Summary of Contents for 4x4Tough 15-50222
- Page 1 jump starter with compressor USER GUIDE Version 2 June, 2015...
-
Page 2: Table Of Contents
Contents Page FEATURES ................................3 IMPORTANT ................................ 3 OVERVIEW ................................3 IMPORTANT SAFEGUARDS ..........................4 CHARGING YOUR JUMP STARTER ....................... 4 CHARGING WITH AC ADAPTOR ........................5 CHARGING WITH DC ADAPTOR ........................5 BUILT IN SOLAR PANEL - BATTERY TRICKLE CHARGER................. 5 JUMP STARTING .............................. -
Page 3: Features
FEATURES • 900 AMP Peak / 400 AMP Crank Jump Starter • USB Power Port • Built In Solar Panel - Battery Trickle Charger • 3 X LED Work Lights • 260 PSI Air Compressor • 2 X Detatchable LED Torches •... -
Page 4: Important Safeguards
IMPORTANT SAFEGUARDS • To protect against electrical hazards or shock, do not immerse charger, adaptors, or unit in water or other liquid. • Close supervision is necessary when used near children. • Do not use unit for applications other than its intended use. •... -
Page 5: Charging With Ac Adaptor
CHARGING WITH AC ADAPTOR Use a standard 240 volt AC power outlet to charge the jump starter. Only use the charger provided with the unit. Keep the power on/off switch in the OFF position whilst charging. Plug the AC charger into a standard 240 volt AC POWER outlet and the input plug into the jump starters charging jack. -
Page 6: Using The Air Compressor
If the jump starter LED light is green this indicates battery polarity connection is correct. WARNING: If the jump starter LED light is red and an alarm sounds this indicates reverse battery polarity which is incorrect. STOP! Carefully disconnect the jump starter clamps. Reconnect the jump starter clamps correctly. -
Page 7: Detachable Torches
2 x DETACHABLE TORCHES To detach the torches, slide in an upward motion from the front of the jump starter (see figure A). Turn the battery cover at the end of the torch anti-clockwise to “open” and fit it with 3 x AAA sized battery and turn clockwise to close the cover (6 x AAA sized batteries are required for 2 x Figure A torches). -
Page 8: Warranty Details
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint. Please telephone us on 1300 883 104 or write to us at: Natural Product Solutions Pty Ltd Unit 3 60 Box Road, TAREN POINT 2229 Telephone: 1300 883 104 Email: sales@4x4tough.com.au Website: www.4x4tough.com.au...
