Summary of Contents for Lectronics LongRanger4
- Page 1 Portable Wireless Sound System L o n g R a n g e r FAST CHARGE PORTABLE WIRELESS SOUND SYSTEM OPERATING INSTRUCTIONS and trouble-shooting guide LECTROSONICS, INC. Rio Rancho, NM, USA Rio Rancho, NM – USA...
-
Page 2: Table Of Contents
Long Ranger 4 INTRODUCTION Thank you for selecting the Long Ranger portable wireless sound system. This unique design combines a rechargeable power supply, a high-power amplifier and loudspeaker, and high quality VHF wireless microphone into a single compact assembly. The design has evolved with numerous refinements since its first prede- cessor was introduced in the early 1980’s to serve public address applications indoors and outdoors, with the ruggedness and reliability needed for professional use. -
Page 3: General Technical Description
Portable Wireless Sound System GENERAL TECHNICAL DESCRIPTION The standard Long Ranger Portable Wireless Sound System consists of a combination wireless receiver/amplifier/ speaker with a rechargeable battery pack, a belt-pack or plug-on transmitter and a microphone. Optional micro- phones, extension speakers and add-on equipment for a second wireless channel are available. The Long Ranger features a VHF wireless microphone system with a transmitter-to-receiver operating range of up to 750 feet. -
Page 4: Controls And Functions
Long Ranger 4 CONTROLS AND FUNCTIONS CONTROL PANEL WIRELESS MICROPHONE VOLUME Turns unit power on and off and also functions as the volume control for the internal wireless receiver. POWER A red LED that lights when unit power is on. A green LED that lights when the companion transmitter is turned on and there is sufficient signal for good system operation. -
Page 5: Front Panel
Portable Wireless Sound System FRONT PANEL 12V DC EXT POWER A special jack used to connect an external 12 Volt DC source to the unit to substitute for the “on-board” battery pack. It is most commonly used for connecting the Long Ranger to a vehicle cigarette lighter or 12V DC auxiliary recep- tacle. -
Page 6: System Setup Rules
Long Ranger 4 SYSTEM SETUP RULES This section includes some basic rules that will ensure trouble-free operation of your Long Ranger system: 1) Make sure the transmitter battery is good, or better yet, new. 2) Charge up the battery pack in the Long Ranger fully before you use the system. Charge until the green charging lamp underneath the CHARGER jack on the Long Ranger control panel goes out. - Page 7 Portable Wireless Sound System 8) A small screwdriver is supplied with the transmitter. The screwdriver is used to adjust the audio gain of the transmitter to match your microphone and your voice. The adjustment is made while observing the MOD LEVEL lamps on the Long Ranger control panel: a) Speak at the voice level you will be using during actual operation.
-
Page 8: Using Additional Speakers
Long Ranger 4 USING ADDITIONAL SPEAKERS CAUTION! ALWAYS TURN THE LONG RANGER POWER OFF BEFORE PLUGGING IN OR UNPLUGGING EXTERNAL SPEAKERS In some cases, the proper coverage of an audience requires a second speaker. The optional H300 is identical to the Long Ranger speaker and can be used to spread the sound over a broader area. -
Page 9: Adding A Second Wireless Channel To Your Long Ranger
Portable Wireless Sound System ADDING A SECOND WIRELESS CHANNEL TO YOUR LONG RANGER A very popular feature of the Long Ranger is the ability to add a second wireless channel to an existing system in the field. The Lectrosonics Add-On Receiver system was expressly designed for that purpose. The standard system consists of an Add-On receiver, an M175 transmitter and a microphone. -
Page 10: Initial Adjustments To The Add-On Receiver System
Long Ranger 4 INITIAL ADJUSTMENTS TO THE ADD-ON RECEIVER SYSTEM 1) Set up the Long Ranger system according to the Initial Equipment Adjustments on page 6. 2) Leave the Long Ranger power turned on. Set both volume controls on the Long Ranger control panel to mini- mum. -
Page 11: Multiple Long Ranger Systems
Portable Wireless Sound System MULTIPLE LONG RANGER SYSTEMS A unique use of the AUX IN/OUT jack is for connecting two Long Ranger systems together for simultaneous use. When connected in this manner, they will operate like a single system. It is best to use two different Long Ranger units that operate on different frequencies. -
Page 12: Microphone Choices
Long Ranger 4 MICROPHONE CHOICES M119 - This is a very small, omni-directional mic used only as a lavalier (“lapel”) microphone. It may be prone to feedback since it is usually placed so far away from the users mouth; however it has a very flat response and excel- lent tone quality. -
Page 13: Accessories And Replacement Parts
Portable Wireless Sound System ACCESSORIES AND REPLACEMENT PARTS DCR15/2AU Battery Charger Replacement HM142V Single headband With locking micro plug for M175 series transmitters. HM152V Double Headband Double adjustable headband. With micro plug Headset Microphone for M175 series transmitters. HM162 “Over ears” Headset A comfortable headworn design that places the microphone pickup element close to the mouth, using a dual-element, noise cancelling technique to minimize feedback. -
Page 14: Troubleshooting
Long Ranger 4 TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE Long Ranger red POWER lamp not on 1) WIRELESS MICROPHONE VOLUME or dim control in OFF position 2) Batteries completely discharged 4) Battery terminals disconnected or loose Long Ranger green RF lamp not on 1) Transmitter not on 2) Dead battery in transmitter 3) Transmitter and receiver not on same frequency... -
Page 15: Service And Repair
Portable Wireless Sound System SERVICE AND REPAIR If your system malfunctions, you should attempt to correct or isolate the trouble before concluding that the equip- ment needs repair. Make sure you have followed the setup procedure and operating instructions. Check out the interconnecting cords and then go through the TROUBLE SHOOTING section in the manual We strongly recommend that you do not try to repair the equipment yourself and do not have the local repair shop attempt anything other than the simplest repair. -
Page 16: Warranty
LIMITED ONE YEAR WARRANTY LIMITED ONE YEAR WARRANTY The equipment is warranted for one year from date of purchase against defects in materials or workmanship provided it was purchased from an authorized dealer. This warranty does not cover equipment which has been abused or damaged by careless handling or shipping.
