RANGE HOOD

Owner's Manual
H97.10SB
Thank you for your purchase of this
product. Please read the manual care-
fully before operating the appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H97.10SB and is the answer not in the manual?

Questions and answers

Summary of Contents for Premier Range H97.10SB

  • Page 1: Range Hood

    RANGE HOOD Owner’s Manual H97.10SB Thank you for your purchase of this product. Please read the manual care- fully before operating the appliance.
  • Page 2 Installation Diagram...
  • Page 3: Table Of Contents

    Contents Introduction………………………….1 Features……………………………...1 Installation………………………..2 Charcoal Filter (not supplied)…..3 How To Use…………………………..4 Lamp Change……………………..…5 Safety Information………………….6 Troubleshooting…………………..7 Specifications……………………….8 Cleaning & Maintenance……...…..9 Warranty……………………………...9...
  • Page 4: Introduction

    Introduction 1.1 This appliance has been manufactured with materials and processes that respect the environment. We hope that you will continue this important consideration in the opera- tion of this appliance & the disposal of the packaging mate- rials, thank you. 1.2 The installation work must be undertaken by a qualified technician experienced in cooker hood installation.
  • Page 5: Installation

    Installation 3.1 The range hood should be mounted at a distance of 650- 750mm from the cooking surface for safety & optimum per- formance (If the instructions for installation of the gas hob specify a greater distance, this has to be taken into account.) (see pic1).
  • Page 6: Charcoal Filter (Not Supplied)

    Charcoal filter (not supplied) The hood can install the charcoal filter which can make your kitchen cleaner. Step1. Remove this label if installing charcoal filter. Step2. Buckle the filter on the air cabinet and push it up. Step3. Press the catch and push it into the hole.
  • Page 7: How To Use

    How To Use adjustment 3 Speed adjustment adjustment pic 2). 3 Speed pic 2). ◆ Push the Low button, and the motor runs at low speed. ◆ Push Stop button, and the motor will stop. ◆ Push the Mid button, and the motor runs at mid speed. ◆...
  • Page 8: Lamp Change

    Lamp Change As with any maintenance on the appliance, first turn off the power supply by unplugging from the wall socket. From the rear of the lamp socket, detach the low-voltage electric con- nector. Then press the lamp’s clip to take out the lamp holder (see pic 3).
  • Page 9: Safety Information

    Safety Information ◆ There must permanent & adequate ventilation of the room when operating the range hood with appliances burning gas or other fuels. ◆ Do not check the status of the filters when the range hood is operating, wait at least 30 minutes after switching off to avoid scalding.
  • Page 10: Troubleshooting

    Troubleshooting If any problem occurs, please detach the plug from the socket and contact the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. Problem Cause Solution Light on, but motor The outlet valve is blocked Detach flue and duct then does not work turn on the hood to check if...
  • Page 11: Specifications

    Specifications H97.10SB Power Supply 240V~50Hz Rated Input Power 142W Lighting Power 2W×2 Motor Power 138W Airflow ≥900m³/h...
  • Page 12: Cleaning & Maintenance

    Cleaning & Maintenance Warning: Before cleaning, please ensure that the power is switched off by detaching the plug from the wall socket. 10.1 Clean the surface of hood every week with mild soap or detergent. Avoid solvents, acid, alkali, scouring pads or powders that could irreparably damage the stainless steel surface.
