INSTRUCTION MANUAL
Verti 830 / 831
Granberg Interior AB
Box 6112
SE-600 06 Norrköping
SWEDEN
English
Verti 830/831
Doc. No: M830/831
Edition: 5
Date: 2012-12-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Verti 830 and is the answer not in the manual?

Questions and answers

Summary of Contents for Granberg Verti 830

  • Page 1 English Verti 830/831 Doc. No: M830/831 Edition: 5 Date: 2012-12-07 INSTRUCTION MANUAL Verti 830 / 831 Granberg Interior AB Box 6112 SE-600 06 Norrköping SWEDEN...
  • Page 2 For more information, see: www.granberg.se...
  • Page 3: Table Of Contents

    Content Section: Headline: Page: Introduction ..............................4 Declaration of Conformity ......................... 4 Intended use - Technical data ........................4 Installation instructions: Mechanical construction ..........................5 Delivery modules ............................5 Joist heights ..............................6 Location wall socket and control devices .................... 7 Preparations ..............................
  • Page 4: Introduction

    It can be used separately, or together with the Granberg work top units, and it becomes then a total adaptation of the kitchen. The lift is suitable for all wall cabinets of various makes, which are made according the standards EN 1116 and EN 1153.
  • Page 5: Mechanical Construction

    Mechanical construction The Verti Cabinet lift unit comprises a rear panel, to be mounted on a wall, a lifting mechanism and a rack with 3 shelves. The vertical lifting and lowering motions are made by an electrically powered lifting belt, which is fitted between the rear panel and the shelf rack.
  • Page 6: Joist Heights

    Joist heights for Verti The Verti unit is fixed to the wall through the rear panel. Laying joists shall be placed according to the dimensions below: A = 1440 mm from floor to centre of the joist B = 2052 mm from floor to centre of the joist ----------------------------------------------------------------------------- --------------------------------------------------------------------- -------------------...
  • Page 7: Location Wall Socket And Control Devices

    Location of sockets and control devices The Verti unit shall be connected to a separate main switch, which is placed in the kitchen or its vicinity. The location of a socket for 230 V, 50 Hz / 120 V, 60 Hz (depends on model) should be coordinated with other equipment in the kitchen. The Verti wall cabinet system is often in combined with a worktop system.
  • Page 8: Preparations

    Preparations The Verti unit shall be mounted inside a wall cabinet. Avoid placing Verti above the water tap, as this can prevent the Verti to be lowered to the bottom position. If necessary choose a low water tap. 4.5.1 Location in cabinet At cabinet height 70 cm: At cabinet height more than 70 cm: Example on alternative installation:...
  • Page 9: Installation On Wall

    4.5.3 Preparations at installation of Verti in a Verti cabinet frame (accessories) * The Verti cabinet frame is delivered unassembled. Assemble the sides and top. * Assemble the adjacent wall cabinet. * Install the Verti cabinet frame between the adjacent cabinets. Fix the Verti unit with screws in the adjacent cabinets. (If there are no adjacent cabinets available mount the Verti unit with consoles on the frame inside).
  • Page 10: Installation Of Lighting Under The Safety Panel (Accessory)

    4.7.4 Connection can be made to the printed circuit board (see section 12 or to a Picture 2 separate transformer. NOTE! Only the Granberg original lighting grants full safety. Installation of light ramp (Accessory) Picture 3 Install the light ramp with angles on the trip plate. (Angles and screws are not included).
  • Page 11: Safe Use

    Safe use In order to utilise the properties of Verti lift and to prevent and avoid damages it is important that you carefully read the in- structions and operates it in the right way. • Only use the Verti for its intended purpose. •...
  • Page 12 • Competent persons only must carry out • Installation, service and repair works. • Only Granberg original spare parts shall be used when replacing any parts. Our warranty commitment can otherwise be invalidated.
  • Page 13: Safety Arrangements

    We recommend that a Risk assessment in accordance with the Machinery Directive shall be made for the actual working con- ditions. If the owner fits accessories, contact Granberg to get approval of the loading conditions. Actions after use The Verti unit shall after use be left fully raised to the top level, the parking position.
  • Page 14: Alternative Control Devices

    Alternative control devices The operator shall have a clear view of the hazardous parts of the Verti and its motions, but not directly within the work area, as there is a risk that objects may fall out of the cabinet. (Due to limited space it can be necessary to place the control devices is placed within the work area).
  • Page 15: Maintenance

    When the Verti unit shall be re-used shall it must be cleaned, inspected and go through a full operation test before it is in- stalled on the new site. We recommend the machine to be sent to Granberg or to the Granberg distributor to get this done. The machine is manufactured from re-usable materials or from materials that can be recycled.
  • Page 16: Decals

    Damages caused by misuse or incorrect operation of the equipment means that the warranty would expire. Before any warranty work is commenced by a customer Granberg must be contacted for analysis and approval. We do not ac- cept to carry any warranty costs if the repair work has started without an agreement by us.
  • Page 17: Service & Maintenance Records

    Service and Maintenance Records Type and model:_______________________ Manufacturing No.:________________________ Delivery date:_____________________________ Service & maintenance Service & maintenance Service & maintenance Date:______________________ Date:______________________ Date:______________________ Sign._______________________ Sign._______________________ Sign._______________________ Remarks:___________________ Remarks:___________________ Remarks:___________________ ___________________________ ___________________________ ___________________________ ___________________________ ___________________________ ___________________________ ___________________________ ___________________________ ___________________________ Service & maintenance Service &...
  • Page 18: Fault Finding

    SHALL BE MADE, BEFORE IT IS TAKEN INTO USE. (SEE SECTION 4.9) Spare parts list If any component does not work or has broken, contact your supplier. Only Granberg original spare parts must be used when replacing any parts. Our warranty commitment may otherwise be invalidated.
  • Page 19: Electric Circuit Diagram

    Up/Down Button Not in use Down CE-Declaration of conformity (According Machinery Directive 2006/42/EG, Annexe 2A) Manufacturer: Granberg Interior AB Tel. +46-11-19 77 50 Box 6112, Fax +46-11-12 76 76 SE-600 06 NORRKÖPING, Sweden declares under sole responsibility that the product:...
  • Page 20 Box 6112 SE-600 06, Norrköping Sweden Tel: +46 (0)11-19 77 50 Fax: +46 (0)11-12 76 76 E-mail: info@granberg.se - Internet: www.granberg.se...
