  • Page 1 INTELLIGENT TEACHING CAM PC PROJECTOR EZ-200 Operation Manual...
  • Page 2 Overview Image-recognition-learning system EZ-CAM (Intelligent Teaching Cam) The image-recognition-learning system, EZ-CAM enables to proceed immediate and intensive lecture by adopting the picture image recognition technology with retaining variety contents material. Teachers can collect and produce required materials for the lecture in advance and utilize them in the class, and as such learning data base which has been built and re-produced consolidated lecture material...

  • Page 3: Table Of Contents

    Contents Chapter 1 EzCam feature 1. Product contents 2. Hardware Specification 3. Connect hardware and computer Chapter 2 EzCam software installation 1. EzCam software installation 2. EzCam Driver installation 3. EzCam Driver settings Chapter 3 EzCam software functions 1. EzCam program execution 1) EzCam project contents 2) Create/manage contents folder 3) EzCam program structure...

  • Page 4: Product Contents

    Chapter 1 EzCam feature 1. Product contents In the standard EzCam(EZ-200) model, EzCam hardware body (camera part, mounting stand), storage box, users manual and installation CD are provided (Version upgrade is available through the home page related to the function upgrade within same model)

  • Page 5: Connect Hardware And Computer

    2. Specification LIST Description Product Name Image-recognition-learning system Model EZ-200 Camera sensor 1/3inch, 2million pixels DSP Resolution Maximum UXGA 1600x1200 Lens/Picture Angle F 2.8 / 5cm ~ Focus control function Auto/manual (AUTO FOCUS/PUSH AUTO) Brightness & Color adjustment function Auto/manual (Program volume adjustment)

  • Page 6: Chapter 2 Ezcam Software Installation

    Chapter 2 EzCam software installation 1. EzCam software installation Please install EzCam driver and program as following process sequency. Insert install CD Install EzCam program files Install EzCam driver Connect EzCam to computer USB port Check driver setting of connection port Finish Install EzCam program files Run installation file in the CD (\EzCam\setup.exe)
  • Page 7 3. Setting of EzCam driver After installation of EzCam softwares and drivers, connect EzCam USB cable to the computer USB port and complete the driver settings of connection port. 1) Driver setting sequence (Automatic search) Connect USB Search new hardware Driver auto-search Message output for XP compatible...

  • Page 8: Chapter 3 Ezcam Software Functions

    Chapter 3 EzCam software functions 1. EzCam program execution Click the EzCam icon in desktop to execute the image-recognition-learning and epidiascope function. Please confirm the connection with camera prior to run the program, so that the program is executed in connection state with camera. Icon Screen of Program loading Screen of program executing...

  • Page 9: Ezcam Project Contents

    2) Create and manage contents folders It is the first screen after program loading, also it displays the learning contents which had been made, and files can be open at the contents folder directory . And user can create additional contents folder so that contents files can be stored and managed efficiently.
  • Page 10 3) The structure of EzCam program The picture image is linked with learning material related to recognition for enabling image-recognition-learning function, and it enables the user centric perceptible teaching . Tool window (mode/function) Contents link window Link image window & move image/zoom in Image recognition Text input window...
  • Page 11 4) Detail function of EzCam icon tool bar All function buttons are replaced with icons in order to execute EzCam program and to manage and create learning contents, so that user can execute all required work in the selected mode. Icon functions are categorized in the screen top tool bar and sub-tool bar in the main image window, and each of their functions are as below.
  • Page 12 Auto focus | Adjust focus when the it is out of focus due to the change of picture angle. Edit text & Help Edit text | Fix learning mode recognition | Help Screen bottom tool bar of main image window Fix tool bar | Change entire screen | Rotate image | Move image(left/right) | play back sound file /Pause/stop | Fit image size to window | Image zoom-in/out bar 2.
  • Page 13 Click the mouse right button | Available to delete recognition-image file and change name Available to delete selected image file by Delete in keyboard. (in the deletion, links of files are cleared and file which was supposed to be imported from outside is deleted with the message of file deletion automatically.) Window for importing external recognition-image It creates the recognition-image file of window, and coverts existing photos and...
  • Page 14 Linking to 7 kinds of learning contents is available as well as the repeat playback of same sort of contents. In the learning mode, when image is recognized the linked file source becomes in standby mode which is available to be used immediately. Icons by the source of linked contents are below.
  • Page 15 Folder selecting window Window of selecting individual contents image Import contents Click the contents import icon in the top tool bar to import individual contents and entire contents in the selected folder, so that they can be used in other PC. The folder under the folder selection window or individual contents file is...

  • Page 16: Learning Mode

    2) Learning mode The learning contents which was completed in edit mode can be utilized in contents for lecture and play learning through image recognition. As there is no difference between recognition objects, applications in variety area are available, it maximize the utilization of existing contents, it lists the data automatically during the lecture and saves waste of additional time, and as the result it is helpful in the present educational environment which requires utilization of variety contents.

  • Page 17: Epidiascope Function

    3. EzCam epidiascope function High resolution epidiascope can be used in learning with functions such as image view, image capture and saving motion picture. The resolution in epidiascope mode is 2million pixels 1600*1200 size, and it provides fixed ratio(4:3) of image with considering the monitor resolution for occurring no image corruption in various monitor so that the utmost screen image can be displayed in existing projection TV and projector.
  • Page 18 The presently displaying motion image can be captured as 1600 1200 still image by the image-capture icon button. The saved image is JPG file format. 4. Produce sample contents using EzCam The process of producing the EzCam image recognition learning contents is as below.
  • Page 19 Learning mode : image recognition Activate lecture contents Proceed lecture(repeat recognition/lecturing by subject/keep lecture time efficiently) It links material for supplementary explanation related to recognized image, and then it enables insight and efficient lecture. (Activate pop-up window for document/sound/media files.) Main image window (Contents related to the recognized image is displayed, Image recognition...

  • Page 20: Chapter 4 Ezcam Installation And Check List In Case Of Malfunction

    Chapter 4 EzCam installation and check list in case of malfunction When the program starts, it messages “Camera may not be connected, or it’s not the appropriate camera. Please connect the camera again” and no more execution. - Please confirm the connection between EzCam camera and USB. ( No other camera other than EzCam can execute program.) - Control panel System...
  • Page 21 Quality warranty period of this product is one year. Within the warranty service period, failure of product under normal use will be repaired free of charge. Product Name EZ-CAM (EZ-200) Mgf No. Date of purchasing Store of purchasing Customer name...

  • Page 22: Sample Image

    Sample Image...
  • Page 23 Sample Image...
  • Page 24 Sample Image...
  • Page 25 Sample Image...
  • Page 26 Sample Image Tulip...
  • Page 27 Sample Image...
  • Page 28 Sample Image Remember the Trees Francois Ruyer data source : Dongsamo.co.kr e-book contents...
  • Page 29 data source : Dongsamo.co.kr e-book contents...
  • Page 30 data source : Dongsamo.co.kr e-book contents...
  • Page 31 data source : Dongsamo.co.kr e-book contents...
  • Page 32 data source : Dongsamo.co.kr e-book contents...
  • Page 33 data source : Dongsamo.co.kr e-book contents...
  • Page 34 data source : Dongsamo.co.kr e-book contents...
  • Page 35 data source : Dongsamo.co.kr e-book contents...
  • Page 36 Earzone Co., Ltd. 309 Ace Techno Tower III 197-48, Guro-3-dong, Gurogu, Seoul, Korea Tel: 82-2-2109-6770 Fax:82-2-2109-6776 Copyright EARZONE Corporation 2007...
