Wood stove
EN 13240
Model : 134 05 01
Technical manual
Output : 5 kW
to be saved
by the user
for future reference
Description of the appliance
Installation instructions
Parc d'activités de la Verte Rue
Operating instructions
Allée des Prêles
59270 BAILLEUL
Spare parts
Tél. : 03 28 40 32 50
Warranty certificate
Advertisement
Table of Contents
Summary of Contents for Franco Belges MONTFORT 134 05 01
-
Page 1: Wood Stove
MONTFORT Document n° 1171- ~ 20/02/2013 FR EN NL Wood stove EN 13240 Model : 134 05 01 Technical manual Output : 5 kW to be saved by the user for future reference Description of the appliance Installation instructions Parc d’activités de la Verte Rue Operating instructions Allée des Prêles 59270 BAILLEUL... -
Page 2: Table Of Contents
“MONTFORT” - ref. 134 05 01 FRANCO BELGE congratulates you on your choice. FRANCO BELGE, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 80-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products. -
Page 3: Description Of The Unit
“MONTFORT” - ref. 134 05 01 Description of the unit This appliance is meant to burn wood or solid fuel safely WARNING Incorrectly installed, this appliance can be dangerous and possibly cause serious accidents. We recommend that you engage the services of a professional engineer for its installation and the regular maintenance requirements 1. -
Page 4: Installation Instructions
“MONTFORT” - ref. 134 05 01 Installation instructions 2. Installation instructions 2.1. Warning to the user All the local and national regulations, and in particular those relating to national and 1 5 0 European standards, must be observed when installing the appliance. -
Page 5: Assembly Of Flue Collar
“MONTFORT” - ref. 134 05 01 Installation instructions The chimney must be at least 4.5 m (15 ft high). In case of a flat roof or when the roof gradient is lower than 15°, the stack must be 1,2 m (4 feet) high at least. - If the chimney has any down draught tendency, due to its position in relation to nearby obstacles, then an anti-down draught cowl must be installed on the... -
Page 6: Chimney Connector
“MONTFORT” - ref. 134 05 01 Installation instructions 2.5. Chimney connector - The connection to flue must be carried out according to local building regulations. - The appliance must be installed as close as possible to the chimney. - The connector pipe must be approved for installation with combustion products (either 24 ga. -
Page 7: Instructions For User
“MONTFORT” - ref. 134 05 01 Instructions for user 3. Instructions for user The manufacturer will not be responsible for damages Note : It is recommended to use a fireguard in the presence of children, and also in the presence of old on parts of the appliance due to the use of prohibited and/or infirm people. -
Page 8: Instructions For Use With Wood
“MONTFORT” - ref. 134 05 01 Instructions for user Figure 8 - Removing the fuel retainer 3.2. Instructions for use with wood 3.2.1. Lighting (figure 7) • Slide the secondary air inlet (# B1) to the right. Open the primary air inlet (# C1). •... -
Page 9: Cleaning
“MONTFORT” - ref. 134 05 01 Instructions for user 3.4. Cleaning • Remove all deposits from the combustion chamber and clean the grate area. It is essential to keep the grate free from a heavy build • Cleaning of the glass door can be done with a soft cloth up of ashes. -
Page 10: Trouble Shooting
“MONTFORT” - ref. 134 05 01 Instructions for user 3.9. Trouble Shooting þ : This sign means that you should asked for a qualified engineer to do the work. Problem Probable causes Action Fire difficult to start. Fire goes Wood green… or too damp Use hard wood logs, which have been cut for at least out. -
Page 11: Spare Parts
“MONTFORT” - ref. 134 05 01 Spare parts 4. Spare parts When ordering spare parts, specify the stove type and serial number, including the colour index (on the guarantee or identification plate), the name of the part and the part number. Example : Wood stove “MONTFORT”, ref. - Page 12 “MONTFORT” - ref. 134 05 01 Spare parts Figure 10 - Stove - exploded view Technical manual “1171”...
- Page 13 “MONTFORT” - ref. 134 05 01 Spare parts N° Code ..Designation ..Type ..A . . . B . . . C . . . D . . . E . . . F . . . G . . Qty 27 303860 MK .
- Page 14 Guarantee certificate our “Guarantee Inspection” Department. Carriage and Legal guarantee labour is at the user’s cost. Moreover, if the repair or The specifications, dimensions and information shown replacement of parts covered by the guarantee is found on our documents are provided for information purposes to be too costly vis-à-vis the price of the appliance, the only and under no circumstances are binding upon the decision to replace or repair the appliance will be taken...
