SQUANTO
TK-STAR GPS PET TRACKER

USER MANUAL

PREFACE
Thank you for purchasing the Pet GPS tracker from Squanto Tracking. This manual shows how to operate the
device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note
that specification and information within this document is subject to changes without prior notice. Any change
will be integrated in the latest release. The manufacturer assumes not to be responsible for any errors or
omissions in this document.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TK-STAR and is the answer not in the manual?

Questions and answers

Related Manuals for SQUANTO TK-STAR

Summary of Contents for SQUANTO TK-STAR

  • Page 1: User Manual

    USER MANUAL PREFACE Thank you for purchasing the Pet GPS tracker from Squanto Tracking. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information within this document is subject to changes without prior notice. Any change will be integrated in the latest release.
  • Page 2 1. SUMMARY Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet. It uses the latest advanced technology of GPS and A-GPS dual positioning. Content Specs. Dimensions 70mm x 37mm x 20mm(2.7”*1.4”*0.78”) Weight Network GSM/GPRS...

  • Page 3: Led Indicator Status

    LED INDICATOR STATUS MEANING Left-GREEN-Not lit Device fault or dormant. Left-GREEN-Continuously lit No GPRS signal. Left-GREEN-Flashing GSM/GPRS communication established. Center-RED-Not lit Fully charged. Center-RED-Solid red Charging. Center-RED-Flashing Low battery. Right-BLUE-Not lit No power to the unit or the unit can’t start. Right-BLUE-Continuously lit Searching for GPS signal.
  • Page 4 2. INITIAL SET UP - Before First Use. Please complete the following in order to make sure your tracker works correctly. 1. Before first use charge battery for 8-12 hours. This conditions the battery for maximum performance. The red ‘charging’ LED light will go out after a while – please continue to charge for up to 12 hours for the first charge. Troubleshooting Note 1: On occasion when the unit is turned on it will freeze with both Blue and Green LED lights turned on and will not power off when the power button is pressed nor will it respond to commands.
  • Page 5 COMMAND (TEXT MESSAGE) REPLY (CONFIRMATION) INSTRUCTION 1. You need to reboot the device at first begin123456 begin ok start up to ensure correct working. Send the unit a SMS message with the following written in the message: 2. The admin number ensures your unit admin123456+(space)+phone admin ok only communicates with you.
  • Page 6 communicate with the unit. Once the password has changed please make sure you substitute the default 123456 in the below commands with your new 6 digit passcode. Please don’t lose the new passcode – you will need to download the software and reset the unit in order to use it properly.
  • Page 7 Change password. Password123456+(space)+new Password ok As above it is important to change the password. password to prevent anyone not E.g. authorised by you accessing the device. Password123456 987654 PLEASE keep a note of your new password as it is very difficult to reset the device without it.
  • Page 8 5. USING ADDITIONAL FUNCTIONS AND COMMANDS Please see the below table for different functions and their commands. Note: if you have changed the password you need to substitute “123456” with your new 6 digit password on all the below commands. Instructions Command Reply...

  • Page 9: Tracking Options

    recommended as it relies on mobile phone masts for location, but will save some more battery. If you wish to save the battery it is recommended you use the Sleep mode as above. Send the following command: Change the device back into GPRS gprs123456 gprs ok mode...
  • Page 10 App Tracking: Platform: http://2.tkstargps.net/ IMEI No.: On the inside of the cover Password: 123456 (or whatever you have set) APPLICATIONS FOR ANDROID/iOS Android: Please go to www.tkstargps.net/ for the latest releases of the Android GPS applications. iOS: Search TKSTAR GPS in the Apple App Store to install the applications on your iOS device.
