Summary of Contents for Raysharp D6004
- Page 1 User Manual...
-
Page 2: Table Of Contents
User Manual CONTENTS Chapter 1: DVR Features ............................1 DVR Feature ..............................1 Chapter 2: Overview ..............................1 2.1 Front Panel ..............................1 2.2 Rear Panel ..............................2 2.3 Remote Control ............................3 Chapter 3: Installation.............................4 3.1 Install Hard Disk ............................4 3.2 Connecting Camera and Monitor .........................4 3.3 VGA Output (optional)..........................4 3.4 Connecting Power Supply ..........................4 Chapter 4: Starting the DVR...........................5... - Page 3 User Manual 6.2 Audio Recording ............................19 6.3 Stop Recording ............................20 6.4 Estimated Recording Length ........................20 Chapter 7: Playback...............................20 8.1 Driver Installation ............................21 8.2 Program Interface – Button Functions .......................21 8.3 Program Running ............................22 8.3.1 HDD play mode ..........................22 8.3.2 FILE play mode..........................23 8.3.3 NET play mode ..........................23 Chapter 9: Specification ............................24 Chapter 10: Appendix ............................25...
-
Page 4: Chapter 1: Dvr Features
User Manual Chapter 1: DVR Features DVR Feature MPEG-4 compression 4-Channel: 4 BNC Camera Inputs - 2 BNC Video Outputs 9-Channel: 9 BNC Camera Inputs - 1 BNC Video Output 4-Channel: 2 Audio Inputs - 2 Audio Outputs 9-Channel: 1 Audio Input -1 Audio Output System Format : NTSC /PAL Motion Detection with Sensitivity and Area Settings Time Schedule, Alarm and Motion Triggered Recording Modes... -
Page 5: Rear Panel
User Manual 18. Power LED 19. IR receiver :Select/Edit/Right 20. HDD LED 17. PTZ：Enter or exit PTZ mode 9-ch DVR front panel 2.1.2 14. :DOWN Circumgyrate Door (optional) 2. SEARCH : 3. MUTE : Turn on/off audio output 4. CH- : View previous channel : Menu/ESC/Left 5. -
Page 6: Remote Control
User Manual 1. Audio Inputs 7. Audio Outputs 2. Video Outputs 8. CH1-CH4：Video input1- video input4 3. VGA Output (Optional) 9. RS-485/SENSOR/ALARM 4. USB Port (Optional) 10. Power Input Jack 5. POWER Switch 11. Grounding 6. LAN: Ethernet port 9-ch DVR rear panel 2.2.2 1.Audio output 7.POWER Switch... -
Page 7: Chapter 3: Installation
User Manual Chapter 3: Installation 3.1 Install Hard Disk NOTICE Don’t take out HDD when DVR is running. (1) Take out the Hard Disk Drive tray carefully. (2) Connect the power cord and data cable to hard disk carefully. (3) Put the Hard Disk Drive tray back into the DVR and then lock the HDD tray. 3.2 Connecting Camera and Monitor There are 4/9 camera inputs and 2/1 Monitor outputs with BNC connectors (Refer to 2.2 Rear Panel). -
Page 8: Chapter 4: Starting The Dvr
User Manual Chapter 4: Starting the DVR 4.1 Firmware Version After connecting the power adapter and turning on the power button, the system will boot-up and V1.9 display the version and released date of the DVR V-EN-BG firmware. 2008.2.23 4.2 Detecting Installed Hard Drive DVR will detect the installed hard drive and display the hard drive information. -
Page 9: Chapter 5: Dvr Menu System
User Manual Chapter 5: DVR Menu System Navigating the Menus Press [MENU] to enter Main Menu MAIN MENU Press [▲, ▼, ] button to move the CAMERA SETUP cursor RECORD SETUP RECORD FRAMERATE VIDEO QUALITY NORMAL Press [SEL] to select/modify settings RECORD SCHEDULE SENSOR SETUP HARD DRIVE SETUP... -
Page 10: Record Setup
User Manual If a camera channel is set to OFF, it will not be recorded (Refer to 6.4 Record Setup) Note： Record Setup Record Setup allows you to set up recording 1 ON NOCAM channels. RECORD SETUP Press [▲, ▼, ] button to select a channel, and then press [SEL] to modify the setting to ON or OFF. -
Page 11: Sensor Setup
User Manual time of day. The time line indicates 24 hours of a day based RDCORD SCHEDULE on AM/PM (0 = 12). 0… 3… 6… 9… 0… 3…. 6… 9… Press [▲, ▼, ◄◄ or ►►] button to select a time point, press [SEL] to modify the recording NO-RECORD NORMAL-RECORD... -
Page 12: Motion Detector Setup
User Manual For 4-ch DVR, there are 4CH inputs of the sensor Note: For 9-ch DVR, there are 8CH inputs of the sensor 5.10 Motion Detector Setup This section allows you to set up motion detection options for each camera. Motion Detector Setup: ON/OFF: Enable or disable motion detection MOTION DETECTOR SETUP... -
Page 13: Miscellaneous Setup - Change Password
User Manual by the DVR : You will be prompted for the password when formatting a hard drive. The default Note password is “111111” 5.12 Miscellaneous Setup - Change Password This option allows you to change the system MISCELLANEOUS SETUP password. -
Page 14: Miscellaneous Setup - Hidden Channel
User Manual 5.14 Miscellaneous Setup - Hidden Channel The system provides a function to hide a channel MISCELLANEOUS SETUP on monitoring mode. The selected channel can still be CHANGE PASSWORD recorded while it’s hidden; the hidden picture is SET TIME [ 4 ] HIDDEN CHANNEL viewable during playing back. -
Page 15: Miscellaneous Setup - Image Parameters
User Manual 5.17 Miscellaneous Setup - Image Parameters You can adjust the image parameters MISCELLANEOUS SETUP according to your needs. [ 1 ] CHANGE PASSWORD SET TIME Move the cursor to this selection and press HIDDEN CHANNEL [ CH3 ] AUDIO PORT SETUP [ OFF ] ] or [... -
Page 16: Miscellaneous Setup - Keypad Tones
User Manual 5.19 Miscellaneous Setup - Keypad Tones This function allows you to enable /disable MISCELLANEOUS SETUP buzzer sound when pressing a button. Press [SEL] CHANGE PASSWORD SET TIME to select ON or OFF. HIDDEN CHANNEL [ 4 ] AUDIO PORT SETUP PTZ SETUP IMAGE PARAMETERS [ CH4 ]... -
Page 17: Network Setup
User Manual 5.22 Network Setup Network Setup allows you to prepare the DVR for viewing over the internet or local network. In a local area network(LAN)， MAC ADDRESS: NETWORK SETUP the MAC (Media Access Control) address is your computer’s unique hardware identity code(On an <00:11:22:33:44:55>... -
Page 18: User Manual
User Manual GATEWAY: Set this number to the gateway NETWORK SETUP set by your modem/router. <00:11:22:33:44:55> MAC ADDRESS [STATIC] IP ALLOCATION [192.168.1.100] IP ADDRESS [255.255.255.0] SUBNET MASK [192.168.1.1] GATEWAY [0.0.0.0] DNS1 ADDRESS [0.0.0.0] DNS2 ADDRESS HTTP PORT USER SETUP DDNS SETUP (HTTP PORT) 80, 1024-49151 )MOVE (SEL)SELECT (MENU)EXIT NOTE: To adjust the IP ADDRESS，SUBNET MASK and GATEWAY value, only when the... -
Page 19: Language
User Manual [111111] DDNS SETUP：If you require an external DDNS SETUP service to maintain a dynamic IP address enter [WWW.DynDNS.com ] DDNS PROVIDER the user information here. DDNS USER NAME DDNS PASSWORD DOMAIN NAME )MOVE (SEL)SELECT (MENU)EXIT LAN-DVR Connection See the diagram below for steps to connect your DVR to a local area network or the internet. For remote monitoring from your computer，you must have a LAN connection available or broadband Internet access. -
Page 20: Video Backup
User Manual 5.24 Video Backup This function is only available for the model which supports USB memory stick or CD-RW device backup. If your DVR is with PC-link USB interface, please refer Chapter 8 for video backup. Move the cursor to “VIEW EVENTS”, EVENT LIST press [SEL] to enter event list. -
Page 21: Reset Menu
User Manual Insert your USB memory stick device into VIDEO BACKUP DVR’s USB port. VIEW EVENTS Move the cursor to “BACKUP TO USB START: 2008/08/22 16:20:22 END: 2008/08/22 16:48:28 DEVICE”, press [SEL] button. SIZE: [197] MB FILE NAME: [VID000.MCG] BACKUP TO CD/DVD BACKUP TO USB DEVICE )MOVE (SEL)SELECT (MENU)EXIT DVR will check your USB device as left... -
Page 22: Chapter 6: Record
User Manual Chapter 6: Record Start Recording Press [●] record button to start recording according to the record schedule you have set. System will display some information on screen. ● the red pot next to the channel name indicates that the channel is being recorded. [A-REC]: indicates the current record schedule is set to NORMAL-RECORD mode. -
Page 23: Stop Recording
User Manual button to switch one of the two audio inputs to live output Stop Recording When pressing [■] stop button DVR will stop recording. If password protection function is enabled, system will prompt you to input password. Only correct password can stop recording process. -
Page 24: Driver Installation
User Manual Chapter 8: USB Progamming Driver Installation (1) Insert driver CD into your CD-ROM Drive. (2) Open CD directory. (3) Double click on the install applications. (4) Run “Install” program. (5) Follow the setup wizard to finish the installation. 8.2 Program Interface –... -
Page 25: Program Running
User Manual Program Running 8.3.1 HDD play mode System will detect the HDD automatically when you connect the USB cable to your PC. An USB icon“ ” will appear in the system tray (right bottom corner of the screen). After you’ve seen the USB icon, double click “... -
Page 26: File Play Mode
User Manual Press “ ” to play video. 8.3.2 FILE play mode Press “ ” to open a folder and select the file you want play. Double click the file. Note : This function is only used to play the backup files on USB or CD/DVD device. 8.3.3 NET play mode This mode allows you to remote control your DVR via Internet or Intranet. -
Page 27: Chapter 9: Specification
User Manual that you want remotely access and then press Login to enter the main page. Chapter 9: Specification 4 / 9-Channel DVR Items Descriptions Video Standard NTSC/PAL Video Input/Output 4 Channels/2 Channels，9 Channels/1 Channel Audio Input/Output 2 Channels/2 Channels，1 Channel/1 Channel NTSC:720X480@30fps(Each Ch) Resolution PAL:720X576@25fps(Each Ch) -
Page 28: Chapter 10: Appendix
User Manual Chapter 10: Appendix 10.1 System connection diagram 4-CH DVR (Speed dome not included) (Cameras not included) 9-CH DVR (Speed dome not included) (Cameras not included) -
Page 29: Accessories (Optional)
User Manual 10.2 Accessories (optional) Power Cord Power Adaptor User’s Manual Guarantee Card Quality Cert. CD Disk Remote Controller USB Cable Batteries for RC Screws (For PC Backup Only) - Page 30 The material in this document is the intellectual property of our department . No part of this manual be reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without noti ce.
