Accessories
Power cable
(x1)
Instructions
1
5
Please take notice of the voltage and make sure it will be safe
Control method
Control button
Switch control button
Infrared controller
(x1)
2
6
Remote control
UP
STOP
DOWN
MICRO-DOWN
MICRO-UP
Caution:
-- The minimum distance between receiver and controller is 0.5 meter.
- Controller will work within 30 degrees away horizontally from the center of the
receiver point within 8 meters from the screen.
- The controller will not work if the signal is covered by something.
- Keep the controller away from high temperature and humidity.
- Please change the battery when the signal is low.
- Please remove the battery from the remote control when the controller
is not being used for a long time.
- Please use the same type of battery as original supplied.
- After 3 minutes of inactivity, the receiver will turn on automatic standby.
- If the receiver is to be out of use for a long time, please turn the electricity off
or unplug it.
- When pressing the control button you will hear a sound from the receiver,
which means it is working, normally.
External IR receiver
3
7
Integrated infrared receiver
Infrared receiving window
0.5 m min
17 m max
E
den
(x1)
Allen key
4
+
-
-
External infrared receiver
or
Infrared jack
http://www.lumene-screens.com
(x1)
2 x 1.5V
AAA x 2
-
+
+
