P C - 5 0 1 U s e r M a n u a l

Mechanical Illustration

S217IR

Technical Specifications

Dimensions
USB connector
Communications
Power
Approvals

Radio Specifications

The PC501 houses either a 0dB (P/N 02-9994) or 20dB (P/N 02-9894) radio, depending on the required application.
Performance
RF Data Rate
Antenna Type
Indoor Range
Outdoor/ RF line-of-sight range
Transmit Power
Receive Sensitivity
Frequency Band
S5bus header
S5bus header
95mm x 95mm x 25mm
Mini USB 5-pin header
Infrared (IR5), S5bus, RF, 802.15.4
See current consumption chart in table x.
FCC Part 15
02-9994
250kbps
SMT
70ft
540ft
1mW (+0dBm)
-94.6dBm
2.4Ghz
P a g e 3 o f 8
CC2430 0dB
radio
Indicator LEDs
MiniUSB
02-9894
SMT
SMT
100ft
1000ft+
10mW (+18dBm)
-94.6dBm
2.4Ghz
