Summary of Contents for Premier designs Pyramid Racer
- Page 1 v e c t o r k i t e s b y p r e m i e r d e s i g n s...
- Page 2 Congratulations! Welcome to the world of Vector Kite Flying. Keep in mind that you are now one of the first pioneers of this exciting new RC sport. Vector Kite Flying offers you new challenges and excitement not found in any other form of model aviation.
-
Page 3: Names Of Parts
Names of Parts King Post Fitting Cross Strut King Post Arrow Knock Arrow Knock Loop 707 Vector Power Wing Loop Wing Unit Loop Spine Nose... -
Page 4: Parts List
Parts List Vector Power Unit V707 Completed Pyramid Racer Sail 10242 Blue Flash 10243 Tecmo Nose Strut 10285 Pyramid Racer Spine (Complete) 10241 V707 Vector Power Unit Vector Power Receiver Unit Frame 7520 MG Servo 1 7520 MG Servo 2... - Page 5 Kite Assembly Instructions Packaged Kite Cross Strut Unrolled Kite Unroll the kite. Set aside the Cross Strut King Post Fitting Cross King Post Strut Loop Attach the Cross Strut. Slide the Cross Strut through the King Post Loop. Make sure the King Post Fitting is in between the King Post Loops.
- Page 6 King Post Cross Fitting Strut Vector Power Unit Strut Vector Power Unit Connect the Vector Power Unit. Insert the top of the Vector Power Unit into the King Post Fitting. Power Unit Power Unit Fittings Connect the bottom of the Vector Power Unit. Insert the bottom of the Vector Power Unit into the Power Unit Fittings on the Spine.
- Page 7 Connect the remaining Wing Loop by bowing the Cross Strut and slip the Wing Loop into the Arrow Knock. Construction Tip Although the Pyramid Racer is extremely durable and made of the highest quality carbon struts, on a hard nose down crash, it is possible to break the Nose Strut.
- Page 8 5200 Lawrence Place Hyattsville, Maryland 20781, USA Toll Free: 1-888-416-0174 Phone: 301-277-3888 Fax: 301-277-3323...
