Electric Underfloor Heating
INSTALLATION MANUAL
Mat
w
w
w
100
/150
/200
LIFETIME
WARRANTY
Before you begin installing, read through these instructions
carefully and check that you have all the components required.
www.smartmat.co.uk
01473 559077
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mat 100W and is the answer not in the manual?

Questions and answers

Summary of Contents for SmartMat Mat 100W

  • Page 1 Electric Underfloor Heating INSTALLATION MANUAL /150 /200 LIFETIME WARRANTY Before you begin installing, read through these instructions carefully and check that you have all the components required. www.smartmat.co.uk 01473 559077...
  • Page 2 • Use flexible tile adhesives and grouting materials. • Ensure the floor sensor thermostat is inserted within The SmartMat underfloor heating mat has a self- the flexible tube provided and installed between two adhesive fibre glass backing mesh with an ultra-thin...

  • Page 3: Electrical Requirements

    01473 559077. When designing your electrical installation, you should always consult an electrician regarding It is a requirement that all SmartMat systems are your requirements. protected by a 30ma RCD earth trip either at the consumer unit or by a combined RCD spur outlet.

  • Page 4: Installation Instructions

    Installation Instructions 100 watt/150 watt/200 watt Ensure your SmartMat is correctly sized before you unpack the product. Call 01473 559077 if you have any questions. Step 2 Note Directly below the electrical connection point install The floor should now be prepared ready for the a 10mm flexible tube (provided with each SmartMat) SmartMat installation.
  • Page 5 Check the resistance of the mat again (see Register your warranty online at: page 7 for details) to make sure damage www.smartmat.co.uk/warranty hasn’t occurred during the installation process.
  • Page 6 (power cables) are returned to the thermostat power connection and are wired in parallel, never wire your SmartMat in series, Layout of rst mat and always check your SmartMat is thoroughly adhered to the floor Layout of second mat before tiling.

  • Page 7: Testing And Commissioning

    1. Before you lay the SmartMat. 2. After you have laid your SmartMat and before you cover your SmartMat. 3. After your finished floor has been laid. This information must then be recorded on your commissioning record form (enclosed in the mat box).

  • Page 8: Product Specifications

    Product Specifications 100 watt/150 watt/200 watt 100W Quick Find Part Code Coverage Length Width Wattage Resistance +9/-4% 8488 SmartMat 100-1 1.00m² 2.0m 0.5m 100w 529.00 Ω 8489 SmartMat 100-1.5 1.50m² 3.0m 0.5m 150w 352.67 Ω 8490 SmartMat 100-2 2.00m² 4.0m 0.5m...
  • Page 9 Product Specifications 100 watt/150 watt/200 watt 200W Quick Find Part Code Coverage Length Width Wattage Resistance +9/-4% 8516 SmartMat 200-1 1.00m² 2.0m 0.5m 200w 264.50 Ω 8517 SmartMat 200-1.5 1.50m² 3.0m 0.5m 300w 176.33 Ω 8518 SmartMat 200-2 2.00m² 4.0m 0.5m...
  • Page 10 Floor plan Sketch Calculate your total heat area...
  • Page 11 Floor Plan Sketch Calculate your total heat area Scale approx 1:18 (56mm = 1m) When sketching your floor plan, please work around any permanent / fixed furniture items as these will block the heated areas...

  • Page 12: Troubleshooting

    Thermostat not set correctly Refer to thermostat instructions Floor sensor too close to heating element Contact the SmartMat Helpdesk 01473 559077 Contact the SmartMat Helpdesk with any questions on 01473 559077 Notes Use this space to make notes for reference SmartMat...
