- Page 1 Flashlink User Manual CWDM-1-8/9-16 CWDM-1-8-M/9-16-M CWDM-1-8-L/CWDM-9-16-L 8-channel CWDM multiplexer and demultiplexer/ - multi mode (-M)/ -low-loss (-L) Rev. 2...
-
Page 2: Revision History
CWDM-1-8/-9-16/1-8-L/9-16-L/1-8-M/9-16-M Rev. 2 Network Electronics ASA Thorøya P.O. Box 1020 N-3204 Sandefjord, Norway Phone: +47 33 48 99 99 Fax: +47 33 48 99 98 Email: support@network-electronics.com www.network-electronics.com Support Phone: +47 90 60 99 99 Revision history Current revision of this document is the uppermost in the table below. -
Page 3: Table Of Contents
3.1 Mounting the CWDM filter .................... 6 3.2 1-8 channel system......................6 3.3 9-16 channel system...................... 7 4 Laser safety precautions ..................8 General environmental requirements for Network Electronics equipment....9 Product Warranty ....................10 Appendix A Materials declaration and recycling information ........11 A.1 Materials declaration ....................11 A.2 Environmentally-friendly use period ................ -
Page 4: Product Overview
CWDM-1-8/-9-16/1-8-L/9-16-L/1-8-M/9-16-M Rev. 2 1 Product overview The Flashlink CWDM (Coarse Wavelength Division Multiplexing) system is based on all- optical modules for multiplexing and demultiplexing 8 CWDM wavelengths according to ITU-T G.694.2. Two sets of wavelengths, one from 1470 to 1610nm (1-8) and one from 1270 to 1410nm with an upgrade port. -
Page 5: Specifications
CWDM-1-8/-9-16/1-8-L/9-16-L/1-8-M/9-16-M Rev. 2 2 Specifications 2.1 Optical specifications Single mode Number of channels Ch. 1-8: 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610nm Available wavelengths Ch. 9-16: 1270, 1290, 1310, 1330, 1350, 1370, 1390, 1410nm Connector SC/UPC 5dB max for 8 channels Insertion loss (end to end, including connectors) 7dB max for 16 channels... -
Page 6: Connections
CWDM-1-8/-9-16/1-8-L/9-16-L/1-8-M/9-16-M Rev. 2 3 Connections 3.1 Mounting the CWDM filter The CWDM filter must be mounted in a Flashlink subrack. This is done from the rear of the subrack. Do not use force when inserting the CWDM filter, once the module’s upper rail aligns with the card rail in the subrack, it should slide easily into place. -
Page 7: Channel System
CWDM-1-8/-9-16/1-8-L/9-16-L/1-8-M/9-16-M Rev. 2 3.3 9-16 channel system Using the upgrade port of the CWDM-9-16 enables to have up to 16 wavelengths on a single fibre. Each set of 8 channels must first be connected like described in chapter 3.2, figure 3. Figure 5: 16-channel CWDM filters connected to main fibre network-electronics.com | 7... -
Page 8: Laser Safety Precautions
CWDM-1-8/-9-16/1-8-L/9-16-L/1-8-M/9-16-M Rev. 2 4 Laser safety precautions These are guidelines to limit hazards from laser exposure. All the available EO units in the Flashlink range include a laser. Therefore this note on laser safety should be read thoroughly even though there is no laser onboard this product. -
Page 9: General Environmental Requirements For Network Electronics Equipment
CWDM-1-8/-9-16/1-8-L/9-16-L/1-8-M/9-16-M Rev. 2 General environmental requirements for Network Electronics equipment The equipment will meet the guaranteed performance specification under the following environmental conditions: Operating room temperature range: 0°C to 50°C Operating relative humidity range: <90% (non-condensing) The equipment will operate without damage under the following environmental... -
Page 10: Product Warranty
Rev. 2 Product Warranty The warranty terms and conditions for the product(s) covered by this manual follow the General Sales Conditions by Network Electronics ASA. These conditions are available on the company web site of Network Electronics ASA: www.network-electronics.com network-electronics.com | 10... -
Page 11: Appendix A Materials Declaration And Recycling Information
See http://www.aeanet.org/GovernmentAffairs/qfLeOpAaZXaMxqGjSFbEidSdPNtpT.pdf for an unofficial translation of the draft guidance. For our own products, Network Electronics has chosen to use the 50 year figure recommended in this draft regulation. Network Electronics suggests the following statement on An “Environmentally Friendly Use Period”... -
Page 12: Recycling Information
Please contact Network Electronics’ Customer Support for assistance with recycling if this site does not show the information you require. Where it is not possible to return the product to Network Electronics or its agents for recycling, the following general information may be of assistance: −...
