Microphone Discussion System Safety First! • Please check the carton box for any kind of damage on reception of the goods. In case of a damaged carton, please contact your dealer before opening the carton. • !!!! Danger !!!! Exposure to high sound levels may cause a permanent hearing loss.
Page 5
Instruction manual • Set level controls on amplifiers all the way down during power- up to prevent speaker damage if there are high signal levels at the inputs. • Power down & disconnect units from mains voltage before making connections. •...
Page 6
In a system with 20 units, the recommended maximum length between each unit is 5 meters. The CAT5 cables are inserted at the rear of the MDS units. Every unit has an IN and OUT connector, however, both connectors are...
Page 7
• Only use the power supply supplied with the MDS.INT unit. • Do not connect the CAT5 cables from the MDS system to a computer network, router or network switch. • To prevent feedback noise, turn down the gain levels of all units before oper ating the system.
Page 8
Microphone Discussion System Parts and functions of the MDS.CHAIR unit 1. Chairman mute button: press this button to mute all delegate units. The led on the base unit (2) and on the gooseneck microphone (9) will blink. Press again to exit mute.
Page 9
5 have the same function. 6. Power supply connector: connect the power supply supplied with the MDS.INT unit here. Only one supply connection is required for the entire system. 7. Power led: green led lights up when the unit is powered.
Page 10
Microphone Discussion System Parts and functions of the MDS.DEL unit 1. Talk button: push to talk. The led indicator (2) on the base unit and the gooseneck microphone (8) will light up. Press again to stop. 2. Led indicator: lights up steady when the talk button (1) is...
Page 11
4 have the same function. 5. Power supply connector: connect the power supply supplied with the MDS.INT unit here. Only one supply connection is required for the entire system. 6. Power led: green led lights up when the unit is powered.
Microphone Discussion System Parts and functions of the MDS.INT unit 1. Audio in RJ45 connector: connect the CAT5 cable from the last unit in the chain here. 2. Power led: lights up when the system is powered. 3. Audio out: 6.3 mm unbalanced jack connector: connect the...
Page 13
Instruction manual Accessories supplied with MDS.INT System power supply and 6.3 mm unbalanced jack cable: NOTE: the power supply can power up to 20 units in a daisy chain. Output voltage is 15VDC/4.3A. The on/off switch.
Small size microphone discussion system with 1 chairman unit and up to 9 delegate units: the power supply can be located at the end of the chain, where the MDS.INT is located. The chairman unit can be located anywhere in the chain.
Page 15
Medium size microphone discussion system with 1 chairman unit and up to 19 delegate units: the power supply should be located near the middle of the chain. The MDS.INT unit will be located at the end. The chairman unit can be located anywhere in the chain.
Power supply in 100 – 240 VAC/47-53Hz/1.4A max Power supply out 15 VDC/4.3A switching mode power supply Dimensions MDS.INT (h x w x d) 24 x 49 x 49 mm Net weight MDS.INT 36 g Dimensions power supply 38 x 53 x115 mm (excl. cables)
Page 17
Instruction manual Net weight power supply 300 g Packing dimensions 52 x 115 x 224 mm Gross weight 600 g Accessories supplied power supply & cable, 1.5 m 6.3 mm jack cable (unbalanced)
Page 20
Audioprof nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
