Solid Apollo SA-CTRL-InWallRGB-Black Product Manual

Glass touch rgb controller 12v-24v
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT MANUAL
Glass Touch RGB Controller 12V-24V

Product Description

Solid Apollo's Glass Touch In-Wall RGB controllers are an easy and sophisticated way to control lights in
one room or space. The Glass Touch In-Wall RGB controllers run on 12-24V power and supply 12-24V
Color Changing RGB LED lights and can be mounted in walls with any American electrical gang/screw
boxes. You can easily turn on your lights, quickly choose a color, cycle through 20 present colors and 19
color changing programs, as well as controlling program speed and full dimming functionality. The Glass
Touch In-Wall RGB controllers also have sound indication, meaning when you press a key, an slight beep
is emitted to confirm the change.
Main Functions
• Mountable in an American Wall Electrical Gang Box
• Mountable in Walls or surfaces to control LED RGB Color Changing
• Turn on and Off your 12-24V LED Light Fixtures at the touch off a button
• Quick Dimming Control with Glide Dimmer
• Program Speed Control using Glide Dimmer when program running
• Precise Color Selection with Color Wheel
• 19 Color Changing Modes
• 20 Different Static Color Options
• Sound/Touch Recognition to confirm button selection.
This Manual will review
• T he entire Installation Process
• P roduct Features and Primary Uses
• D etailed Functionality
• T echnical Parameters
SA-CTRL-InWallRGB-Black
SA-CTRL-InWallRGB-White
™
Toll Free. 866-592-3873
www.SolidApollo.com
sales@SolidApollo.com
page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-CTRL-InWallRGB-Black and is the answer not in the manual?

Questions and answers

Summary of Contents for Solid Apollo SA-CTRL-InWallRGB-Black

  • Page 1: Product Description

    Product Description Solid Apollo’s Glass Touch In-Wall RGB controllers are an easy and sophisticated way to control lights in one room or space. The Glass Touch In-Wall RGB controllers run on 12-24V power and supply 12-24V Color Changing RGB LED lights and can be mounted in walls with any American electrical gang/screw boxes.

  • Page 2: Installation & Wiring

    Installation: Wiring Solid Apollo’s Glass Touch In-Wall RGB Controllers are meant to be housed inside a wall. They conveniently fit inside of any American Electrical gang box. To securely install, you will have to first carefully wire your controller through your gang box (not included) in order to test your lights with both your power and RGB LEDs, and then be able to put it nicely into your gang box.

  • Page 3: Terms To Know

    ™ PRODUCT MANUAL Glass Touch RGB Controller 12V-24V Toll Free. 866-592-3873 www.SolidApollo.com sales@SolidApollo.com Installation: Separating the Backplate and Faceplate Now that you have wired your controller, and tested it to ensure it is working with your current wiring, you can begin to take off the faceplate. This is so you are able to mount the backplate (which has the two screwholes) to any American Gang Box (not included).
  • Page 4 ™ PRODUCT MANUAL Glass Touch RGB Controller 12V-24V Toll Free. 866-592-3873 www.SolidApollo.com sales@SolidApollo.com Installation: Putting your controller in the Gang Box After removing the faceplate, you can now mount your controller with two screws inside an American Gang/Switch Box (screws not included) and place that entire unit in the wall.
  • Page 5 ™ PRODUCT MANUAL Glass Touch RGB Controller 12V-24V Toll Free. 866-592-3873 www.SolidApollo.com sales@SolidApollo.com Installation: Putting your controller back together. You can now put back on your controller’s faceplate, completing the installation. 5. Follow Diagram2 below to begin wiring your controller. Your gang box should be secured in the wall at this time, with your controller backplate screwed into, and your wiring connections secured within the gang box.

  • Page 6: Basic Functionality

    ™ PRODUCT MANUAL Glass Touch RGB Controller 12V-24V Toll Free. 866-592-3873 www.SolidApollo.com sales@SolidApollo.com Basic Functionality Color Wheel Power On/Off Sound Control Smooth Glide Dimmer/ Program Speed Control Static Program Color Selection Selection SA-CTRL-InWallRGB-Black Figure 1 page 6...

  • Page 7: Advanced Functionality

    ™ PRODUCT MANUAL Glass Touch RGB Controller 12V-24V Toll Free. 866-592-3873 www.SolidApollo.com sales@SolidApollo.com Advanced Functionality Power Button and Sound Control: Your controller’s main button which turns your 12V-24V DC RGB LED lights on and off as well as enabling and disabling the sound indications for your controller.
  • Page 8 ™ PRODUCT MANUAL Glass Touch RGB Controller 12V-24V Toll Free. 866-592-3873 www.SolidApollo.com sales@SolidApollo.com Advanced Functionality Glide Dimmer and Speed Button: To dim your RGB LED lights, or to control a program speed, you will use the Glide Dimmer and Speed Adjust- ment button pictured below.

  • Page 9: Technical Details

    • 4 amps max per channel • 192W max @ 24V • 96W max @ 12V • Dimensions: 4.75” x 2.78” x 1.75” 1.63” 4.75” 2.75” .5” 1.28” 2.88” .5” 2.75” Product Dimensions Glass Touch In-Wall Controllers Solid Apollo LED 1.28” page 9...

This manual is also suitable for:

Sa-ctrl-inwallrgb-white
