ST-5000
Gooseneck Microphone Combo
Thanks for choosing JTS ST-5000 Gooseneck Microphone. In order to obtain the best efficiency, you are recommended to read this manual before applying.
The ST-5000 is the easiest gooseneck mic can be found. Designed with
Push ON/Push Off switch and XLR male output it meets basic
requirements for all installed applications.
FEATURES
✜ Supercardioid pick up pattern
✜ Push ON/OFF
✜ LED indicator
✜ Balanced XLR male output
PARTS IDENTIFICATION
1. Capsule
2. Gooseneck
3. LED Indicator
4. ON / OFF Switch
5. 3P XLR-Male Connector
1
2
3
4
5
Advertisement
Summary of Contents for Gooseneck ST-5000
- Page 1 ST-5000 Gooseneck Microphone Combo Thanks for choosing JTS ST-5000 Gooseneck Microphone. In order to obtain the best efficiency, you are recommended to read this manual before applying. The ST-5000 is the easiest gooseneck mic can be found. Designed with Push ON/Push Off switch and XLR male output it meets basic requirements for all installed applications.
- Page 2 TYPE: Back Electret Condenser OUTPUT CONNECTOR: XLR-M type FREQUENCY RESPONSE: 80~18,000Hz SWITCH : Push ON/OFF POLAR PATTERN: Supercardioid GOOSENECK LENGTH: 368mm OUTPUT LEVEL(at 1,000 Hz): -60±3 dB* (1mV)*0dB=1V /μbar BASE DIMENSIONS: 96mm(W)*46mm(H)*113mm(D) IMPEDANCE: 220Ω NET WEIGHT: 541 grams MAX. SPL FOR 1％ THD: 125dB POWER SUPPLY: 12-48 VDC Phantom power CURRENT CONSUMPTION: ≤5.8mA...
