MINI Scooter E Concept

Owner's Manual and Assembly Instructions

Model #: 5F62B5D

Read and understand the entire manual before assembly and operation. The vehicle must be

assembled by an adult who has read and understands the instructions.

Made in China.

Styles and colors may vary. Do not return to store. Call 1-888-982-9309 for assistance and

replacement parts.

IMPORTANT:

Save this manual with your sales receipt.

MINI Scooter E Concept, electric ride-on vehicles manufactured by Paragon Child Products Co., Ltd. (Goodbaby Group). The MINI

trademarks are used under license from BMW AG/ MINI name and associated logos are trademarks of BMW AG.

Table of Contents

Need help?

Do you have a question about the Mini E Concept and is the answer not in the manual?

Questions and answers

Summary of Contents for Avigo Mini E Concept

Page 1 MINI Scooter E Concept Owner’s Manual and Assembly Instructions Model #: 5F62B5D Read and understand the entire manual before assembly and operation. The vehicle must be assembled by an adult who has read and understands the instructions. Made in China. Styles and colors may vary.
Page 2: Specifications
Introduction Thank you for purchasing this vehicle from Aria Child. We hope the rider enjoys it for miles to come. Please read this instruction guide carefully before assembling and operating the vehicle. Please have your model number and serial number ready before calling. Please have proof of purchase.
Page 3 IMPORTANT! YOU MUST CHARGE THE BATTERY FOR 24 HOURS BEFORE FIRST USE! Charge the battery after each use. Charge the battery at least once a month, even if the vehicle is not in use. DO NOT RETURN THIS ITEM TO THE STORE! Contact Customer Service if you need assistance or replacement parts.
Page 4: Table Of Contents
Table of Contents Safety ............5 Parts ............7 Charging Instructions .......8 Assemble the Front Wheel ......9 Install the Handle Bars ......10 Attach the Mirrors ........11 Install the Support Wheels......12 Battery and Seat Attachment ....13 Operating Instructions ......14 Maintenance ..........15 General Care ..........16 Troubleshooting Guide ......17 FCC Information ........19 Service and Repairs .......20...
Page 5: Safety
Safety WARNING: SAFETY RIDING RULES PREVENT INJURIES AND DEATHS: NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when child is in vehicle. Direct adult supervision is REQUIRED. NEVER use on roadways, near cars, on or near steep inclines or steps, swimming pools or other bodies of water.
Page 6 Safety (Continued) WARNING: BATTERY SAFETY • Battery posts, terminals and related accessories contain lead and lead compound (asic) chemicals known to the state of California to cause cancer, reproductive harm, and are toxic and corrosive. DO NOT open the battery. •...
Page 7: Parts
Parts 1. Manual 9. Left Support Wheels Not Included: 2. Battery 10. Right Support Wheels 3. Charger 11. Long Screw 4. Front Mudguard 12. Nut 5. Front Wheel Assembly 13. Flat Washers (2) 6. Side Mirrors (2) 14. Spring Washers (2) 7.
Page 8: Charging Instructions
Charging Instructions YOU MUST CHARGE THE BATTERY FOR 24 HOURS BEFORE THE FIRST USE! ONLY AN ADULT SHOULD HANDLE THE BATTERY AND CHARGER. Charge the Battery: 1. Ensure the vehicle is stopped and turned off. 2. Open the fuel tank and gently remove the wires.
Page 9: Assemble The Front Wheel
Assemble the Front Wheel 1. Insert the front wheel assembly (5) into the front of the scooter body (8).
Page 10: Install The Handle Bars
Install the Handle Bars 1. Securely connect the three connectors from the vehicle body to the three connectors on the handlebars. Ensure all of the wires are placed inside of the scooter body. 2. Remove the screw (11) and the nut (12) from the handle bars (7) before attaching.
Page 11: Attach The Mirrors
Attach the Mirrors 1. Attach the left and right mirrors (6) to the handle bars (7). A click ensures they are securely attached.
Page 12: Install The Support Wheels
Install the Support Wheels 1. Align the left and right support wheels with the square bracket on the bottom of the scooter on both sides accordingly. 2. Slide 1 thin washer (14) and 1 thick washer (13) on the short screw (15). 3.
Page 13: Battery And Seat Attachment
Battery and Seat Attachment 1. Open the fuel tank door and gently take out the two red battery connector wires. Do not remove them using force. 2. Connect the two red battery connectors. 3. Replace the connectors inside the scooter body and close the fuel tank door.
Page 14: Operating Instructions
Operating Instructions Power Button Left Right Button Button 1. To turn on the scooter, press the Power Button on the center of the handle bars. The engine start sound plays and the handle bars light up. 2. To move the scooter forward, twist the right handle bar toward the rider.
Page 15: Maintenance
Maintenance Important Battery and Charger Information • Only an adult who has read and understands the safety warnings may handle and operate the battery and battery charger. Keep away from children. • Charge the battery for 24 hours before using the vehicle for the first time.
Page 16: General Care
General Care • Regularly inspect all vehicle parts to ensure they are in good working condition. • Regularly inspect the charger, cord, plug, and other related parts for damage. • Remove any damaged parts and immediately contact Customer Service for replacement parts. See Service and Repairs on Page 19 for more information.
Page 17: Troubleshooting Guide
Troubleshooting Guide Completely read through the manual and troubleshooting guide before contacting Customer Service. Problem Potential Cause Solution Vehicle does not run Battery is low Recharge the battery Thermal fuse tripped This product uses a recoverable fuse which will automatically cut power to the vehicle if the current is overflowed.
Page 18 Problem Potential Cause Solution Vehicle needs a push to Loose wires or loose Ensure the battery connectors start connectors are securely attached. If wires are loose, contact Consumer Service for repairs “Dead spot” on motor A “dead spot” means electricity is not being delivered to the terminal.
Page 19: Fcc Information
FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 20: Service And Repairs
Service and Repairs Do not return this vehicle to the store. If your product requires service, repairs or replacement parts, please contact Aria Child Customer Service. Hours: 9 AM - 5 PM (CST), Monday - Friday 888-982-9309 Phone: 1- Email: customerservice@ariachild.com Web: www.ariachild.com For a list of available replacement parts, please visit www.ariachild.com.
Page 21: Warranty
Warranty Aria Child 6-Volt Limited Warranty • One-year limited warranty from the date of purchase with proof of purchase from • Six month limited warranty on the 6-Volt battery with proof of purchase from an • This one-year limited warranty covers the ride-on vehicle against defects in materials and workmanship to the original purchaser.
Page 23: Product Registration
Product Registration Fill out the form below and mail it to: Aria Child 1131 W. Blackhawk St. Second Floor Chicago, IL 60642 www.ariachild.com We will use the information provided only for your warranty. We will not sell, rent or share your personal information. Product Registration First Name: Last Name:...
