HSS Hire C8 Operating & Safety Manual

Bolens Horse
Fuel Tap
Choke
Lever
Tine Selection
Lever
Tine
cultivator will move forward. If you release the OPL when
the drive lever is engaged, the engine will STOP .
To change gear, disengage the drive, and set the
throttle to idle. Select the required gear and prepare to
move off as already described.
To STOP in an emergency, release the OPL.
To engage the tines, disengage the drive, and set the
throttle to idle. Select tine drive by moving the tine selection
lever back (to the right if viewed from the side).
NOTE, this machine does not have a reverse gear.
All Models...
Stone Alert
Keep a constant look lookout or large stones, bits of
wood, wire or rubble. Running into debris could
damage the equipment and cause personal injury.
If the soil is naturally stony, ask our shop staff for
advice.
Drive to the start of the strip to be cultivated then
engage the tines. Keep clear of the rear flap, and never use
Throttle
Pull Start
Disengage
Drive
Lever
Engage
Gear
Selection
Lever
Slow
Depth
Adjuster
the machine with it raised. Earth and stones may be thrown
back at dangerous speeds.
At the end of a strip, disengage the tines and turn the
cultivator round for the next strip.
For deep cultivation first dig the plot over to a depth of
about 75mm, then repeat gradually increasing the
depth.
EQUIPMENT CARE
Never push the equipment beyond its design limits. If it
will not do what you want with reasonable ease and speed,
assume you have the wrong tool for the job. Contact your
local HSS Hire Shop for advice.
Keep the equipment clean - you will find this less of a chore
if you clean it regularly, rather than wait until the end of the
hire period.
Regularly check the fuel level and top up as necessary
with unleaded petrol.
Regularly check the oil level - when the engine is cold and
on level ground. Withdraw the dipstick, wipe it clean, then
replace it, remove it a second time and verify that the oil level
is between the min and max lines, top up as necessary.
Suitable oils are available on sale or return from your local HSS
Hire Shop.
Keep the engine upright. If it should tip over, mop up any
spilled oil and fuel and contact your nearest HSS Hire Shop
before restarting.
Watch for oil leaks as they may indicate a cracked crankcase,
so switch OFF immediately and contact your local HSS Hire
Shop.
When not in use, store the equipment somewhere clean,
Operator
dry and safe from thieves.
Presence Lever
FINISHING OFF
Select neutral gear, disengage the tines and release the
OPL and set the throttle to idle. Close off the fuel tap.
Hose the equipment down to get it as clean as possible
ready for return, to your local HSS Hire Shop.
Operator
Presence Lever
Fast
...any comments?
If you have any suggestions to enable us to improve
the information within this guide please fax your
comments or write to the Product Manager at the
Fax: 020 8687 5001
©HSS Hire Service Group Plc 2003 No. 571/02
Group Office: 25 Willow Lane, Mitcham, Surrey CR4 4TS
Web Site: http://www.hss.com
Operating & Safety Guide 571
Petrol driven cultivators for preparation
of ground prior to sowing or planting
address below
Cultivator
Code 62526
