Vollrath Cayenne CBL2024 Operator's Manual
Hide thumbs
Also See for Cayenne CBL2024:
- Operator's manual (8 pages) ,
- Operator's manual (13 pages) ,
- Installation instructions manual (12 pages)
Advertisement
Quick Links
HEAVY DUTY CAYENNE
Item
Model
924CG CBL2024 Gas Char Broiler Radiant/Lava 24"
936CG CBL2036 Gas Char Broiler Radiant/Lava 36"
948CG CBL2048 Gas Char Broiler Radiant/Lava 48"
960CG CBL2060 Gas Char Broiler Radiant/Lava 60"
972CG CBL2072 Gas Char Broiler Radiant/Lava 72"
*Shipped setup for Natural Gas and includes a kit for conversion to Propane Gas
Conforms to ANSI
Z83.11b -2009
Certified to CSA
STD 1.8b - 2009
Thank you for purchasing this Vollrath equipment. Before operating the equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging. Use this
packaging to ship the equipment if repairs are needed.
Description
Conforms to
NSF Std. 4
Operator's Manual
GAS CHAR BROILER
®
BTU/hr
Gas Type
80,000
Natural Gas or Propane*
120,000
Natural Gas or Propane*
160,000
Natural Gas or Propane*
200,000
Natural Gas or Propane*
240,000
Natural Gas or Propane*
ENGLISH
Item No. 2350069-1 en Rev 06/14
