Summary of Contents for Dynamix FiberMix 2802-60FE-BL

  • Page 1 FiberMix 2802-60FE-BL User Manual...
  • Page 2 Dynamix Pro., Ltd shall not be held liable for errors contained herein or direct, indirect, special, incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3: Contact Information

    Contact Information World Wide Web You can access the most current Dynamix product information on the World Wide Web at the following URL: http://www.godynamix.com http://www.dynamix.ua Feedback Comments and questions about how the FM2802-60FE-BL device works are welcomed. Please review the FAQ in the related manual, and if your question is not covered, send email by using the following web page: http://www.godynamix.com/ukr/cont.htm.
  • Page 4: Table Of Contents

    CONTENTS Release Notes------------------------------------------------------------------------------------------------- 5 General Safety Instructions ------------------------------------------------------------------------------ 6 Safety Symbols ---------------------------------------------------------------------------------------------------------------------6 Handling Energized Products ---------------------------------------------------------------------------------------------------6 General Safety Practices ------------------------------------------------------------------------------------------------------------------------ 6 Connection of AC Mains ------------------------------------------------------------------------------------------------------------------------- 7 Connection of DC Mains ------------------------------------------------------------------------------------------------------------------------- 7 Preventing Electrostatic Discharge Damage --------------------------------------------------------------------------------7 Chapter 1 Product Overview ------------------------------------------------------------------------- 1 Overview---------------------------------------------------------------------------------------------------------------------1 Function features ----------------------------------------------------------------------------------------------------------1...
  • Page 5: Release Notes

    Release Notes Date of Release Manual Version Revisions 20071119 200706 REV.A...
  • Page 6: General Safety Instructions

    General Safety Instructions The following instructions serve as a general guide for the safe installation and operation of telecommunications products. Additional instructions, if applicable, are included inside the manual. Safety Symbols This symbol may appear on the equipment or in the text. It indicates potential safety hazards regarding product operation or maintenance to operator or service personnel.
  • Page 7: Connection Of Ac Mains

    be present inside certain products even when the power switch (if installed) is in the OFF position or a fuse is blown. For DC-powered products, although the voltages levels are usually not hazardous, energy hazards may still exist. Before working on equipment connected to power lines or telecommunication lines, remove jewelry or any other metallic object that may come into contact with energized parts.
  • Page 8: Chapter 1 Product Overview

    w w w .g o d y n a m ix .c o m User Manual Chapter 1 Product Overview 1.1 Overview FM2802-60FE-BL is a modular PDH multiplexer of a fiber optic transmission device applicable to point-to-point network or network with small or medium capacity, like wireless communication base station, private networks, switch network and etc.
  • Page 9 w w w .g o d y n a m ix .c o m User Manual FM2802-60FE-BL-SS13 Modular device, 2 120Ω balanced E1 interfaces (RJ-45), 1 Ethernet interface (RJ-45), 1 optical interface (SC-PC), single-strand, two-wavelength, Tx wavelength 1310nm, transmission distance 0~25km FM2802-60FE-BL-SS15 Modular device, 2 120Ω...
  • Page 10: Chapter 2 Technical Specifications

    w w w . g o d yn a mix .c o m User Manual Chapter 2 Technical Specifications 2.1 Technical specifications of the E1 interface Bit Rate: 2048Kbps±50ppm Coding: HDB3 Interface Type: RJ-45 Interface Impedance: 120Ω Physical characteristic: comply with ITU-T G.703 recommendations Transfer characteristic: comply with ITU-T G.823 recommendations Jitter tolerance: comply with ITU-T G.823 recommendations 2.2 Technical specifications of Ethernet interface...
  • Page 11: Power Supply

    w w w .g o d y n a m ix .c o m User Manual RX:1550 SS15 SC/PC FP/DFB TX:1550 -12~-3 > -8 < -30 0 ~ 25 RX:1310 SS23 SC/PC TX:1310 -5~0 > -8 < -32 10 ~ 50 RX:1550 SS25 SC/PC...
  • Page 12: Chapter 3 Device Appearance And Descripiton

    w w w . g o d yn a mix .c o m User Manual Chapter 3 Device Appearance and Descripiton 3.1 Device front panel LNK/ACT 100M 3.2 Indicator description Power supply indicator: PWR (Green): power supply working status indicator ON: the power supply is working normally E1 indicator: LOS1 (Red): indicator for loss of E1 signal at E1 1...
  • Page 13: Interface Description

    w w w .g o d y n a m ix .c o m User Manual Yellow ON: both the local and remote device is working normally when the remote system is power down. 3.3 Interface description 2 E1 balanced interface: 1 RJ-45 interface provides 2 lines of 120Ω...
  • Page 14: Chapter 4 Device Settings

    w w w .g o d y n a m ix .c o m User Manual Chapter 4 Device Settings 4.1 DIP switch description 4.1.1 The location of the DIP switches There are an 8-bit DIP switch SW1 and a 4-bit DIP switch SW2 on the back of the print circuit board.
  • Page 15 www .g od yn a mix .co m User Manual Bit 4 ALS function setting Disable Enable Bit 5: Loopback setting of 1 Bit 5 Loopback setting of 1 No loopback Loopback Bit 6: Loopback setting of 2 Bit 6 Loopback setting of 2 No loopback Loopback Bit 7: Loopback type setting...
  • Page 16 www .g od yn ami x.c om User Manual Optical E1 Side Interface E1 Side Tester Side Local Remote Set local bidirectional loopback on the local PDH multiplexer Note: Please note that when configuring any loopback on the local PDH multiplexer, the status of all loopback setting bits of the DIP switch on the remote PDH multiplexer must be OFF (no loopback).
  • Page 17: Default Settings

    w w w .g o d y n a m ix .c o m User Manual S2 (1310 Tx&Rx) S3 (1550 Tx&Rx) SS13 (1310 Tx, 1550 Rx) SS15 (1550 Tx, 1310 Rx) SS23 (1310 Tx, 1550 Rx) SS25 (1550 Tx, 1310 Rx) 4.1.3 Default Settings The default settings of all bits of SW1 are OFF.
  • Page 18: Chapter 5 Typical Application

    www.g o d yn a m ix .c om User Manual Chapter 5 Typical Application 5.1 Basic connection 1 2 3 4 5 6 7 8 9101112 CONSOLE COL- HS1 HS2 OK1 OK2 PS ACT- STA- ALM/ LNK/ACT 100M LOS1 CO Site LOS2 E1? ?
  • Page 19: Chapter 6 Network Management Features

    w w w . g o d yn a mix .c o m User Manual Chapter 6 Network Management Features 6.1 Network management platform Through Raisecom’s network management platform NView NNM V5.0 together with corresponding EMS FM002_5.0 (Build 3) or above version, users can view the status information of the FM2802-60FE-BL device.
  • Page 20: Chapter 7 Device Installation Preparation And Connection

    w w w .g o d y n a m ix .c o m User Manual Chapter 7 Device Installation Preparation and Connection 7.1 Checking and preparation before installation Please check the model and the number of the device and spare parts according to the packing list.
  • Page 21: Cable Connection

    w w w .g o d y n a m ix .c o m User Manual 7.2.2 Cable connection Please make sure that the E1 interfaces and the optical interface are well connected. 7.2.3 Device electrifying Please fix the module properly in the chassis before turning ON the power supply. After electrifying, the power supply status indicator PWR on the front panel of the device will turn ON to show that the power supply is working normally.
  • Page 22: Appendix A Faq

    w w w . g o d yn a mix .c o m User Manual Appendix A FAQ For some problems you may meet during installation and operation, please try to solve them following the suggestions below. For the problems can not be solved using the following suggestions, please contact with distributors for technical support.
  • Page 23 Web: http://www.godynamix.com Email: support@dynamix.ua...
