Front & Rear Panel
Front
❶
1. Remocon senser (Red : Stand by, Green : Power on)
Rear
1. DC 12V To input DC power from power outlet.
2. AV IN/SPK OUT Video signals from a device, TV sound out.
3. COMPONENT Video signals from a device with component outputs
4. ANTENNA JACK Connect to an antenna or a cable TV system .

Accessory

Standard
※ ※ Connect a set of power cables between
White cable on the +12V signal, and
Black Cable on the GND signal.
Option
DC Power Supply
!
Power Sources-This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to
your car, consult your product dealer.
You must insert or replace the batteries in the remote controller when you:
Purchase the set.
Find that the remote controller is no longer operating correctly.
2
1
• Wipe the battery dry cloth and set properly confirming ends(+,-).
Use only Lithium Battery.
• Use finger sacks or non-metallic tweezers.
You open the battery lid
• Keep the battery in a dark, cool and dry place.
with coin.
• Do not throw the battery into fire, not recharge.
! You can use your remote controller within a distance of 7-10m and an angle of 30
degrees from the left and right sides of the remote controller receptor of your monitor.
Wall mount Lift Stand
