OM1006A Industrial Ethernet Switch Four 10/100/1000BASE-T PoE/PoE+ ports Two 100/1000BASE-X SFP optical ports USER MANUAL Rev. 1.1 July 7, 2014 102 WALGREEN ROAD, OTTAWA, ONTARIO, K0A 1L0 Telephone (613) 831-7777 Fax (613) 831-7778 www. luxcom.com email: sales@luxcom.com... - Page 2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Part 15 Class A This Class A digital apparatus complies with Canadian ICES-003.
- Page 3 Manual Revision History Revision 1.0 Initial release September 6, 2013 Revision 1.1 Document tap aggregator option...
-
Page 4: Table Of Contents
Table of Contents Description........................1 USB Console Port......................3 SFP Selection........................3 PoE Card...........................4 Power Inputs........................4 Alarm Relay........................5 Management Interface.....................5 Main Menu..........................6 Options Menu........................7 Ethernet Setup Menu......................7 PoE Setup Menu........................11 Alarm Setup Menu....................... 14 Software Upload Menu......................15 Ethernet Diagnostic Menu....................16 Register Diagnostics Menu....................16 Reset Switch........................ -
Page 5: Description
Both Alternative A and Alternative B pinouts are supported. All connectors are on the front for easy access. The OM1006A has redundant power inputs. Power adapters are available for both non PoE and PoE applications. A relay contact closure is provided for alarms on link, power and PoE power delivery. - Page 6 Description Indicators ALARM Red when an enabled alarm condition is present. Green when power is applied to power input 1. Green when power is applied to power input 2. LINK Green when a 1000BASE-T LINK has been (Ports 1-4) established. Orange-Green when a 100BASE-TX LINK has been established.
-
Page 7: Usb Console Port
As a result, the same driver instance is selected by Windows for all units. If multiple OM1006A units are connected to a USB hub, it may be desirable to program different serial numbers for each unit. This can be done with the FTDI MProg application. -
Page 8: Poe Card
See the Ordering Information section for the available SFP modules. PoE Card When the OM1006A is shipped with a PoE card, it is shipped with the PoE jumpers positioned for “Alternative A” (jumpers toward middle of card). The jumpers can be repositioned for “Alternative B” (power on spare pairs) by moving the jumpers to the edge of the card. -
Page 9: Alarm Relay
Class 1 supplies. The OM1006A is a limited power source as defined in IEC 60950-1. Each PoE output is independently fused. This limits the maximum output current per port to less than 1.75 A and the maximum output power to less than100 Watts. -
Page 10: Main Menu
Register diagnostics menu Reset switch Set password :> 1 OM1006A Ethernet Switch (merlin) OM1006A BootLoader 1.0 May 07 2012 11:50:01 OM1006A Application 1.0 Sep 14 2012 09:26:30 Mode: SFP ports (5 and 6) trunked Monitor Mode: Off Ethernet Status Port... -
Page 11: Options Menu
Set port VID for 802.1Q VLAN switch mode Back :> 1 OM1006A Ethernet Switch (merlin) OM1006A BootLoader 1.0 May 07 2012 11:50:01 OM1006A Application 1.0 Sep 14 2012 09:26:30 Mode: SFP ports (5 and 6) trunked Monitor Mode: Off Ethernet Status... - Page 12 VLAN aware. The managed switch can perform device authentication (802.1X) if desired. Port 6 can also connect to a OM1006A in “Secure 802.1Q VLAN port fan out (MidSpan)” mode. This mode is similar to the “Secure 802.1Q VLAN port fan out (EndSpan)”...
- Page 13 Enter crossover mode (0 = MDI-X, 1 = MDI) [0]: :> 1 OM1006A Ethernet Switch (merlin) OM1006A BootLoader 1.0 May 07 2012 11:50:01 OM1006A Application 1.0 Sep 14 2012 09:26:30 Mode: SFP ports (5 and 6) trunked Monitor Mode: Off...
- Page 14 Enter monitor destination port (1 to 4): 1 Enter monitor source port (1 to 4): 4 Luxcom Technologies Inc. OM1006A Ethernet Switch (merlin) OM1006A BootLoader 1.0 May 07 2012 11:50:01 OM1006A Application 1.0 Sep 14 2012 09:26:30 OM1006 Main Menu Show Ethernet status...
-
Page 15: Poe Setup Menu
Management Interface Enter monitor mode (0 to 3) [0]: Luxcom Technologies Inc. OM1006A Ethernet Switch (merlin) OM1006A BootLoader 1.0 May 07 2012 11:50:01 OM1006A Application 1.0 Sep 14 2012 09:26:30 OM1006 Main Menu Show Ethernet status Show PoE status Show SFP status... - Page 16 Power on manual/semiauto ports Shutdown low-priority ports Reset PoE chip Reconfigure shutdown ports Back :> 1 OM1006A Ethernet Switch (merlin) OM1006A BootLoader 1.0 May 07 2012 11:50:01 OM1006A Application 1.0 Sep 14 2012 09:26:30 PoE Status and Configuration Port PwrGood PwrEnable Class...
- Page 17 1 = Manual 2 = Semiauto 3 = Auto Enter port config (hex) [0x0F]: 1f :> 1 OM1006A Ethernet Switch (merlin) OM1006A BootLoader 1.0 May 07 2012 11:50:01 OM1006A Application 1.0 Sep 14 2012 09:26:30 PoE Status and Configuration Port PwrGood PwrEnable...
-
Page 18: Alarm Setup Menu
PoE devices. The following shows the result of doing a “Reset PoE chip” command: :> 6 :> 1 OM1006A Ethernet Switch (merlin) OM1006A BootLoader 1.0 May 07 2012 11:50:01 OM1006A Application 1.0 Sep 14 2012 09:26:30 PoE Status and Configuration Port PwrGood... -
Page 19: Software Upload Menu
Reprogram card with PRIMARY Back :> 1 PRIMARY MCU software file Model: OM1006A Ethernet Switch Card: OM1006A Application 1.0 Sep 14 2012 09:26:30 BACKUP MCU software file Model: OM1006A Ethernet Switch Card: OM1006A Application 1.0 Sep 14 2012 09:26:30 :> 2... -
Page 20: Ethernet Diagnostic Menu
Management Interface Card: OM1006A Application 1.0 Sep 14 2012 13:55:29 BACKUP MCU software file Model: OM1006A Ethernet Switch Card: OM1006A Application 1.0 Sep 14 2012 09:26:30 Ethernet Diagnostic Menu This menu provides information about the register state of the Ethernet controller, port MIB statics, and cable tests. -
Page 21: Set Password
The password prompt has a 120 second keyboard timeout delay. Here is an example: :> 9 Enter old password: ****** Enter new password: ***** Reenter new password: ***** Password successfully changed The default password as shipped is “luxcom”. -
Page 22: Ordering Information
= +56V, 60W, 0 ~ 40°C, PoE/PoE+ *This power cube comes with four different styles of plug for non-North American mains. Replacement power adapters can be ordered by specifying OM1006A power supply option A. All A/C Adapters accept 100-240Vac, 50-60 Hz input. -
Page 23: Accessories
Accessories Accessories DIN Rail Mounting Clip The OM1006A may be ordered with a mounting clip which allows it to be snapped to 35mm or G-type DIN rails. Part number: DIN-CLIP-05 Spare Power Cube The modem comes with a A/C adapter. For non PoE modems, a +12V North American power adapter may be ordered using the following number. -
Page 24: Specifications
Specifications Specifications Optical 802.3 Laser Light Fiber Optical Optical Optical Module Specification Source Size Output Sensitivity Range Minimum Maximum 1000BASE-SX 1000-SX 850 nm 50/125 µm -9 dBm -18 dBm 550 m 62.5/125 µm -9 dBm -18 dBm 275 m 1000BASE-LX 1000-LX 1310 nm 50/125 µm... -
Page 25: Certification
Warranty This Luxcom product is warranted against defects in materials and workmanship for a period of five years from the date of shipment. Luxcom will, at its option, repair or replace products that prove to be defective during the warranty period provided they are returned to Luxcom . Repairs necessitated by misuse of the product are not covered by this warranty.
