Avari Fitness A450-261 Owner's Manual

Adjustable height treadmill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Adjustable Height Treadmill
Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 250 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springfield, MO 65803
Customer Service
1 (800) 375-7520
www.staminaproducts.com
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: A450-261
STAMINA PRODUCTS
MADE IN CHINA
©
2014 Stamina Products, Inc.
2014, 05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A450-261 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avari Fitness A450-261

Summary of Contents for Avari Fitness A450-261

  • Page 1 When calling for parts or service, please specify the following number : Product May Vary Slightly From Pictured. Model#: A450-261 CAUTION: Weight on this product should not exceed 250 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Instructions ........2 Conditioning Guidelines ......16 Before You Begin ........4 Warm-Up and Cool-Down ......17 Equipment Warning, Caution & Notice Labels ... 5 Product Parts Drawing ......18 Hardware Identification Chart ....6 Parts List ............ 19 Assembly Instructions ........

  • Page 3: Customer Service

    Call Us First Customer Service 1 (800) 375-7520 www.staminaproducts.com THANK YOU FOR PURCHASING THE Avari® Adjustable Height Treadmill To enact your warranty, please register your product by going to register.staminaproducts.com To help you get started, we have pre-assembled most of your Avari®...

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the Avari® Adjustable Although Stamina constructs its products with Height Treadmill. We take great pride in producing the finest materials and uses the highest standards this quality product and hope it will provide many of manufacturing and quality control, there can hours of quality exercise to make you feel better, sometimes be missing parts or incorrectly sized...

  • Page 5: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the Avari® Adjustable Height Treadmill. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. Labels are larger than actual size CAUTION LABEL(63) MAINTENANCE DECAL(37)

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 2 Refer to illustration A. Attach the RIGHT UPRIGHT(4) to the MAIN FRAME(1) with BUTTON HEAD BOLT(M10x1.5x65mm)(43), and PLASTIC WASHER(ø10.2xø25x4mm)(25). Repeat on other side. STEP 3 Refer to illustration B. Rotate the LEFT and RIGHT UPRIGHTS(3, 4) to the upright position. Attach the LEFT and RIGHT UPRIGHTS(3, 4) to the BASE FRAME(2) with CARRIAGE BOLTS(M8x1.25x45)(42), WASHERS(M8)(61), and NYLOCK NUTS(M8x1.25)(19).
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 6 Refer to the illustration below. Attach the RIGHT HANDRAIL(5R), the one with EXTENSION WIRE(54), to the RIGHT UPRIGHT(4) with BUTTON HEAD BOLTS(M8x1.25x40)(34) and ARC WASHERS(M8)(60). Attach the LEFT HANDRAIL(5L) to the LEFT UPRIGHT(3) with BUTTON HEAD BOLTS(M8x1.25x40) (34) and ARC WASHERS(M8)(60).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 9 Refer to illustration C. Attach the METER CLIPS(51) to the back of the METER(52) with ROUND HEAD SCREWS(M5x0.8x10mm)(50). STEP 10 Install two AA batteries into the METER(52), the batteries are not included. See page 11 for detailed battery installation instructions.

  • Page 11: Operational Instructions

    OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON: Walking Belt movement or press any button. POWER OFF: Automatic shut off after 4 minutes of inactivity. mode reset FUNCTION BUTTONS: MODE : Press and release to select each function for display or preset target values. Press the button and hold it down for three seconds to reset all functions to zero.

  • Page 12: Belt Tension

    OPERATIONAL INSTRUCTIONS TREADMILL ADJUSTMENTS When adjusted properly, the Avari® Adjustable Height Treadmill’s WALKING BELT(11) will roll smoothly around the BOARD(10) and over the front and rear rollers without catching or rubbing. For the belt to run smoothly, there are a few points that need to be noted.
  • Page 13 OPERATIONAL INSTRUCTIONS MAIN FRAME HEIGHT ADJUSTMENT The MAIN FRAME(1) can incline to three different heights by moving the REAR SUPPORTS(23) up or down. Insert the PULL PINS(20) into the holes in the REAR SUPPORTS(23) to adjust. Choose the one that best meets your workout needs: the higher the height, the more level the walking surface while the lower height will provide more of an incline.

  • Page 14: Storage

    STORAGE 1. To store the Avari® Adjustable Height Treadmill, simply keep it in a clean dry place. 2. To avoid damage to the electronics, remove the batteries before storing the Avari® Adjustable Height Treadmill for one year or more. 3. To fold the Avari® Adjustable Height Treadmill for easy storage, follow this process. Refer to the illustrations below.

  • Page 15: Maintenance

    MAINTENANCE The safety and integrity designed into the Avari® Adjustable Height Treadmill can only be maintained when the Avari® Adjustable Height Treadmill is regularly examined for damage and wear. Special attention should be given to the following: 1. Adjust the TENSION KNOB(45) and verify that it functions properly and the resistance changes. 2.

  • Page 16: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 17: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place.

  • Page 18: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT BACK...

  • Page 19: Parts List

    PARTS LIST PART# PART NAME Main Frame Base Frame Left Upright Right Upright Handrail Front Handrail Front Roller w/ Flywheels Rear Roller Flywheel Cover Board Walking Belt Side Molding Left Rear Cap Right Rear Cap Bolt, Socket Head (M6 x 1 x 65mm) Adjustment Plate Plastic Spacer (ø12.2 x ø16 x 30mm) Magnetic Brake...
  • Page 20 PARTS LIST PART# PART NAME Handrail Cap Screw, Round Head (M4 x 25mm) Screw, Round Head (M5 x 0.8 x 10mm) Meter Clip Meter Sensor Connecting Wire Extension Wire Meter Connecting Wire Pulse Connecting Wire Pulse Sensor Long Foam Tube Foam Tube Arc Washer (M8) Washer (M8)

  • Page 21: Warranty

    LIMITED WARRANTY MODEL A450-261 WARRANTY Stamina Products, Inc. warrants that this product will be free from defects in materials and workmanship under normal use, service, proper assembly and proper operation for a period of 90 days on the parts and three years on the frame from the date of the original purchase from an authorized retailer.

  • Page 22: Notes

    NOTES...

  • Page 23: Fax/Mail Ordering Form

    TO CONTACT CUSTOMER SERVICE TO CONTACT CUSTOMER SERVICE For your convenience, Stamina’s customer service representatives can be reached by email at customerservice@ staminaproducts.com or by phone at 1-800-375-7520 (in the U.S.). Our customer service representatives are available Monday through Thursday from 7:30 a.m. until 5:00 p.m., and Friday 8:00 a.m. until 3 p.m. Central Time. ONLINE MAIL TELEPHONE...
