! Check the operation of the PTZ cameras • Connect the Logipix PTZ camera to your computer and run the previously installed SCPlayer by clicking on its desktop icon! Adjust the IP address of the PTZ camera in the pop up window! The camera picture is going to be shown immediately on the video monitor surface of the software. -
Page 24: Installation Of The Logipix Hybrid Extenders
Installation Guide Installation of the Logipix Hybrid Extenders • Mounting the Hybrid Extender into the rack cabinet • Connecting the analog cameras • Connecting the CAT5 cables • Power on • Checking LED information Rear view Connector Name Power connector... -
Page 25: Mounting The Hybrid Extender Into The Rack Cabinet
Installation Guide Mounting the Hybrid Extender into the rack cabinet The 1U high Hybrid extender can be mounted in a 19” rack cabinet. 1. Place 4 pieces of M6 cage nuts (2 on each side) on the front columns of the rack cabinet according to the mounting holes of the Hybrid Extender, which you can see at the edges of the front panel! 2. -
Page 26: Connecting The Analog Cameras
Connect the CAT5 Ethernet cables' to the RJ-45 sockets of the Hybrid Extender! The sockets can be found at the back of the Hybrid extender. Power on You need to power the Logipix Hybrid Extender using the bundled 12V DC power supply. The extender will boot immediately upon powering. 26/80... -
Page 27: Checking Led Information
Installation Guide Checking LED information The left side The right side Status Description Ready LED Blinking red Normal operation Net Link LED Lights up in orange Network link present Net Act LED Blinking green Network communication Camera LEDs (Video Lights up green Normal operation Signal) Dark... -
Page 28: Installation Of The Lnvrs (Rack-Mount)
Installation steps 1. Install the HDDs 2. Mounting the LNVR into the rack cabinet 3. Connecting to the network 4. Connecting the Logipix cameras 5. Connecting the Hybrid Extenders 6. Connecting the power 7. Power on 8. Checking LED information... -
Page 29: The Front View
100 MBps Ports 1-16 LPoE ports for direct Hybrid Extender connection GIGABIT Port G17 Camera VLAN – Gigabit port for the Logipix cameras (Local Network Switch must be connected here) GIGABIT Port G18 Camera VLAN – Gigabit port for the Logipix... -
Page 30: Install The Hdds
GIGABIT Port G20 VMS VLAN – Gigabit port for company network connection Optical Port 1 Camera VLAN – Optical port for the Logipix multi-megapixel fix cameras (connected to the Local Network Switch) Optical Port 2 Camera VLAN – Optical port for the Logipix... -
Page 31: Mounting The Lnvr Into The Rack Cabinet
Installation Guide Only those rows get power which have at least one configured HDD. Mounting the LNVR into the rack cabinet The 6U high LNVR can be mounted in a 19” rack cabinet. 4. Place 6 pieces of M6 cage nuts (3 on each side) on the front columns of the rack cabinet according to the mounting holes of the LNVR, which you can see at the edges of the front panel! 5. -
Page 32: Connecting The Logipix Cameras And The Hybrid Extenders To The Lnvrs
Installation Guide Connecting the Logipix cameras and the Hybrid extenders to the LNVRs All the Logipix cameras, the Logipix Full HD cameras, the Logipix Full HD • PTZ cameras and the Logipix multi-megapixel cameras and the Logipix hybrid extenders must be connected to Local Network Switches of the CAMERA VLAN. - Page 33 Installation Guide Optionally two external 24V battery cells (ACCU1 and ACCU2) can be connected to the LNVR according to the draw above. In case of blackout the LNVR is able to further operate. To calculate the operation time after the power failure has occurred take into consideration the power consumption of the LNVR and the electrical charge of the battery cells! 33/80...
-
Page 34: Checking Led Information
Installation Guide Checking LED information System LED states during startup: States Description System Lights up in red LNVR is starting up (it lasts about 11.5 sec) Lights up in yellow Initialization Stays yellow for a There is no communication long time with the motherboard (no watchdog) Lights up in green... -
Page 35: Checking Led Information Of The Cameras
Lights up in green Operation from external battery Blinking in green ACCU is charging Lights up in yellow ACCU voltage under 22V Lights up in red ACCU Low Checking LED information of the cameras LEDs of the Logipix multi-megapixel cameras LED1 LED2 35/80... -
Page 36: Leds Of The Logipix Ptz Cameras
Blinking in green and red if the camera is ready to LEDs of the Logipix PTZ cameras • The LEDs can be found inside the camera enclosure. To make them visible, you have to unscrew the hexagonal metal cover panel, which you find at the front bottom of the horizontal rotating part of the camera case. -
Page 37: Appendix B
Analog camera 0.06 * The LNVR records the video stream of the Logipix 15 MP cameras and the Logipix PTZ cameras using a VRM fail-safe file system which means the frames of the video stream are stored divided on four HDDs at once. Thus there is no need to mirror the data. -
Page 38: Installing The Software
Installation Guide Installing the software Installing the server Hardware configuration Name Recommended Operating system Windows Server 2008 x64 or Windows 7 x64 Processor Intel Core i7 – Quad Core System RAM 8 Gbyte RAM Graphics card ATI Radeon HD 5450 Hard Drives 1 TB HDD Before the installation... -
Page 39: Installation Steps
Installation Guide Software ports: 3050 10272 10704 10240 10700 10705 10262 10701 10710 10263 10702 10800 10271 10703 10806 Installation steps • Put the installation CD in the server computer and run STPInstall.exe! • Choose Installation! • After reading the welcome message, click Next! •... -
Page 40: Installing The Workstations
Installation Guide Installing the workstations Hardware configuration Name Recommended Operating system Windows 7 x64 Processor Intel Core i7 – Quad Core System RAM 8 Gbyte RAM Graphics card ATI Radeon HD 7750 Hard Drives 1×3 TB HDD Before the installation •... -
Page 41: Installation Steps
Installation Guide Software ports: 3050 10272 10704 10240 10700 10705 10262 10701 10710 10263 10702 10800 10271 10703 10806 Installation steps 1. Put the installation CD in the client computer! 2. Install a Firebird client according to your operation system! The Firebird client can be found in CD:\Utils\Other\firebird\FB v2.5.2 folder. - Page 42 Installation Guide Allow to open the new file (Yes), then browse the proper software key for the given client computer from the Keys folder of the Installation Adjust a User name and a Password! The AccAlarm.ini file is going to be created in C:\STP folder. 42/80...
-
Page 43: Software Configuration
Add new controller icon... as well! The window of the New item appears. Enter the Name of the LNVR, adjust its IP address and choose Logipix NVR Enterprise from the Type list! Click on OK! - Page 44 LNVR! Sign Raid group 1 and Raid group NOTE: Do not select any HDD which is not in the LNVR, because it can cause permanent reboots. 5. Repeat the previous two steps with all the Logipix LNVRs of the system! 44/80...
- Page 45 Installation Guide 6. Right click on the LNVR in the left tree and choose Add new logipix or hybrid! In the popup window select Logipix! Enter the Name of the Logipix multi-megapixel camera, adjust its IP address, Select Normal Housing and choose Logipix 15 from the Type list! Adjust the Line where the camera is connected! It is the 1 (Gigabit) in case of the first camera.
- Page 46 Installation Guide 9. Repeat the previous step with all the Logipix PTZ cameras of the Logipix LNVR! Right click on the LNVR in the left tree and choose Add new logipix or hybrid! In the popup window select Logipix! Enter the Name of the...
- Page 47 Installation Guide Repeat the previous step with all the Hybrid extenders of the Logipix LNVR! Right click on the Hybrid Extender in the left tree and choose Add new camera! In the popup window enter the Name of the analog...
-
Page 48: Automatic Registration
Logipix 15MP cameras it is recommended to set YES value to the HaveABF fields. These parameters can be adjusted later during camera configuration, but this is a faster way to set all Logipix 15MP as cameras with Auto Back Focus module. Template is optional as well. It can be later adjusted during camera configuration. - Page 49 Installation Guide 3. Click on Read import file button and browse the appropriate predefined text file! Select it and click on Open! The software is going to build up the Import structure of the devices automatically. If there are some problems in the structure the program signs it with red warning messages in the proper lines.
-
Page 50: Configuring The Devices
The ABF module changes the position of the sensor to find the right focus. It can be used with the 15 megapixel Logipix camera with ABF module. The ABF setting must be performed individually for all the Logipix 15MP cameras. - Page 51 Installation Guide 6. To find the right focus, use the ABF Position slider! You can adjust it manually, or you can use the Automatic focus search. There is a graph between the sliders, which shows the actual focus value. In case of automatic adjustment the program moves the sensor between the two end positions (from -2700 to 2700) and finds the max focus value.
-
Page 52: Configuring The Logipix Multi-Megapixel Cameras
Configuring the Logipix multi-megapixel cameras 1. Click on the Configure icon on the main software surface! 2. Select the Logipix multi-megapixel camera in the left tree which you would like to configure! Click on the '+' sign near the camera name and select Settings! 3. -
Page 53: Configuring The Logipix Full Hd Cameras
Configuring the Logipix Full HD cameras 1. Click on the Configure icon on the main software surface! 2. Select the Logipix Full HD camera in the left tree which you would like to configure! Click on the '+' sign near the camera name and select Settings! 3. -
Page 54: Configuring The Logipix Ptz Cameras
Configuring the Logipix PTZ cameras 1. Click on the Configure icon on the main software surface! 2. Select the Logipix PTZ camera in the left tree which you would like to configure! Click on the '+' sign near the camera name and select Settings! 3. -
Page 55: Configuring The Analog Cameras
Installation Guide Configuring the analog cameras 1. Click on the Configure icon on the main software surface! 2. Select the Hybrid extender in the left tree to which the analog camera is connected! Click on the '+' sign near the Hybrid extender! The cameras of the device appear. -
Page 56: Configuring The Analog Ptz Cameras
Installation Guide 6. If the new setup is selected, adjust the lower quality configuration for after the event! This camera setup will operate when the Event has closed. Configuring the analog PTZ cameras 1. Click on the Configure icon on the main software surface! 2. -
Page 57: Set The Rest Of The Cameras As Camera Groups
Device type radio button! Chose the camera type which cameras you would like to configure at once! (Logipix 15MP camera / Logipix Full HD PTZ camera / Logipix 2MP camera / analog camera / analog PTZ camera) 2. - Page 58 Installation Guide 5. In case of selecting several cameras, a table is going to be displayed at the place of the camera pictures. The rows of the table contain the selected cameras and the columns of the table contain the parameters and the setups of the cameras.
-
Page 59: Download Settings
Installation Guide Download settings After you have set all the cameras, you need to upload the configuration settings to the LNVR. Click the “arrow” icon on the toolbar! The following popup • window appears: • You have the opportunity, to select the LNVRs individually, or you can upload the configuration to all at once. -
Page 60: Creating Camera Setup Groups
3. Enter a Name and an Export code for the Panorama camera! (The export code can be any name that contains only letters (A-Z) and numbers (0-9) Click OK. 4. Assign the appropriate Logipix multi-megapixel cameras to the Panorama camera! The list of the Selectable cameras can be seen on the right. 60/80... -
Page 61: Creating Monitor Profiles
Installation Guide Move those cameras to the list on the left (Selected) which form a Panorama camera picture! Use the traditional Drag & Drop method, or use the Add button! 5. At the X position of the camera field set each camera's X axis position according to their physical position in the line of the cameras! Number one is the camera that records the left side of the panoramic image. -
Page 62: Stitching The Images Of The Panorama Cameras
Installation Guide profiles in the Video Monitor. If this will be the primary Monitor profile at the workstation, adjust “1”! 4. The previously registered devices can be found in the left tree. Choose the camera which you would like to place on the profile, then Drag & Drop it to the matrix! The size of the matrix is determined by the software according to the monitor resolution. - Page 63 Installation Guide Control Center software! 3. The previously created Monitor Profile with the Panorama camera appears on the left as a button with its name. Click on it! Now the camera pictures are shown in the Video monitor. 4. Once the connection is established, the pictures of the IP cameras which are in the common camera group can be seen side by side.
- Page 64 Installation Guide 9. Place the markers at every image border! The placed markers can be relocated. Move the mouse pointer over the marker, press Shift then the middle mouse button at the desired position! The undesired markers can be deleted by Shift+right mouse button.
- Page 65 Installation Guide hold the Shift button and designate the areas at the border of an image by placing at least 3 points by the left mouse button. Place the points on the neighboring image as well to appoint approximately the same area. You can go back to edit stitching points if you press the N key.
-
Page 66: Ptz Area Configuration
Logipix Full HD PTZ cameras can be controlled on the Logipix panoramic camera images in the Video Monitor by selecting a desired area. To perform this action we have to configure special PTZ guidance points on the Logipix camera image and on the uploaded map. Based on these guidance points the Logipix Full HD PTZ cameras can find the appointed area. -
Page 67: Creating A Configuration Monitor Profile
Installation Guide Creating a configuration monitor profile 1. To configure PTZ Area function, create a new Monitor Profile, marked as Configuration Window, with two zoom windows! This profile will be visible only in the PTZ Area Configuration window. 2. Click on the Monitor profiles icon on the main surface of the Control Center! 3. -
Page 68: Configuring Ptz Area
Installation Guide camera, selecting PTZ cameras from the left tree! 5. Click on OK, then close the Monitor Profiles window! Configuring PTZ Area 1. Click on Video menu and open Setup / PTZ Area Config! 2. Choose the previously created profile, which you can find in the lower left corner! 3. - Page 69 If you have created, modified or deleted a point accidentally, you can use the ESC key to undo your last action. Create at least six point-pairs with this method for each Logipix PTZ camera. Try to create the points forming triangle shapes (place them as they would be the apexes of triangles), and avoid to place all of them on one common line.
- Page 70 Installation Guide Activating the M icon on the PTZ image, you can modify the position of the crosshair on the PTZ, namely you can choose to assign the actual deignated point of the panoramic image/map to the center or any corner of the PTZ image.
-
Page 71: System Usage
System usage This part of the document gives information about the usage of the Control Center software, which performs complex supervision tasks of the Logipix Stadium Video Surveillance System. Start the Control Center software clicking on its icon on the desktop! - Page 72 Installation Guide • Open the Event management form! You can find it in the Video / Stadium menu. • Create a new Event by the New button! • Name it in the Event name field! • Enter the Date of the event! (This is only administrative information) •...
-
Page 73: Controlling The Monitor Profile
Installation Guide Controlling the Monitor Profile Watching live pictures 1. Open the Video Monitor! Click on its icon on the main surface of the Control Center software! At every Video Monitor launch or profile change the connecting information are shown at the place of the camera pictures. Steps of the connection procedure can be seen textually, and the camera name appears in between round brackets. - Page 74 Installation Guide Jump to the beginning Play backward with higher speed: Pushing it once the playback starts backward at double speed. For other presses it increases the speed to 4x and after 8x, till 16x. After reaching the maximum speed for another press the record is going to be played at double speed.
- Page 75 Installation Guide The second: • Set the time interval of the desired archive period by the date and time fields at the bottom of the window! Move the mouse pointer over the desired camera picture(s) and select them by clicking the •...
-
Page 76: Controlling The Logipix Full Hd Ptz
Controlling on the panoramic image You can select a Logipix PTZ camera that you want to control by moving your mouse pointer on the Logipix panoramic image. Click the pin icon in the lower right corner of the PTZ camera picture. -
Page 77: Printing Pictures
Installation Guide 6. Choose the destination path of the files in the pop-up window! 7. Name the file! 8. Click on Save button! Printing pictures 1. Select the camera(s) which from you would like to print a still image or images on the Video Monitor! 2. -
Page 78: Using The Lplayer To Watch .Scv Files
Using the LPlayer to watch .scv files LPlayer has been developed to play the downloaded video streams, saved in Logipix Video Surveillance System. LPlayer is a simple, easy to use software to play the saved video files of the surveillance system. The video streams can be played forward or backward at different speeds and they can be stepped frame by frame. -
Page 79: Open A File From The Software
Installation Guide Open a file from the software To open an .SCV file to be played, click on the Browse icon. • In the popup window you can find the right folder of the desired .SCV file. If you have found the folder, double click on the file or use the Open button, and the player is going to display the video stream immediately. - Page 80 Installation Guide 4. Place the markers at every image border! 5. The placed markers can be relocated. Move the mouse pointer over the marker, press Shift then the middle mouse button at the desired position! The undesired markers can be deleted by Shift+right mouse button.
