Summary of Contents for Dessmann BG22
- Page 1 DESSMANN - FINGERPRINT SAFE BOX User Guide BG Series SMS Function Version 2014.01...
-
Page 2: Table Of Contents
Contents 1 Introduction 1.1 Packing List ..........1.2 Technical Data . - Page 3 CONTENTS CONTENTS 8 Contact Us...
-
Page 4: Introduction
Chapter 1 Introduction 1.1 Packing List Thank you for choosing a DESSMANN Safe Box. The following accessories are provided in order to set up and use your safe box: Item Product Reference 01/ Safe Box 1 Pce 02/ Mounting Screws... -
Page 5: Technical Data
1.2. TECHNICAL DATA CHAPTER 1. INTRODUCTION 1.2 Technical Data Safe Box Dimensions Outer Body (WxDxH) 385x220x420mm Inner Body (WxDxH) 414x323x214mm BG22 Volume 28 Liters Weight 21 Kg Outer Body (WxDxH) 380x330x280mm Inner Body (WxDxH) 374x268x274mm BG28 Volume 28 Liters Weight... - Page 6 1.2. TECHNICAL DATA CHAPTER 1. INTRODUCTION Specifications BG22-BG28 3mm Cold Rolling Plate BG45-BG65-BG85 4mm Cold Rolling Plate Door Panel Acrylic Glass Body Interior Finish Velvet Suede Power Supply 2 sets of 4 AA Batteries External Power Supply Battery Box Screen...
-
Page 7: Product Description
Chapter 2 Product Description... -
Page 8: Basic Instructions
Chapter 3 Basic Instructions 3.1 Batteries Setup One set of 4 AA batteries or two sets of 4 AA batteries are required to power the safe. 3.2 Mechanical Dial Very Important After you set up your safe for the first time, open the safe cache panel & turn the mechanical dial 4 times clockwise with a screwdriver to activate the mechanical opening method. -
Page 9: Sim Card
3.3. SIM CARD CHAPTER 3. BASIC INSTRUCTIONS 3.3 SIM Card If you want the safe box to communicate via SMS, you need to install a SIM card into it. Make sure this SIM card can operate in your country and has sufficient credit to to send SMS. At the back of the door, beside the battery case, press the small yellow button of the SIM card slot to release the SIM card case. -
Page 10: Quick Start
Chapter 4 Quick Start Functions Operation 1/ Press START to get to the logo Enter 2/ Press MENU System Menu 3/ Enter Admin Fingerprint (Default: none) 4/ Press ENTER 1/ Enter System Menu 2/ Select ”2.User Setting” Admin 3/ Select ”1.Add Admin FP” 4/ Scan Fingertip Twice 5/ Enter a Name. -
Page 11: Close The Lock
4.2. CLOSE THE LOCK CHAPTER 4. QUICK START pull the door. Best Practices To guarantee an optimal authentication: Make sure your finger is clean & dry Align your finger parallel to the authentication lens Do not move your finger for 2 seconds while scanning with Password Press START, enter password &... -
Page 12: Safe Menu
Chapter 5 Safe Menu DESSMANN lock management software let you easily manage your users. Browse with the arrows keys & press ENTER to confirm each step. 5.1 Enter the System Menu System can only be managed with the admin fingerprint. -
Page 13: Safe Settings
CHAPTER 5. SAFE MENU 5.2 Safe Settings 5.2.1 Unlock Mode There are 3 modes offered by DESSMANN safe box to open it: Fingerprint Only - Identification with fingerprint only Fingerprint OR Password - Identification with either fingerprint OR password Fingerprint & Password - Identification with both fingerprint AND password 5.2.2 Lock Password... -
Page 14: Set Time
5.2. SAFE SETTINGS CHAPTER 5. SAFE MENU 5.2.3 Set Time We recommend you to properly set the time to fully enjoy all the functions of your safe box. Change the values with the keypad. Press MENU to move to the next digit. Press ENTER to confirm. 5.2.4 Safe Alarm Set-up the Alarm function ON or OFF &... -
Page 15: User Settings
5.3. USER SETTINGS CHAPTER 5. SAFE MENU 5.3 User Settings 5.3.1 New Admin Scan the new admin fingertip twice. Enter a name for this admin using the keypad. The name can only have a maximum of 6 digits or charac- ters. -
Page 16: New User
5.3. USER SETTINGS CHAPTER 5. SAFE MENU 5.3.2 New User Scan the new user fingertip twice. Enter a name for this user using the keypad. The name can only have a maximum of 6 digits or characters. Press ENTER to confirm. Best Practices To ensure optimal results, register the same finger 2 to 3 times. -
Page 17: Information
5.4. INFORMATION CHAPTER 5. SAFE MENU 5.4 Information 5.4.1 Users Log Users log informs you about: User Name User Type – T for a user with Time Control selected (5.5.4 Time Control) – F for a user with Report function activated (5.5.3 Report User) –... -
Page 18: Sms Function - Chamberlain Techniques
5.5. SMS FUNCTION - CHAMBERLAIN TECHNIQUES CHAPTER 5. SAFE MENU 5.5 SMS Function - Chamberlain Techniques 5.5.1 Panic Password Enter the panic password (must be 6 digits, no more, no less), press ENTER, confirm it again, press EN- TER. Panic Function This password will open the safe &... -
Page 19: Report User
5.5. SMS FUNCTION - CHAMBERLAIN TECHNIQUES CHAPTER 5. SAFE MENU Panic User This user will open the door & send the following report SMS to the numbers selected in 5.5.5 (SMS Numbers - Panic Numbers): 5.5.3 Report User Select Report User with the arrows & switch this function ON or OFF, press ENTER to confirm. Report User This user will open the door &... -
Page 20: Sms Numbers
5.5. SMS FUNCTION - CHAMBERLAIN TECHNIQUES CHAPTER 5. SAFE MENU Enter the desired time zone using the keypad, press MENU to move to the next digit, press ENTER to confirm. In this example, the user can only open the door from the 1st of january 2014 to the 31st of december 2015, from 08:30 to 18:00, from monday (1) to friday (5). - Page 21 5.5. SMS FUNCTION - CHAMBERLAIN TECHNIQUES CHAPTER 5. SAFE MENU Panic Function A warning SMS will be sent to the above numbers every time one of the following is activated: 5.5.1 - Panic Password 5.5.2 - Panic User 6.1.1 - Illegal Intrusion Alarm 6.1.2 - Multi-attempts Alarm 6.2 - Batteries Low - First Warning SMS Center...
-
Page 22: Safe Functions
Chapter 6 Safe Functions 6.1 Alarm Functions 6.1.1 Illegal Intrusion Alarm If a thief is trying to steal or pick-lock your safe box, a buzzer will ring to scare him out. SMS Function The following warning SMS will be sent to the numbers selected in 5.5.5 (SMS Numbers - Panic Numbers): Move your Safe This function is deactivated for 10 minutes after each successful authentications with finger or pass-... -
Page 23: Batteries Low
6.2. BATTERIES LOW CHAPTER 6. SAFE FUNCTIONS SMS Function After After 10 failed fingerprint authentications or 5 failed password authentications, the following warning SMS is sent to the numbers selected in 5.5.5 (SMS Numbers - Panic Numbers): 6.2 Batteries Low When the batteries are low, a buzzer will bip as a warning when you open the door &... -
Page 24: Emergency Battery Box
6.3. EMERGENCY BATTERY BOX CHAPTER 6. SAFE FUNCTIONS Last Warning At last warning, the door cannot operate anymore, you should use the emergency battery box or the me- chanical opening method. 6.3 Emergency Battery Box In case the safe runs out of battery. You can power the system with the emergency battery box. Install 4 x AA Batteries in the emergency power box, open the cache panel &... -
Page 25: Mechanical Opening Method
6.5. MECHANICAL OPENING METHOD CHAPTER 6. SAFE FUNCTIONS 6.5 Mechanical Opening Method In case of system failure or damage, the lock can still be opened mechanically. Open the cache panel to access the mechanical dial. Check the opening code on 1.1 Packing list of the user guide provided with the safe. For example: 11 - 22 - 33 - 44. -
Page 26: Factory Reset
6.6. FACTORY RESET CHAPTER 6. SAFE FUNCTIONS 6.6 Factory Reset To delete all datas stored in the safe system, proceed to a factory reset: 1. Open the battery cover, leave one set of 4 batteries and take one single battery out 2. -
Page 27: Product Warranty
Chapter 7 Product Warranty DESSMANN warrants to the original purchaser that the hardware product shall be free from defects in material and workmanship for twelve (12) months from the date of purchase. If a defect covered by this warranty occurs during this warranty period, DESSMANN or a DESSMANN AUTHORIZED REPAIR CENTER will repair the defective hardware product or component, free of charge. - Page 28 Chapter 8 Contact Us Maintenance, Repair & Operations Tel: +86 571 8711 9266 Fax: +86 571 8711 9299 Mail: mro@dessmannlock.com www.dessmannlock.com...
