Summary of Contents for AllSee Technologies TL40H1
- Page 2 User’s Manual LCD Video Wall LCD Video Wall Universal User’s Manual Video Wall Model: TL40H1, TL46H1, TL46H2, TL46H3...
-
Page 3: Table Of Contents
User’s Manual LCD Video Wall CONTENT: Chapter I - Introduction to interface ----------------------------------------------------------3 1.1 Introduction to interface-------------------------------------------------------------------------3 1.2 Introduction to OSD buttons-------------------------------------------------------------------4 Chapter II - Connecting -----------------------------------------------------------------------------5 2.1Control video wall through RS232------------------------------------------------------------5 2.2 Display DVI Signal-------------------------------------------------------------------------------5 Chapter III - Introduction to Remote Control and Signal Input ----------------6 3.1 Introduction to Remote Control--- ------------------------------------------------------------6 3.2 Instruction to signal input selection-----------------------------------------------------------6... -
Page 4: Chapter I Introduction To Interface
User’s Manual LCD Video Wall Chapter I Introduction to interface 1.1 Interface ： A． AC IN： AC POWER IN B． RS232 INPUT/OUTPUT: RS232C serial Port C． BNC/RGB/HV IN: (R, G, B, H, V)BNC Connector for VGA signal –D) IN: DVI-D Connector for digital signal input； D．... -
Page 5: Introduction To Osd Buttons
User’s Manual LCD Video Wall 1.2 Introduction to OSD buttons: ： Left and Right buttons 1） a. adjust volume b. select in OSD menu. c. select in signals input d. adjust values ： 2） Open/Close OSD Menu or Return to Previous Menu Open signals input list Select signal input. -
Page 6: Control Video Wall Through Rs232
User’s Manual LCD Video Wall 2.1 Control monitors through RS232: Video wall monitors can be controlled by computer through RS232 cable. There are two RS232 connectors on the monitor (one for signals input, the other for signals output). Every monitor needs a separate ID number to manage through RS232. -
Page 7: Chapter Iii Introduction To Remote Control And Signal Input
User’s Manual LCD Video Wall Chapter III Introduction to Remote Control and Signal Input 3.1 Introduction to Remote Control: Power MODE: Select signal input Navigation Butt ons: Press these but tons to select preference and MENU for confirmation. 3.2 Instruction to signal input selection: Press MODE button to enter signals input list and use navigation buttons to make a choice. -
Page 8: Instruction To Menu
User’s Manual LCD Video Wall 3.3 Introduction to menu： ■ Picture： Press “MENU”button, following picture will show on the screen. Press“▲, ▼” to choose the item you want and press “◀ , ▶” to change parameters. 1) Contrast：Adjust the contrast ratio of the picture. Press “◀, ▶”... - Page 9 User’s Manual LCD Video Wall 1) TEMPERATURE：Actual temperature insight machine. 2) FAN ACTIVE：The user can set an optimum temperature. When the actual temperature is higher than the set temperature, the fan will automatically run; when temperature inside the machine is lower than the set temperature, fan will shut down automatically.
-
Page 10: Set Board Id
User’s Manual LCD Video Wall 1） CLOCKER：Set current time 2） ON TIEM： Automatically power on as the time you set. 3） OFF TIME： Automatically power off as the time you set. 4） CURRENT X: Number of X on the digital wall 5) CURRENT Y: Number of Y on the digital wall 6) TOTAL X: Total number of monitor on X axis 7) TOTAL Y: Total number of monitor on Y axis...
