Redwall Redscan RLS-3060L Installation Instructions Manual

Redwall redscan rls-3060l laser scan detector

Advertisement

Laser Scan Detector
Laser Scan Detector
RLS-3060L
RLS-3060L
FEATURES
* Detection range is 30m (Approx. 00ft.) radius, max. 90 degree
* Selectable horizontal or vertical detection area
* Recognition of the intrusion location which can activate 4
independent outputs for PTZ control
* Flexible and easy setup of the required detection area
* Analog (dry-contact) output and IP connection
REDSCAN is an area sensor that configures a fan-like detection
area of 30 m (Approx.00 ft.) radius over 90 degrees arc. using
laser beams.
REDSCAN detects target objects by emitting laser beams at the
target and measuring the time required for the emitted beams to
be reflected and returned to the detector.
There are 2 modes for detecting an intruder. Horizontal Detection
Area2 and Vertical Detection Area. Each one is configured with
an independent detection algorithm.
CONTENTS
! INTRODUCTION
BEFORE OPERATION .........................................................................
-
PRECAUTIONS ................................................................................... 2
-2
PARTS IDENTIFICATION .................................................................... 2
-3
INSTALLATION WORK FLOWCHART................................................. 2
-4
TYPES OF INSTALLATION METHOD ................................................. 3
2-
TYPES OF DETECTION METHOD ..................................................... 3
2-2
AREA SETTING PROCEDURE ........................................................... 4
2-3
INSTALLING TO WALL OR CEILING PLANE ...................................... 4
3-
INSTALLING TO POLE ........................................................................ 5
3-2
3-3
3-4
WIRING ................................................................................................ 6
4-
SIGNAL OUTPUT ................................................................................. 6
4-2
POWERING ON ................................................................................... 6
4-3
LED FUNCTIONS ................................................................................ 7
4-4
INITIALIZATION TO FACTORY DEFAULT ........................................... 7
4-5
SELECTOR SWITCH OPERATION ..................................................... 7
5-
ADJUSTMENT OF HORIZONTAL DETECTION AREA ....................... 7
5-2
5-3
SELECTOR SWITCH OPERATION ..................................................... 8
6-
ADJUSTMENT OF VERTICAL DETECTION AREA ............................. 9
6-2
AUTO SETTING OF VERTICAL DETECTION AREA .......................... 9
6-3
WALK TEST ....................................................................................... 0
7-
SYSTEM FUNCTION AFTER POWER FAILURE .............................. 0
7-2
( IP CONNECTION WITH REDSCAN
DEFAULT SETTINGS ......................................................................... 0
8-
REDSCAN MANAGER ....................................................................... 0
8-2
REDWALL EVENT CODE ................................................................. 0
8-3
SPECIFICATIONS OF THE MAIN UNIT ............................................
9-
DIMENSIONAL DRAWING.................................................................
9-2
OPTIONS ...........................................................................................
9-3
No. 598 5- 0 5
INSTALLATION INSTRUCTIONS

INTRODUCTION
- BEFORE OPERATION
Read this instruction manual carefully prior to installation.
This manual uses the following warning indications to provide
information regarding correct usage of the product to prevent
you and other people from being harmed and your assets
from being damaged. These warning indications are described
below.
Ensure you understand these precautions before reading the
rest of this manual.
Warning
Caution
This symbol indicates prohibition.
The specific prohibited action is provided in and/or around
the figure.
This symbol requires an action or gives an instruction.
Do not use the product for purposes other than the
detection of moving objects such as people and
vehicles.
Do not use the product to activate a shutter, etc.,
which may cause an accident.
Do not touch the unit base or power terminals of
the product with a wet hand (do not touch when the
product is wet with rain, etc.). It may cause electric
shock.
Never attempt to disassemble or repair the product. It
may cause fire or damage to the devices.
Do not exceed the voltage or current rating specified
for any of the terminals, doing so may cause fire or
damage to the devices.
Ensure the power is turned off before connecting
wiring.
Confirm the signal name of every terminal to ensure
wiring is carried out correctly.
Whenever a commercial switching regulator is used,
be sure to connect PE (Protective Earth Terminal).
Hold the main unit securely when you install or
service it. Exercise care not to bump the product
against nearby objects or drop it inadvertently.
This product is not capable of detecting objects in the
dead zone of the laser scan.
Do not use this product for an application where it is
not capable of covering the detection area required
by the task.
Please note that the product can malfunction,
including producing an irregular output and
committing a detection error, if it is exposed to
unfavorable environmental conditions such as
strong ambient light, electronic noises or mechanical
vibrations.
Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
Clean and check the product periodically for safe use.
If any problem is found, do not attempt to use the
product as it is.
When disposing of this product, be sure to follow the
waste-disposal regulations of the country or region
where it is used.
This product is intended to detect an intruder(s)
and is not designed to prevent theft, disasters or
accidents. The manufacturer shall not be held liable
for any damage to user's property resulting from
theft, disasters or accidents.
-  -
Failure to follow the instructions provided by
this warning and improper handling may cause
death or serious injury.
Failure to follow the instructions provided by
this caution and improper handling may cause
injury and/or property damage.
Warning
Caution

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RLS-3060L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Redwall Redscan RLS-3060L

  • Page 1: Table Of Contents

    Laser Scan Detector • This manual uses the following warning indications to provide information regarding correct usage of the product to prevent RLS-3060L you and other people from being harmed and your assets RLS-3060L from being damaged. These warning indications are described below.
  • Page 2: Precautions

    -2 PRECAUTIONS -3 PARTS IDENTIFICATION Install the product only on a In the Horizontal Detection Mounting bracket Main unit solid surface. Area, this product must normally be used within the recommended installation height in order to detect an Cover intruder. Cover mounting screw Installation height: 0.7 m to  m...
  • Page 3: Types Of Installation Method And Detection Areas

    -Vertical Detection Area TYPES OF INSTALLATION METHOD AND DETECTION AREAS This mode allows setting of a fan-like detection area in the vertical direction with a maximum radius of 30 m (Approx. 00 ft.), 2- TYPES OF INSTALLATION METHOD a spread angle of 80 degrees. This mode creates a non detection area, .5 m (Approx.
  • Page 4: Area Setting Procedure

    2-3 AREA SETTING PROCEDURE Remove the mounting bracket from the main unit. The setting procedure comprises two options; P and P2. Loosen 4 lock screws. Move the The setting procedure in each mode varies depending on which mounting detection method of either Horizontal Detection Area 2 or Vertical bracket detection Area is selected.
  • Page 5: Installing To Pole

    3-2 INSTALLING TO POLE Install the cable gland. When installing the product to a pole, use the optional pole mounting bracket (RLS-PB). Pole mounting Ensure that any unused bracket (optional) Stainless belt wiring holes are covered (included with the securely with a wiring pole mounting hole cap.
  • Page 6: Confirmation Of Location Of The Laser Plane

    CONFIRMATION OF LOCATION OF 4-2 SIGNAL OUTPUT THE LASER PLANE -D.Q. output It is recommended that the optional Laser Area Checker (LAC-) The algorithm specific to REDSCAN allows for is used to confirm the location of the laser plane. detection during foggy conditions. However, during severe conditions such as heavy rain, dense fog -Horizontal Detection Area or snow storms the Environmental DisQualification...
  • Page 7: Led Functions

    Area Area Area Area Note >> The following switch settings of the RLS-3060L can only 5 m be changed using the Redscan manager software. Refer 4 m 30 m to ( for IP connection and the Help menu of the Redscan Manager software for more details.
  • Page 8: Auto Setting Of Horizontal Detection Area

    SETTING VERTICAL DETECTION AREA Note >> The following switch settings of the RLS-3060L can only be changed using the Redscan manager software. Refer to ( for IP connection and the Help menu of the Redscan Manager software for more details.
  • Page 9: Adjustment Of Vertical Detection Area

    -Selecting the Auto mode 6-3 AUTO SETTING OF VERTICAL DETECTION AREA SELECTOR FUNCTION POSITION Fixed detection area. (Factory default) Adaptive detection area. 30 m -Setting the detection sensitivity Installation height Area A Area B Set the detection sensitivity using the SIZE and SENS buttons as Area Area Area...
  • Page 10: ² Area Checkups

    AREA CHECKUPS IP CONNECTION WITH REDSCAN 7- WALK TEST 8- DEFAULT SETTINGS - IP address : 92.68.0.26 (Can be changed) - Subnet mask : 255.255.255.0 (Can be changed) Ensure that the detection area has been correctly set by observing the indicators or detection circle on the Redscan Manager software.
  • Page 11: Specifications

    9-2 DIMENSIONAL DRAWING SPECIFICATIONS 9- SPECIFICATIONS OF THE MAIN UNIT Model RLS-3060L Detection method Infrared Laser Scan Class  IEC / EN60825- Laser protection Second edition 2007 Class I class FDA 2CFR 040.0,040. (Laser Notice No.50) (5.7) (6.) (0.7) (2.5)
  • Page 12 OPTEX CO., LTD. (JAPAN) OPTEX INCORPORATED (USA) OPTEX SECURITY Sp. z o. o. (POLAND) TEL:+-909-993-5770 TEL:+48-22-598-06-55 (ISO 9001 Certified) Tech:(800)966-7839 URL:http://www.optex.com.pl/ (ISO 14001 Certified) URL:http://www.optexamerica.com/ 5-8-2 Ogoto Otsu Shiga 520-00 OPTEX (EUROPE) LTD. (UK) OPTEX KOREA CO., LTD. (KOREA) TEL:+44-628-63000 TEL:+82-2-79-597 JAPAN URL:http://www.optexkorea.com/...
  • Page 13 D.Q. OUTPUT (ENVIRONMENTAL DISQUALIFICATION) The algorithm specific to REDSCAN allows detection of an intruder during fog. However, during severe conditions such as heavy rain, dense fog or snow storms the Redscan detection capability may be reduced. During such conditions, the Enviromental DisQualification (D.Q.) output will be activated. When this output is activated, other solutions are required to secure the area.
