PROFESSIONAL SPREADER Assembly / Operation Instructions / Parts
DO NOT RETURN TO THE STORE
Please call 888-201-1193 if you are missing any parts, having trouble assembling, or have any questions regarding the safe
operation of this product.
Carefully Read These Instructions Before Use
IMPROPER USE OR FAILURE TO FOLLOW INSTRUCTIONS CAN RESULT IN PRODUCT FAILURE OR INJURIES. FOR SAFE
USE OF THIS PRODUCT YOU MUST READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING.
- Do not allow anyone to operate the broadcast spreader without proper instructions
- Do not permit children to operate the broadcast spreader
- Wear protective eyewear and gloves when handling and applying lawn and garden chemicals
- Read the chemical label instructions and warnings for handling and applying the chemicals you plan to
spread – application settings provided are only a guideline
MODEL 6333N
CHAPIN OUTFITTERS P.O. BOX 549 700 ELLICOTT ST. BATAVIA, NY 14021-0549 www.chapinoutfitters.com 888-201-1193
WARNING
013652 R0414
Advertisement
Table of Contents
Summary of Contents for Bio-Logic 6333N
- Page 1 - Read the chemical label instructions and warnings for handling and applying the chemicals you plan to spread – application settings provided are only a guideline MODEL 6333N CHAPIN OUTFITTERS P.O. BOX 549 700 ELLICOTT ST. BATAVIA, NY 14021-0549 www.chapinoutfitters.com 888-201-1193...
- Page 2 ASSEMBLY INSTRUCTIONS Approximate assembly time is 20-45 minutes Suggested Tools: Wrench and/or Ratchet Set 1.5mm Allen Wrench Pliers Protective Eyewear NOTE: Depending on model, this package may contain additional hardware not needed for assembly. Full scale nuts and bolts M6 Nylon Locknut (7) M6 x 55mm Hex Bolt (6) M6 x 45mm Hex Bolt (1) M5 Nylon Locknut (1)
- Page 3 Step 1: Attach the right Frame leg and the left Frame leg to the Frame Body using 2 spacers, (2) M6X55mm hex bolts and (2) M6 Nylon locknuts per frame leg. After the frame legs have been attached, place the two End caps onto the bottom of both frame legs. DO NOT TIGHTEN DOWN COMPLETELY.
- Page 4 Step 4: Install the Axle/Drive Shaft a. Slide the Drive shaft through one side of the hopper frame b. Slide gearbox onto axle/drive shaft (make sure “FRONT” is facing front of frame as shown) and align middle hole with gearbox c.
- Page 5 Step 6: Look inside hopper. Insert R-pin into hole in impeller shaft. IMPORTANT: You must remove the R-pin when applying salt or ice melt. Step7: A portion of the Handle will be preassembled as shown. Carefully remove the (2) M6 Hex Nuts, while holding the rest of the Handle Assembly together. Install opposite Handle onto the exposed (2) M6 Hex Bolts, and re- secure the (2) M6 Hex Nuts.
- Page 6 Step 9: Attaching the Gate Control Rod a. Slide gate control lever forward and attach hook at bottom of rod to spring at hopper base b. Attach gate control rod to upper screw on gate control by removing the screw first, attaching the rod, and then re-attaching the screw Step 10: Both Hand Grips slide onto both the left and right...
-
Page 7: Replacement Parts
Replacement Parts Ref.# Part No. Description 6-9008 Hopper Base Assembly 6-9010 Gear Box Assembly 6-9009 Drive Shaft w/2 bearing 6-9012 Gate Control Assembly 6-9013 R Pin 6-9014 Impeller 6-9015 Wheels w/hardware 6-9016 Handle Grips 6-9017 Hardware Bag 6-9001 Grate 6-9000 Rain Cover * Not Shown CHAPIN OUTFITTERS P.O. - Page 8 APPLICATION CHART All Season Residential & All Season Residential & Professional Push Spreader Application Conversion Chart Professional General Application Scotts 3.25 3.5 4.75 Guidelines Chapin Weed Control 10-12 Fertilizer 12-16 Sample Spread Pattern Grass Seed - Overseeding 16-20 Grass Seed - New Lawn 21-27 28-30 Salt &...
