Clear Force CF1400HD Operating Manual

Electric powered high pressure washer

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

CLEARFORCE

OPERATING MANUAL

Electric Powered

High Pressure Washer

Version 3

Our Customer Service staff is ready to provide assistance. In the case of a damaged

or missing part, most replacement parts ship from our facility.

For immediate help with assembly, or for additional product information,

vist www.ForceToolsUSA.com or

email support@ForceToolsUSA.com

SAVE THIS MANUAL FOR REFERENCE

You will need this manual for safety instructions, operating procedures, and

Warranty. The original sales invoice is Warranty. The original sales invoice is required

for warranty service.

ELECTRIC POWERED

PRESSURE WASHER

QUESTIONS?

Model

CF1400HD

Table of Contents

Need help?

Do you have a question about the CF1400HD and is the answer not in the manual?

Questions and answers

Summary of Contents for Clear Force CF1400HD

Page 1: Pressure Washer
ELECTRIC POWERED PRESSURE WASHER Model CF1400HD CLEARFORCE OPERATING MANUAL Electric Powered High Pressure Washer Version 3 QUESTIONS? Our Customer Service staff is ready to provide assistance. In the case of a damaged or missing part, most replacement parts ship from our facility.
Page 2: Table Of Contents
CF1400 Operating Manual TaBLE OF CONTENTS Important safety instructions Safety features Parts and diagram list Assembly and operation instructions Using the accessories Working with detergents Taking a break Shutting down and cleaning up Winterizing and long-term storage Cleaning and maintenance Troubleshooting Technical specifications Warranty...
Page 3 IMpOrTaNT SaFETY INSTrUCTIONS with the controls. Stay alert - watch what you are doing. Do not operate this product when fatigued or under the influence of alcohol or drugs. Keep operating area clear of all people and pets. Do not stand on unstable surfaces. Do not overreach or stand on unstable support. Keep good footing and balance at all times.
Page 4 IMpOrTaNT SaFETY INSTrUCTIONS GENERAL SAFETY RULES Never operate the machine without all components properly connected to the machine (handle, gun/wand assembly, nozzle, etc.). Never operate pressure washer with broken or missing parts. Check equipment regularly and repair or replace worn or damaged parts immediately. Never put hand or fingers over the nozzle or spray tip while operating the unit.
Page 5: Safety Features
IMpOrTaNT SaFETY INSTrUCTIONS Warning Connect directly to outlet. Extension cords are not recommended, the use of an extension cord will override the GFCI built into the plug of the power supply cord resulting in the risk of electrical shock. DOUBLE-INSULATION INSTRUCTION In a double-insulation product, two systems of insulation are provided instead of grounding.
Page 6 SaFETY FEaTUrES EXTENSION CORDS If possible, do not use extension cords with this product. However, if you must use one, observe all of the warnings and instructions listed below: Warning Extension cords are not recommended unless they are plugged into a ground fault circuit-interrupter (GFCI) found in circuit boxes or protected receptacles.
Page 7: Parts And Diagram List
parTS aND DIagraM LIST PARTS AND DIAGRAM LIST Item No. Quantity Part Name Adjustable wand Spray gun High-pressure hose Water filter Upper handle Detergent tank assembly Lower handle Hose bracket Gun holder Power cord bracket Needle (for nozzle cleaning) * Water filter come pre-attached on the water inlet, located on the front of the pressure washer.
Page 8: Assembly And Operation Instructions
aSSEMBLY aND OpEraTION INSTrUCTIONS Surface Preparation Before starting any cleaning task, it is important to inspect the area for objects that could create a hazard. Remove any objects from the work area that could be tripped over, such as toys or outdoor furniture. Ensure that all doors and windows are closed tightly. Water Supply (Cold Water Only) Only draw water through the unit.
Page 9 aSSEMBLY aND OpEraTION INSTrUCTIONS Connect detergent suction tube to the Attach high pressure hose to the tank. Insert the tank into the recesses machine’s water outlet (hand tighten and push forward until it locks in. only) Attach high pressure hose to the Insert adjustable wand to the gun and spray gun (hand tighten only).
Page 10 aSSEMBLY aND OpEraTION INSTrUCTIONS OFF(O) ON(I) To allow air to escape from the hose, Turn switch to ON position. Note: If depress the trigger on the gun until no sound is heard this is normal, fol- there is a steady stream of water. low the instruction manual for proper operation.
Page 11: Using The Accessories
aSSEMBLY aND OpEraTION INSTrUCTIONS USING THE ACCESSORIES Adjustable Spray Nozzle The adjustable spray nozzle can be adjusted from fan to jet. The spray is adjusted from jet to fan spray by turning the nozzle. CaUTiOn Jet spray adjustment is very strong. Do not adjust while spraying. WORKING WITH DETERGENTS Working with detergent ensures a quick soaking of the dirt, and allows the high-pressure water to penetrate and remove the dirt more effectively.
Page 12 aSSEMBLY aND OpEraTION INSTrUCTIONS Engage gun safety lock. Set the adjustable wand to the low- pressure setting by pulling the nozzle out. The wand must be set in the low- pressure position to apply detergent. Gently pull detergent container out of storage position, and fill with detergent. Push container back into storage position.
Page 13: Taking A Break
aSSEMBLY aND OpEraTION INSTrUCTIONS CaUTiOn Damage may occur to painted surface if chemical is allowed to dry on surface. Wash and rinse a small section at a time. Avoid working on hot surfaces or in direct sunlight. TAKING A BREAK If taking a break of five minutes or more: Engage gun safety lock.
Page 14: Winterizing And Long-Term Storage
WINTErIZINg aND LONg-TErM STOragE OPTIMUM WINTERIZING PROCEDURE Winterizing your pressure washer will help protect and prolong its life. We strongly recom- mend you follow the below steps using *Pressure Washer Pump Saver. This will keep the internal parts lubricated, protected from rust, and prevents the pump from freezing.
Page 15: Cleaning And Maintenance
CLEaNINg aND MaINTENaNCE Connections Connections on pressure washer hoses, gun and spray wand should be cleaned regularly and lubricated with non-water soluble grease. Tip of the wand only Clogging tip of the wand causes the pump pressure to be too high and cleaning is immediately required.
Page 16: Troubleshooting
TrOUBLE SHOOTINg Disconnect the machine from the power source before making any repairs. Symptom Cause Solution Motor does not run On/Off switch is in the Turn switch to the “ON” ( I “OFF” (O) position. ) position. when “ON”, fully con- nected and trigger GFCI is not plugged in.
Page 17 TrOUBLE SHOOTINg Symptom Cause Solution Output pressure varies Turn water on fully. Check Not enough inlet water garden hose for kinks, high and low. supply. leaks or blockage. Check that hoses and fit- tings are airtight. Turn “OFF” machine, and purge Pump is sucking air.
Page 18 TrOUBLE SHOOTINg Symptom Cause Solution Garden hose connection Loose fittings. Tighten fittings. leaks. Missing / worn rubber Insert new washer. washer. Spray wand, extension, Broken o-ring or plastic insert. Call the Toll-Free Hotline. or nozzle leaks. Pump is noisy. Check that hoses and fittings are airtight.
Page 19: Technical Specifications
TrOUBLE SHOOTINg Symptom Cause Solution Motor buzzes but fails Pressure washer not used Call the Toll-Free Hotline. for long periods. to run. (continued) Disconnect water supply Residual friction among and power ON for 2 to 3 components. Unit might seconds, repeat couple hum.
Page 20: Warranty
2. Send in proof-of-purchase and serial number (if applicable) to conﬁrm warranty coverage. 3. If service or a warranty evaluation is requested, Clear Force USA will provide an RGA number that should be used in all communications with Clear Force USA and is required to be indicated on the product itself and on the outside of the box.
