Summary of Contents for Advance Appliance SFUTS 210
- Page 1 ISSU 5 0914 advance ances INST LL TION USER GUIDE DV NCE UNIVERS L MULTI-FUEL THERM L STORE DV NCE PPLI NCES LTD PLE SE RET IN ND ENSURE SERVICE RECORDS RE KEPT UP TO D TE.
- Page 2 SCHEMATIC DIAGRAM OF UNIVERSAL THERMAL STORE F&E T NK (IF VENTED) RELIEF V LVE (SE LED SYSTEM) TOP SENSOR POCKET BOILER FLOW 28MM FOR SOL R THERM L S FETY NON DJUST BLE HIGH V LVE (SE LED LIMIT THERMOST T SYSTEM) BLENDING V LVE/ DHW OUT...
-
Page 3: Operation
INTRODUCTION The Advance Universal Thermal Store linking system is a major step forward in the design and operation of thermal store systems, allowing for a number of heat inputs to work together for a fully flexible vented or sealed central heating and mains pressure hot water system. OPERATION Traditional boilers can be used to heat the thermal store (or heat bank as it is sometimes called). - Page 4 The immersion heaters should not be required during the solar season, although the top one can be wired to a switched spur for any essential top up. The immersion heaters should be set at 75°C. Note:The immersion heater supplied is fitted with a thermal cut out.This is an essential safety requirement,and immersion heaters without thermal cut outs must not be used.
- Page 5 SFUTS FULLY WIRED AND PLUMBED FOR SOLID FUEL WITH GAS/OIL BOILER ETC The SFUTS (Solid Fuel Universal Thermal Store) takes the worry out of installation. It offers a fully integrated store with all relevant controls and safety features. It has three pumps fitted - a boiler pump, a heating pump and a re-circulator for the solid fuel device to aid heat up and stratification when the appliance is first lit.
-
Page 6: Installation
SCHEMATIC WITH LOOP Heat sink Store Wood burner Note: In the above case the wood burner must have a quench pipe system to protect against overheating INSTALLATION Ensure the unit is installed on a flat surface and that all tappings are accessible for future maintenance. -
Page 7: Hot Water
The SFUTS version is pre-wired and pre-plumbed and is simple to install. See page 5 for a description of this. Follow the layouts carefully, the pumped solid fuel pipe-set is assembled and supplied packed with SFUTS. It should be attached to the store. If this is not possible it should be less than one metre from the store. -
Page 8: Warranty
NOTE: Mains pressures usually increase from late evening to early morning. SIZE & WEIGHT EXPANSION VESSEL MODEL CAPACITY WEIGHT FULL Kg SIZE (CYLINDER ONLY)* HGT X DIA SFUTS 210 210 ltrs 18 ltrs 1500 x 600 SFUTS 250 250 ltrs 24 ltrs 1750 x 600... -
Page 9: Technical Specification
TECHNICAL SPECIFICATION MAX COLD WATER PRESSURE 3 BAR MAX TANK OPERATING PRESSURE 3 BAR MIN OPERATING TEMPERATURE 75 DEGREES IMMERSION HEATERS 3KW / 230V AC 1 " x 14" SHOCK ARRESTOR POTABLE 2 LITRE 3 BAR HEAT EXCHANGER HOT WATER 35KW HEAT EXCHANGER SOLAR 17KW... - Page 10 INSTALLER & COMMISSIONING ENGINEER DETAILS Customer Details Servicing Requirements 1. Check pressure reducing valve Name ................(if fitted) is 3.0 bar static and adjust Address if necessary................ 2. Check flow rates are correct at 18 litres ....................per minute. Clean filter in pressure Tel No.
- Page 11 SERVICE INTERVAL RECORD Service regularly by an approved engineer and record details below Date Date SERVICE 1 SERVICE 2 Engineers Name Engineers Name ..........................Company Name Company Name ..........................Tel No................................... ID Serial ID Serial No..............
- Page 12 advance ances UNIT 4 COPPICE SIDE IND EST BROWNHILLS WALSALL WS8 7EX TEL 01543 377723...
