Page 1 C-Class Operator’s Manual...
Page 2 C 240 C 320 C 32 AMG...
Page 3 Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To ensure your pleasure of ownership, and for your safety and that of your passengers, we ask you to make a small investment of your time: •...
Page 4: Table Of Contents
Introduction Choosing global or selective Multicontour seat ......57 mode on remote control ..... 33 Heated seats ........58 Product information ......7 Opening the trunk ....... 34 Rear seat head restraints ....60 Operator’s manual ......8 Opening and closing windows Seat belts and integrated Where to find it ........
Page 5 Contents Instrument cluster ......98 Night security illumination ..146 Audio system tone level selection ....179 Multifunction steering wheel, Locator lighting ......147 multifunction display ....102 Radio mode ........179 Headlamp cleaning system ..147 Trip and main odometer Selecting radio mode .....
Page 6 Scanning ......... 185 Switching between Rear window sunshade ....205 name search and Scanning ......... 185 Sun visors ........206 number search ......191 Dolby NR 1 Vanity mirrors ........206 Searching and selecting noise reduction system .... 185 Interior ..........207 phone book entries CD mode ..........
Page 7 Contents Driving Tires ..........265 Brake warning lamp ....288 Snow chains ....... 267 Supplemental restraint Control and operation of system (SRS) indicator lamp ..289 Winter driving radio transmitters .....232 instructions ........ 268 Fuel reserve warning ....290 The first 1 000 miles Deep water ........
Page 8 SEAT BELT SYSTEM ....299 Practical hints Spare wheel ........330 ELEC. STABIL. PROG. Spare wheel bolts .......330 First aid kit ........314 (Electronic stability program) ..300 Changing wheels ......331 Stowing things in the vehicle ..314 COOLANT TIREFIT ...........337 Fuses ..........315 (coolant level) ......301 Tire inflation pressure ....
Page 9 Contents Vehicle care Hard plastic trim items ....371 Index Plastic and rubber parts ....371 Cleaning and care Index ..........389 of the vehicle ......366 Technical data Power washer ......367 Spare parts service ......374 Tar stains ........367 Warranty coverage ......374 Paintwork, painted body Identification labels ......
Page 10: Introduction
Use of such parts and accessories could adversely affect the safety, performance or reliability of your vehicle. Please do not use them. Mercedes-Benz original parts as well as conversion parts and accessories approved by us are available at your authorized Mercedes-Benz Center where you will receive comprehensive information, also on permissible technical modifications, and where proper installation will be performed.
Page 11: Operator's Manual
Ignoring them could result in damage to the vehicle or personal injury to you or others. Vehicle damage caused by failure to follow instructions is not covered by the Mercedes-Benz Limited Warranty. Your vehicle may have some or all of the equipment described in this manual. Therefore, you may find explanations for optional equipment not installed in your vehicle.
Page 12 Mercedes-Benz USA, LLC in writing of the...
Page 13 Introduction Roadside assistance The Mercedes-Benz Roadside Assistance Program provides factory trained technical help in the event of a breakdown. Calls to the toll-free Roadside Assistance number: 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Customer Assistance Representatives 24 hours a day, 365 days a year.
Page 14 • gasoline may have a considerably lower octane rating, and improper fuel can cause engine damage. Certain Mercedes-Benz models are available for delivery in Europe under our European Delivery Program. For details, consult your authorized Mercedes-Benz Center or write to:...
Page 15 If there are any equipment details that are not shown or described in this Operator’s Manual, your authorized Mercedes-Benz Center will be glad to inform you of correct care and operating procedures. The Operator’s Manual and Service Booklet are important documents and should be kept with the vehicle.
Page 16: Where To Find It
Where to find it The Operator’s Manual is divided into eight sections: • Instruments and controls: An overview of all the controls that can be operated from the driver’s seat. • Operation: Information on the vehicle’s equipment and its operation. •...
Page 17 If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is not handled to your...
Page 18: Reporting Safety Defects
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or Mercedes-Benz USA, LLC.
Page 20: Instruments And Controls
Instruments and controls Instruments and controls ....18 Door control panel .......20 Overhead control panel ....21 Dashboard ........22 Center console ......24 Contents - Instruments and controls Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 21: Instruments And Controls
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Instruments and controls P 6 8 . 1 0 - 2 5 9 4 - 2 9...
Page 22 Door control panel, see page 20 Dashboard, see page 22 Overhead control panel, see page 21 Center console, see page 24 Instruments and controls Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 23: Door Control Panel
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Door control panel Door handle, pull to open, see page 37 Memory function (for storing seat, steering wheel and exterior rear view mirror settings), see page 95 Front seat adjustment switch, see page 49 Steering wheel adjustment switch, see page 89 Power window switch, see page 197...
Page 24: Overhead Control Panel
Overhead control panel Interior lighting, see page 203 Tele Aid cover (emergency call system), see page 234 Sliding/pop-up roof, see page 200 Hands-free microphone for Tele Aid and optional telephone with voice recognition system Rear view mirror, see page 90 Garage door opener, see page 226 Instruments and controls Instruments...
Page 25: Dashboard
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Dashboard P 6 8 . 1 0 - 2 5 9 5 - 2 9...
Page 26 Hood lock release, see page 318 Multifunction steering wheel, see page 102 Horn (with electronic key in starter switch Parking brake pedal, see page 260 position 1 or 2) Steering wheel adjustment (manual), see page 88 Instrument cluster, see page 98 Parking brake release, see page 260 Voice recognition system switch, see separate Exterior lamp switch, see page 143...
Page 27: Center Console
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Center console Left front seat heater switch, see page 58 Rear window sunshade switch (optional), see page 205 ESP (electronic stability program) control switch, see page 278 Hazard warning flasher switch, see page 151 Central locking switch, see page 39...
Page 28 Ashtray, see page 213 Storage compartment, see page 209 Automatic transmission, see page 251 Armrest, see page 209 or Manual transmission, see page 249 Storage compartment, see page 215 Instruments and controls Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display...
Page 29 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Contents - Operation Operation Trunk lid emergency release ..43 Airbags ..........73 Trunk lid emergency release ..44 Safety guidelines for the seat Vehicle keys ........28 belt, emergency tensioning Trunk lid release switch ....
Page 30 Malfunction/warning Climate control .......152 Interior ..........207 message memory .......119 Automatic climate control .....160 Storage compartments Individual settings ......121 and armrests ......207 Front center console storage Setting the audio volume ....136 compartment ventilation ..171 Glove box ........208 Coolant temperature gauge ..137 Rear passenger compartment Cup holder ........
Page 31: Vehicle Keys
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Vehicle keys Warning! Included with your vehicle are 2 electronic keys with When leaving the vehicle always remove the integrated radio frequency and infrared remote controls electronic key from the starter switch, and lock plus removable mechanical key.
Page 32 The mechanical key (2) works only in the driver’s door, system requiring a special key manufacturing process. trunk, and glove box lock. For security reasons, replacement keys can only be obtained from your authorized Mercedes-Benz Center. Central locking system Instruments Instrument...
Page 33: Start Lock-Out
Contact an switch. There could be a slight delay until the authorized Mercedes-Benz Center or call 1-800-FOR- electronic key can be turned in the starter switch. MERCedes (in the USA), or 1-800-387-0100 (in Canada).
Page 34: Central Locking System
Central locking system Radio frequency and infrared remote control The electronic key has an integrated radio frequency and infrared remote control. Due to the extended operational range of the remote control, it could be possible to unintentionally lock or unlock the vehicle by pressing the transmit button. If one of the transmit buttons is pressed, the battery check lamp lights up briefly –...
Page 35 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system P 8 0 . 3 0 - 2 1 3 9 - 2 6 P 8 0 . 3 0 - 2 1 4 0 - 2 6 Infrared receiver in driver’s door handle Infrared receiver in front passenger door handle...
Page 36: Locking And Unlocking
Locking and unlocking with remote control If within 40 seconds of unlocking with the remote control, neither door or trunk is opened, the electronic Unlocking: key is not inserted in the starter switch, or the central locking switch is not activated, the vehicle will Press transmit button Œ.
Page 37: Opening The Trunk
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Opening the trunk Important! The trunk lid will swing open automatically. You should Do not place remote control in trunk since trunk is always make sure there is sufficient clearance.
Page 38: Opening And Closing Windows And Sliding / Pop-Up Roof From Outside
Opening and closing windows and To interrupt closing procedure, release transmit button. sliding/pop-up roof from outside Ensure that all side windows and the sliding/pop-up (summer opening/convenience feature) roof are properly closed before leaving the vehicle. Aim transmitter eye of remote control at the door receiver.
Page 39: Panic Button
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Panic button Note: For operation in the USA only: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received,...
Page 40: Doors
Doors Opening – pull handle Individual door from inside: Push lock button down to lock. Unlocking driver’s door Front door from inside: Locking driver’s door Pull handle to unlock. Important! When you lock the driver’s door with the mechanical The mechanical key does not operate the central locking key, the door lock button should move down.
Page 41 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system If the vehicle has previously been locked from the To unlock, pull inside door handles or turn mechanical outside, opening a door from the inside will trigger the key in driver’s door lock to position 2.
Page 42: Central Locking Switch
Central locking switch If the vehicle was previously locked with the central locking switch, while in the global remote control mode, the complete vehicle is unlocked when a door is opened from the inside. Notes: If the vehicle was previously locked with the remote control, the doors and trunk cannot be unlocked with the central locking switch.
Page 43: Automatic Central Locking
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Automatic central locking Important! With the automatic central locking system activated, the When towing the vehicle, or with the vehicle on a doors and trunk are locked at vehicle speeds of dynamometer test stand, please, note the following: approximately 9 mph (15 km/h) or more.
Page 44: Trunk
Trunk The lock is located next to the recessed handle. When the trunk is separately locked, it remains locked when centrally unlocking the vehicle. To deny any unauthorized person access to the trunk, lock it separately with the mechanical key. Leave only the electronic key less its mechanical key with the vehicle.
Page 45 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system P 8 8 . 5 0 - 2 1 2 8 - 2 6 Pull handle (arrow) to open the trunk lid. Lower trunk lid using handle (1) and close it with hands placed flat on trunk lid.
Page 46: Trunk Lid Emergency Release
Trunk lid emergency release Note: (vehicles built prior to September 2001) The emergency release button (1) only unlocks and opens the trunk while the vehicle is not in motion. Important! The emergency trunk lid release button (1) does not open the trunk lid, if the trunk has been locked using the mechanical key or the vehicle battery is discharged or disconnected.
Page 47: Trunk Lid Emergency Release
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Trunk lid emergency release Important! (vehicles built September 2001 and later) The emergency trunk lid release button (1) does not open the trunk lid, if the vehicle battery is discharged or disconnected.
Page 48: Trunk Lid Release Switch
Trunk lid release switch Notes: The trunk can also be opened by using the remote control. Press Š button. The trunk lid cannot be opened by the switch or the remote control when previously locked separately with the mechanical key. To open, see page 41. The trunk lid cannot be opened with the trunk lid release switch when the vehicle was previously locked with the remote control.
Page 49: Antitheft Alarm System
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Antitheft alarm system Antitheft alarm system Operation: Once the alarm system has been armed, the exterior vehicle lamps will flash and an alarm will sound when someone: •...
Page 50: Tow-Away Alarm
Tow-away alarm The alarm will last approximately 3 minutes in form of flashing exterior lamps. At the same time an alarm will sound for 30 seconds. The alarm will stay on even if the vehicle is immediately lowered. To cancel the alarm, insert the electronic key in the starter switch or press button Œ...
Page 51: Easy-Entry/Exit Feature
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Easy-entry/exit feature Easy-entry/exit feature Warning! (only vehicles with memory function) You must ensure that no one can become trapped With the easy-entry/exit feature activated, the steering or injured by the moving steering wheel and the wheel tilts upwards and the driver’s seat moves driver’s seat with the easy-entry/exit feature...
Page 52: Front Seat Adjustment
Front seat adjustment When leaving the vehicle always remove the electronic key from the starter switch, and lock your vehicle. Warning! The power seats can also be operated with the Do not adjust the driver’s seat while driving. driver’s or front passenger door open. Do not leave Adjusting the seat while driving could cause the children unattended in the vehicle, or with access driver to lose control of the vehicle.
Page 53 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Power seat Seat adjustment, fore/aft Press the switch (fore/aft direction) until a comfortable seating position is reached that still allows you to reach the accelerator/brake pedal safely.
Page 54 Storing seat positions: The head restraint, steering wheel and exterior rear view mirror position are stored together with the seat position. See page 95 for notes on the memory function. For recalling a stored seat/head restraint/steering wheel/ and exterior rear view mirror position see page 96. Adjust the head restraint angle by hand.
Page 55 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Manual seat We recommend to adjust the seat in the following order: Fore/aft adjustment Lift handle (1), slide seat to desired position and allow handle to reengage. Check for proper engagement before driving.
Page 56 Head restraint height Head restraint inclination Raising: Push or pull the head restraint in direction of arrow. Pull up on head restraint. Lowering: Push button (5) and push down on head restraint. Adjust head restraint to support the back of the head approximately at ear level.
Page 57 Prior to operating the vehicle, the driver should check Children 12 years old and under must never ride in and adjust if necessary the seat height, seat position the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat,...
Page 58: Removal And Installation Of Front Seat Head Restraints
Removal and installation of front seat head Note: restraints Tilt the backrest rearward for easier removal and installation of the head restraints. Power seat To remove: Press switch (1) upwards and hold until the head restraint is fully extended. Pull head restraint out. To install: Press switch (1) upwards and hold for about 5 seconds.
Page 59 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Manual seat Warning! For your protection, drive only with properly positioned head restraints. Adjust head restraint to support the back of the head approximately at ear level. Do not drive the vehicle without the seat head restraints.
Page 60: Multicontour Seat
Multicontour seat (optional) Some models may be equipped with driver’s multicontour seat. These seats have movable seat cushions and inflatable air cushions built into the backrest to provide additional lumbar and side support. The seat cushion movement and amount of backrest cushion height and curvature can be continuously varied with regulators (1, 2 and 3) after turning the electronic key in starter switch to position 2.
Page 61: Heated Seats
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Heated seats (optional) Press switch to turn on seat heater: Normal seat heating mode. One indicator lamp in the switch lights up. Rapid seat heating mode. Both indicator lamps in the switch light up.
Page 62 Notes: If the blinking of the indicator lamps is distracting to you, the seat heaters can be switched off. When in operation, the seat heater consumes a large amount of electrical power. It is not advisable to use the seat heater longer than necessary. The seat heaters may automatically switch off if too many power consumers are switched on at the same time, or if the battery charge is low.
Page 63: Rear Seat Head Restraints
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Rear seat head restraints Folding head restraints back with switch in the center Folding head restraints back in the rear passenger console: compartment: Turn the electronic key in starter switch to position 1 Push lock button (1).
Page 64 Place head restraints upright Important! For safety reasons, always drive with the rear head restraints in the upright position when the rear seats are occupied. Keep the area around head restraints clear of articles (e.g. clothing) to not obstruct the folding operation of the head restraints.
Page 65 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Head restraint height Raising: Pull up on head restraint. Lowering: Push button (2) and push down on head restraint. Adjust head restraint to support the back of the head approximately at ear level.
Page 66: Seat Belts And Integrated Restraint System
Your vehicle is equipped with seat belts for all seats, Children 12 years old and under must never ride in emergency tensioning retractors for all outboard seat the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, belts, dual front airbags, door mounted side impact...
Page 67: Seat Belt Nonusage Warning System
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Seat belt nonusage warning system Warning! With the electronic key in starter switch position 2, a Never ride in a moving vehicle with the backrest reclined.
Page 68 Warning! Warning! Failure to wear and properly fasten and position Never let more people ride in the vehicle than there your seat belt greatly increases your risk of are seat belts available. Be sure everyone riding in injuries and their likely severity in an accident. the vehicle is correctly restrained with a separate You and your passengers should always wear seat seat belt.
Page 69 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Fastening seat belts The lap belt should be positioned as low as possible on your hips and not across the abdomen. Warning! Always fasten your seat belt before driving off. Always make sure your passengers are properly restrained –...
Page 70 Operation of seat belts The inertia reel stops the belt from unwinding during sudden stops or when quickly pulling on the belt. The locking function of the reel may be checked by quickly pulling out the belt. Adjust seat belt so that shoulder portion is located as close as possible to the middle of your shoulder (it should not touch the neck).
Page 71 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Warning! • Never wear the shoulder belt under your arm, against your neck or off your shoulder. In a USE SEAT BELTS PROPERLY. crash, your body would move too far forward.
Page 72 Position Children 12 years old and under must never ride in shoulder belt across chest and shoulder, not face or the front seat, except in a Mercedes-Benz neck. A booster seat may be necessary to achieve authorized BabySmart compatible child seat, proper belt positioning.
Page 73: Babysmart Tm Airbag Deactivation System
The BabySmart airbag deactivation system will for use with the Mercedes-Benz system and available at ONLY work with a special child seat designed to any authorized Mercedes-Benz Center are required for operate with it. It will not work with child seats which are not BabySmart compatible.
Page 74: Supplemental Restraint System (Srs)
Supplemental Restraint System (SRS) Seat belt fastened • first threshold exceeded: ETR activates Airbags are intended as a supplement to seat belts. Airbags alone cannot protect as well as airbags plus • second threshold exceeded: airbag also activates seat belts in impacts for which the airbags were designed to operate, and do not afford any protection Seat belt not fastened whatsoever in crashes for which the airbags are not...
Page 75: Emergency Tensioning Retractor (Etr)
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Emergency tensioning retractor (ETR) They remove slack from the belts in such a way that the seat belts fit more snugly against the body restricting its The seat belts for the front and rear outer seats are forward movement as much as possible.
Page 76: Airbags
Airbags Driver airbag Front airbags Front passenger airbag The most effective occupant restraint system yet developed for use in production vehicles is the seat belt. In some cases, however, the protective effect of a seat belt can be further enhanced by an airbag. In conjunction with wearing the seat belts, the driver and front passenger airbags can provide increased protection for the driver and front passenger in certain...
Page 77 For your safety, we strongly recommend that you visit an authorized undergo a self-check: crash-sensor(s), airbag ignition Mercedes-Benz Center immediately to have the circuits, front seat belt buckles, emergency tensioning system checked; otherwise the “SRS” may not be retractors, seat sensor.
Page 78 The driver and passenger front airbags are designed to Note: activate only in certain frontal impacts exceeding a Heavy objects on the front passenger seat can appear to preset threshold. The front passenger airbag deploys the “SRS” to indicate the presence of an occupant in only if the front passenger seat is occupied and the that seat which causes the passenger front airbag to ü...
Page 79 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Side impact airbags, window curtain airbags The side impact airbag for the front passenger deploys only if the front passenger seat is occupied. Side impact airbags operate best in conjunction with a properly positioned and fastened seat belt.
Page 80 To provide continued reliability after that date, they should be inspected by an authorized Mercedes-Benz Center at that time and replaced when necessary. Restraint systems Instruments...
Page 81 Mercedes-Benz Center. passenger to always be in a properly seated • Do not lean with your head or chest close to the position and to wear your seat belt.
Page 82 BabySmart will not, however, turn Mercedes-Benz authorized Baby Smart off the vehicle’s side impact airbag. compatible child seat, which operates with the It should be noted that with respect to both front...
Page 83 This could result in serious accomplished upon your written election to do so at injuries or death should the side airbag be your authorized Mercedes-Benz Center at an activated; (2) always sit upright, properly use the additional cost. Please contact your local...
Page 84: Safety Guidelines For The Seat Belt, Emergency Tensioning Retractor And Airbag
Use only belts installed or supplied by an electronic equipment on or near “SRS” authorized Mercedes-Benz Center. components and wiring. Keep area between • Airbags and “ETR’s” are designed to function airbags and occupants free from objects (e.g.
Page 85 Work notice to the subsequent owner that it is equipped with on the “SRS” must therefore only be performed an “SRS” by alerting them to the applicable section in by an authorized Mercedes-Benz Center. the Operator’s Manual.
Page 86: Infant And Child Restraint Systems
Infant and child restraint systems Important! We recommend all infants and children be properly The use of infant or child restraints is required by law in restrained at all times while the vehicle is in motion. All all 50 states and all Canadian provinces. lap-shoulder belts except the driver seat belt have Infants and small children should be seated in an special seat belt retractors for secure fastening of child...
Page 87 During an Children 12 years old and under must never ride in accident, they could be crushed between the the front seat, except in a Mercedes-Benz occupant and seat belt. authorized BabySmart compatible child seat,...
Page 88 Installation of infant and child restraint systems This vehicle is provided with tether anchorages for a top To secure a tether strap to the anchorage, securely tether strap at each of the rear seating positions. fasten the hook (3), which is part of the tether strap, to the anchorage ring (2).
Page 89 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Child seat mounts - “LATCH” type To install a “LATCH” type child seat, the mounts (1) must be folded forward until they lock in place. To do so, grip inner side of mounts and fold forward.
Page 90 Warning! Damaged or impact damaged child seats or child seat mounting fittings must be replaced. The “LATCH” mounting fittings are intended for children up to 22 kg (50 lbs) in weight. Do not leave children unattended in the vehicle, even if the children are secured in a child restraint Children too big for child restraint systems must system.
Page 91: Steering Wheel Adjustment (Manual)
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Steering wheel adjustment (manual) Unlocking: Pull handle (1) out to its stop. Adjusting: Move steering wheel to the desired position. Locking: Push handle (1) in until it engages. Important! Do not drive the vehicle until you have properly locked the steering column.
Page 92: Steering Wheel Adjustment (Electrical)
Steering wheel adjustment (electrical) (optional on model C 240) Warning! Do not adjust the steering wheel while driving. Adjusting the steering wheel while driving could cause the driver to lose the control of the vehicle. When leaving the vehicle always remove the electronic key from the starter switch and lock your vehicle.
Page 93: Rear View Mirrors
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Rear view mirrors Rear view mirrors Note: The automatic antiglare function does not react, if incoming light is not aimed directly at sensors in the Inside rear view mirror mirror.
Page 94 Exterior rear view mirrors Exterior rear view mirror adjustment Turn the electronic key in starter switch to position 1 or 2. Push button to select mirror to be adjusted: Driver’s side – Push button (1). Passenger side – Push button (2). Push the adjustment button (3) up, down, left or right according to the setting desired.
Page 95 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Rear view mirrors Parking position exterior rear view mirror Note: (only vehicles with memory function) For activating the mirror adjustment, see under individual setting menu “CONVENIENCE” – “MIRROR The passenger side exterior mirror can be adjusted and SETTING WHEN PARKING”, on page 134.
Page 96 To store passenger mirror parking position: Note: One stored parking position is available for each of the 1. The vehicle must be stationary. two electronic keys. Turn the electronic key in starter switch to This is only possible if you select “ON” in the menu position 1 or 2.
Page 97 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Rear view mirrors Driver’s side exterior rear view mirror, Warning! antiglare mode In the case of an accident liquid electrolyte may With the electronic key in starter switch position 2, the escape the mirror housing when the mirror glass breaks.
Page 98 Memory function Warning! (model C 320 only, optional on model C 240) Do not activate the memory function while driving. Activating the memory function while driving could cause the driver to lose control of the vehicle. Together with the driver’s seat position you can store the positions for steering wheel and exterior rear view mirrors.
Page 99 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Memory function Storing positions into memory: Recalling positions from memory: With the electronic key in starter switch position 1 or 2 To recall a seat /steering wheel/exterior rear view or with the relevant door open and the electronic key mirror position, turn button (2) to selected memory inserted in the starter switch.
Page 100 Prior to operating the vehicle, the driver should check Children 12 years old and under must never ride in and adjust if necessary the seat height, seat position the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat,...
Page 101: Instrument Cluster
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instrument cluster Instrument cluster...
Page 102 Knob for instrument cluster illumination, Indicator lamp without function. It illuminates with see page 100 the electronic key in starter switch position 2. It Reset knob for trip odometer, see page 101 and should go out when the engine is running. individual settings, see page 121 Multifunction display, see page 102.
Page 103 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instrument cluster Activating instrument cluster display Display illumination, changing basic settings for driving at dusk or in darkness: The instrument cluster is activated by: Rotate adjusting knob (1) clockwise – instrument lamp •...
Page 104 (e.g. bank signs etc.). engine damage that is not covered by the Adaption to ambient temperature takes place in steps Mercedes-Benz Limited Warranty. and depends on the prevailing driving conditions (stop- To help protect the engine, the fuel supply is interrupted and-go or moderate, constant driving) and amount of if the engine is operated within the red marking.
Page 105: Multifunction Steering Wheel, Multifunction Display
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Multifunction steering wheel, multifunction display P 5 4 . 3 0 - 4 4 5 2 - 2 9...
Page 106 Depending on your vehicle’s equipment, you may use Navigation system, see page 116 the buttons on the multifunction steering wheel to call Malfunction message memory, see page 119 up, control and set the following systems in the multifunction display: Individual settings, see page 121 Trip computer, see page 117 Trip odometer and main odometer, see page 101 and page 106...
Page 107 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Note: Warning! The displays in the multifunction display can be set to A driver’s attention to the road must always be his/ German, English, French, Italian or Spanish language.
Page 108 Press button: è for next system ÿ for previous system j for next display in system k for previous display in system æ to increase the volume, see page 136 ç to decrease the volume, see page 136 í to dial a telephone number, see page 111 ì...
Page 109: Trip And Main Odometer And Sub Menu
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Trip and main odometer and sub menu P 5 4 . 3 0 - 4 4 5 3 - 2 9...
Page 110 Press è or ÿ button repeatedly until the trip Trip odometer and main odometer See page 101 for instructions on resetting the trip odometer and main odometer display (1) appears. odometer. Press the j or k button repeatedly until the Coolant temperature gauge, see page 137 required display (2, 3, 4, 5, 1) appears.
Page 111: Audio Systems
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Audio systems Audio system is switched off. Radio The radio is switched on. Wave band setting and memory location number, where appropriate.
Page 112: Cd Player
CD player Radio system is switched off. The CD player is switched on. The number of the CD currently playing is displayed if you are using a CD changer. Track number. “TITLE” appears on vehicles with COMAND system. “TRACK” appears on vehicles with audio system. The radio must be switched on.
Page 113: Cassette Player
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Cassette player Audio system is switched off. The cassette player is switched on. Side being played. The radio must be switched on. The cassette player must be switched on.
Page 114: Telephone
Telephone The telephone is switched off. Telephone book The vehicle is currently outside the transmitter or receiver range. The telephone is ready for use. Name selected from the telephone book. Number for the name selected. The dialing commences. Dialing is completed. The name is displayed. The display remains for the duration of the call.
Page 115 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the í button when the name you require The telephone must be switched on. appears in the display (4). The telephone number (5) is Press the è...
Page 116 Redialing The telephone is ready for use. Number or name stored in the redial memory. Number in the redial memory — redialing has commenced. Dialing is completed and the name stored in the telephone book is displayed or the number dialed will remain displayed if no name has been store.
Page 117 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the í button when the required number or The telephone must be switched on. name appears in the display (2). Press the è...
Page 118 Press the í button to answer the call. Incoming call Press the ì button to hang up or if you do not wish to answer the incoming call. The telephone must be switched on. “CALL” — you are being called. Signal strength: Vehicles with audio system (in top right corner): the higher the number, the stronger the phone...
Page 119: Navigation System
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Navigation system The navigation system is switched off. The navigation system is switched on but no destination has been specified. The navigation system is switched on and destination guidance is active.
Page 120: Trip Computer
Trip computer “AFTER START” — short distance memory “AFTER RESET” — long distance memory Estimated range remaining Distance covered “AFTER START” or “AFTER RESET” Elapsed time “AFTER START” or “AFTER RESET” Average speed “AFTER START” or “AFTER RESET” Average fuel consumption “AFTER START” or “AFTER RESET”...
Page 121 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display To reset the short “AFTER START” (1) or long Note: “AFTER RESET” distance memory (2): The “AFTER START” trip odometer reading is Call up the relevant display (1 or 2) using the j or automatically reset after four hours of electronic key not k button and press the reset knob on the instrument...
Page 122: Malfunction/Warning Message Memory
Malfunction/warning message memory There are no messages stored in the system. Number of messages stored in the system. There are messages stored in the system. Press the è or ÿ button repeatedly until the message memory (1 or 2) is displayed. Press the j or k button if display (2) appears.
Page 123 Mercedes-Benz Center to address the malfunction and warning messages. See page 293, for malfunction and warning messages.
Page 124: Individual Settings
Individual settings Preliminary display of the individual settings. “SETTINGS” – the requested menu can be called up in this options menu: “INSTRUMENT CLUSTER”, see page 124. “LIGHTING”, see page 128. “VEHICLE”, see page 131. “CONVENIENCE”, see page 134. The four menus contain additional submenus. Individual settings can be selected in these submenus.
Page 125 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the è or ÿ button repeatedly until the Note: individual setting preliminary display (1) appears. These settings may only be performed with the Press the j or k button until the setting menu electronic key in starter switch position 1 or 2.
Page 126 To return menu “SETTINGS” (2) to its factory Note: setting: For safety reasons, the individual setting “LIGHT CIRCUIT HEADLAMP MODE” in menu “LIGHTING” • Call up the individual setting preliminary display (1) or display (2). cannot be reset while driving, see page 130. If an attempt is made, the message “LIGHTING”...
Page 127 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display “INSTRUMENT CLUSTER” P 5 4 . 3 0 - 4 4 5 5 - 2 9...
Page 128 Preliminary display of the individual settings “SELECT DISPLAY” – The selection “SPEED DISP.” respectively “OUTSIDE TEMPERATURE” is “SETTINGS” – the individual setting menu permanently displayed in the multifunction display. “INSTRUMENT CLUSTER” can be called up in this “SPEED DISP.” can be used to display, for instance, options menu.
Page 129 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the è or ÿ button repeatedly until the Press the j or k button until the required individual setting preliminary display (1) appears. display (3 to 9) is displayed.
Page 130 To return menu “INSTRUMENT CLUSTER” (5 to 9) to its factory setting: • Call up one of the setting menus(3 to 9). • Press the reset knob on the instrument cluster, see page 98, for approximately 3 seconds. Display (10) will appear.
Page 131 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display “LIGHTING” P 5 4 . 3 0 - 4 4 5 6 - 2 9...
Page 132 Press the è or ÿ button repeatedly until the Preliminary display of the individual settings individual setting preliminary display (1) appears. “SETTINGS” – in this options menu you can call up Press the j or k button until the setting menu the individual setting menu “LIGHTING”.
Page 133 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display To return menu “LIGHTING” (3 to 6) to its factory Note: setting: For safety reasons, the individual setting “LIGHT CIRCUIT HEADLAMP MODE” in menu “LIGHTING” •...
Page 134 “VEHICLE” (audio and central locking system) P 5 4 . 3 0 - 4 4 5 7 - 2 9 Multifunction steering wheel, multifunction display Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 135 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the è or ÿ button repeatedly until the Preliminary display of the individual settings individual setting preliminary display (1) appears. “SETTINGS”...
Page 136 To return menu “VEHICLE” (3 and 4) to its factory setting: • Call up menu (3 or 4). • Press the reset knob on the instrument cluster (see page 98) in the instrument cluster for approximately 3 seconds. Display (5) will appear. •...
Page 137 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display “CONVENIENCE” (vehicles with memory function) P 5 4 . 3 0 - 4 4 5 8 - 2 9...
Page 138 Press button æ or ç until the individual setting Preliminary display of the individual settings menu “CONVENIENCE” is selected by the selection “SETTINGS” – in this options menu you can call up marker. the individual setting menu “CONVENIENCE”. Press the j or k button until the required Pressing button æ...
Page 139: Setting The Audio Volume
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display To return menu “CONVENIENCE” (3 to 5) to its Setting the audio volume factory setting: You can only adjust the volume of the system currently in use.
Page 140: Coolant Temperature Gauge
The engine should not be operated with the coolant temperature above 120 ° C. Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Warning! • Driving when your engine is badly overheated can cause some fluids which may have leaked into the engine compartment to catch fire.
Page 141: Flexible Service System (Fss)
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Flexible service system Flexible service system (FSS) The message is displayed for approximately 10 seconds (service indicator) when turning the electronic key in starter switch to position 2, or while driving when reaching the service warning threshold.
Page 142 FSS can be added by your Calling up service indicator manually: Mercedes-Benz Center. Turn the electronic key in starter switch to position 1 The interval between services is determined by the type or 2.
Page 143 Flexible service system Following a completed A or B service the Mercedes-Benz The multifunction display will show the question: Center sets the counter mileage to 10 000 miles “DO YOU WANT TO RESET SERVICE INTERVAL? –...
Page 144: Engine Oil Level Indicator
Engine oil level indicator • with engine not at operational temperature up to approximately 30 minutes. The engine oil level check can be repeated after a short time. Turn the electronic key in starter switch to position 2. To call up the trip odometer and main odometer, press button è...
Page 145: Engine Oil Consumption
During the break-in period, cause damage to the engine and catalytic converter not higher oil consumption may be noticed and is normal. covered by the Mercedes-Benz Limited Warranty. Frequent driving at high engine speeds results in increased consumption.
Page 146: Exterior Lamp Switch
ˆ Standing lamps, right (turn left one stop) Exterior lamp switch ‚ Standing lamps, left (turn left two stops) ‡ Front fog lamps (pull out one stop) with parking lamps and/or low beam headlamps on. Green indicator in lamp switch comes on. †...
Page 147: Headlamp Mode
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamp switch Headlamp mode Automatic headlamp mode Turn exterior lamp switch to position U. Manual headlamp mode • Electronic key in starter switch position 1: The low beam headlamps and parking lamps can be switched on and off with the exterior lamp switch.
Page 148 Daytime running lamp mode • USA only: The high beam headlamps can also be activated Turn exterior lamp switch to position M or U. when driving with the daytime running lamp mode When the engine is running, the low beam headlamps activated and exterior lamp switch in position M.
Page 149: Night Security Illumination
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamp switch Night security illumination Notes: Within 10 minutes after closing the last door the night At low ambient light conditions and with the engine security illumination can be reactivated by opening a having been switched off, the exterior lamps (fog lamps door.
Page 150: Locator Lighting
Locator lighting Headlamp cleaning system After unlocking the vehicle with the electronic key during darkness the fog lamps and parking lamps switch for approximately 40 seconds. The exterior lamps will be switched off when opening the driver’s door. See the individual setting menu “LIGHTING” – “LOCATOR LIGHTING”...
Page 151: Combination Switch
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Combination switch Combination switch To signal minor directional changes, such as changing lanes on a highway, move combination switch briefly to the point of resistance only and release. The turn signals blink three times.
Page 152 Intermittent wiping Vehicles with optional rain sensor: One initial wipe, pauses between wipes are automatically controlled by a rain sensor monitoring the wetness of the windshield. This will not occur with a front door open. Notes: With switch in this position, one wipe occurs when turning the electronic key in starter switch from position 0.
Page 153 I or III, turn combination switch to wiper setting II. Have the system checked at your authorized For temperatures above freezing: Mercedes-Benz Center as soon as possible. MB Windshield Washer Concentrate “S” and water. 1 part “S” to 100 parts water (40 ml “S”...
Page 154: Hazard Warning Flasher Switch
Hazard warning flasher switch To activate hazard warning flasher, press switch once. To deactivate, press switch again. If hazard warning flasher was activated automatically, press switch twice to deactivate. Note: With the hazard warning flasher activated, the combination switch in position for either left or right turn, and the electronic key in starter switch position 1 or 2, only the respective left or right side turn signals will operate.
Page 155: Climate Control
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Climate control Climate control (model C 240) P 6 8 . 1 0 - 2 1 6 4 - 2 9...
Page 156 Display and controls Air volume control for right center air outlet Air volume control for left center air outlet Air volume control and air outlet on dashboard top center Center air outlet, left, adjustable Air volume control for side air outlet Thumbwheel for adding outside air at air outlets for center, left and right sides, as well as dashboard top Side air outlet, adjustable...
Page 157 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Climate control Display and controls Rear window defroster, see page 170 Economy mode, see page 159 Residual engine heat utilization, see page 159 Air distribution and air volume (automatic) Air recirculation, see page 167 Defrosting, see page 157 Important!
Page 158 Economy mode S cannot be switched off. Have The desired interior temperature can be selected the air conditioner checked by a Mercedes-Benz Center separately for the left and right side of the passenger should this happen.
Page 159 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Climate control Basic setting – automatic mode Special settings (use only for short duration) In the automatic mode the climate control cools or heats Air distribution and air volume, manual the interior depending on outside temperature and the Press U button.
Page 160 Defrosting Windows fogged up on the inside Press the P button. The indicator lamp in the button Switch off the economy mode, if selected. Press illuminates. button S. The indicator lamp in the button will go out. Switch off air recirculation, if selected. Press button O, the indicator lamp in the button will go Switch off air recirculation, if selected.
Page 161 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Climate control Air recirculation Switching off air recirculation and activating convenience opening: Select air recirculation: The indicator lamp in the O button is illuminated. The indicator lamp in the O button is not Press button O for more than 2 seconds, the side illuminated.
Page 162 Economy mode Residual engine heat utilization The function of this setting corresponds to the With the engine switched off, it is possible to continue to heat or ventilate the interior for a short while, automatic mode. However, because the air conditioning compressor will not engage (fuel savings), it is not dependent of the temperature setting of the automatic possible to air condition in this setting.
Page 163: Automatic Climate Control
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Automatic climate control (optional on model C 240) P 8 3 . 2 0 - 2 1 4 4 - 2 9...
Page 164 Display and controls Air volume control for right center air outlet Air volume control for left center air outlet Air volume control and air outlet on dashboard top center Center air outlet, left, adjustable Air volume control for side air outlet Thumbwheel for adding outside air at air outlets for center, left and right sides, as well as dashboard top Side air outlet, adjustable...
Page 165 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Display and controls Temperature control, right, raising Temperature control, right, lowering Rear window defroster, see page 170 Economy mode, see page 169 Residual engine heat utilization, see page 169 Air volume control + switch on system...
Page 166 Automatic climate control The system is always at operational readiness, except when manually switched off. The automatic climate control only operates with the engine running. The temperature selector should be left at the desired temperature setting. The temperature selected is reached as quickly as possible.
Page 167 The automatic blower will be activated place. Economy mode S cannot be switched off. Have at the same time. the air conditioner checked by a Mercedes-Benz Center should this happen. We recommend to set the temperature switches on the left and right to 72 °...
Page 168 Special settings (use only for short duration) Air volume, manual Seven blower speeds are available. Air distribution, manual Press right Q or left M side of air volume control Press left or right U button. The button pops out, the switch until the requested blower speed is attained.
Page 169 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Defrosting Windows fogged up on the inside Press the P button. The indicator lamp in the button Switch off the economy mode, if selected: illuminates.
Page 170 Air recirculation Switching off air recirculation and activating convenience opening: Select air recirculation: The indicator lamp in the button O is illuminated. The indicator lamp in the button O is not Press button O for more than 2 seconds, the side illuminated.
Page 171 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Activated charcoal filter The activated charcoal filter should be switched off when windows fog up on the inside, or if the passenger An activated charcoal filter markedly reduces bad odors compartment needs to be quickly heated or cooled and removes pollutants from air entering the passenger...
Page 172 Economy mode To switch the automatic climate control on again, press the U or P button, or set air volume control The function of this setting corresponds to the switch to any speed. automatic mode. However, because the air conditioning compressor will not engage (fuel savings), it is not possible to air condition in this setting.
Page 173 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Rear window defroster The rear window defroster uses a large amount of power. To keep the battery drain to a minimum, turn off the Turn the electronic key in starter switch to position 2.
Page 174: Front Center Console Storage Compartment Ventilation
Front center console storage compartment The air volume is dependent on the setting of: ventilation • air distribution control, • air volume control, • air outlets in the dashboard. The air temperature is about the same as that of the dashboard air outlets.
Page 175: Rear Passenger Compartment Adjustable Air Outlets
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Rear passenger compartment adjustable air outlets Center air outlet, left Air volume control for center air outlets To open: Turn the wheel upward. Center air outlet, right Note: The temperature at the air outlets for the rear passenger...
Page 176: Operation Audio And Telephone
Audio and telephone operation Operating safety These instructions are intended to help you become Warning! acquainted with your Mercedes-Benz audio system. They contain useful tips and a detailed description of Any alterations made to electronic components can the user functions.
Page 177: Operating And Display Elements
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Operating and display elements On/off, volume, see page 176 Radio mode selector, see page 179 Telephone mode selector, see page 190 Manual tuning, see page 180 and 180 Fast Forward/Reverse (tape), see page 184 Seek tuning, see page 180, Fast Forward/Reverse (CD), see page 189...
Page 178 Display panel Scan tuning (Radio, see page 180) The cassette slot is located behind the display panel. Tape track search, see page 184 For notes on playing cassettes, see page 182 CD, see page 180 Alpha-numeric keypad for Function button, see page 182 and 190 station storage and frequency entry, see page 182 Soft keys for optional telephone, see page 190...
Page 179: Button And Soft Key Operation
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Button and soft key operation Operation In these instructions, the alpha-numeric keypad (right side of radio face) and the function buttons (left side of Switching on and off the radio face) are referred to as “buttons”...
Page 180: Adjusting The Volume
Adjusting the volume Bass Turning the control knob clockwise will increase the Press the “AUD” key volume, counterclockwise will decrease the volume. repeatedly until “BASS” appears on the display. Note: Press the “+” key to increase The volume setting can be selected separately for the or the “-”...
Page 181: Balance
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Fader Centering all audio functions Press the “AUD” key Push and hold down the repeatedly until “FADER” “AUD” key. All audio appears on the display. Press functions (bass, treble, the “R”...
Page 182: Audio System Tone Level Selection
Audio system tone level selection Radio mode To select the tone level settings for radio, cassette, Selecting radio mode and CD operation press the Press button. key “AUD”. The tone level settings menu is now displayed. Press key “EXT”, and “SOUND” appears on Selecting the band the display.
Page 183: Manual Tuning
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Manual tuning Seek tuning Press either the Press either the button. The radio will tune button. Step-by-step station to the next receivable station. tuning in ascending or descending order of Scan tuning...
Page 184: Weather Band
Weather Band Storing stations automatically (Autostore) Press the “WB” key. The last weather band station is Press the “AS” key until the tuned in. word “SEARCH” is displayed. The ten strongest stations are Use buttons to select a different station. If P Q R S stored automatically, with the station cannot be received, the next available station...
Page 185: Storing Stations
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Storing stations Cassette mode Hold the desired number button down for O P R approximately 2 seconds. The currently displayed Playing cassettes frequency is stored on the selected station button. The Press the T A P E button.
Page 186: Cassette Eject
The system will switch to Cassette eject cassette mode. Track 1 will be Press the button. The display will fold down and played and “SIDE 1” the cassette will be ejected. Remove the cassette, then displayed. Track 1 is the side fold the display back up manually.
Page 187: Track Selection
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Track selection Note: The beginning of a track can only be located if there is a Press the track selection break of at least 4 seconds between tracks. “TRK”...
Page 188: Scanning
Scanning Dolby NR (noise reduction system) Press the button. “SEEK To enable optimum sound FWD” will appear on the reproduction of cassettes display. Each track will be recorded using the Dolby B played for 8 seconds in system, press the “NR” key so ascending order.
Page 189: Cd Mode
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system CD mode Only use CDs, which bear the label shown and that conform to the compact disc digital audio General notes on CD mode standard (IEC 60908).
Page 190: Cd Changer Installed
CD changer installed Loading/emptying the CD magazine Slide the changer door to the right until it latches open and press the eject button . The magazine will be ejected. Remove the magazine. Pull out the CD tray to its stop and place the CDs in the recess of the tray, label side up.
Page 191: Playing Cds
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Playing CDs Skipping tracks forward/backward Press the button. When the changer is used for the Press the button. The next track on the CD will be first time after removing/inserting a magazine, play played.
Page 192: Fast Forward/Reverse
Fast forward/reverse Random play/repeat function Press and hold the button for audible fast forward. The tracks of the current CD are played in random order when the random feature (RDM) is selected. Press the Press and hold the button for audible reverse. “RDM”...
Page 193: Direct Track Selection
Audio system Direct track selection Telephone operation Various functions of the Mercedes-Benz integrated Tracks can be selected directly using the buttons on the alpha-numeric keypad. Press the “ function button, portable cellular telephone can be performed and displayed via the system.
Page 194: Adjusting The Volume
Adjusting the volume Calling up the telephone book Turning the control knob clockwise will increase the The numbers stored in the telephone number memory volume, counterclockwise will decrease the volume. can be called up via either name or number entries. The memory contents from the portable telephone must Note: contain numbers and names in at least one memory...
Page 195: Searching And Selecting
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Searching and selecting telephone book entries by Searching and selecting telephone book entries by name number Press the “ABC” key. The Press the “NUM” key. The current name is shown on the current number is shown on display.
Page 196: Manual Repeat Dialing (Redial)
Manual repeat dialing (redial) Abbreviated dialing from previously stored telephone numbers The last number entered can be re-selected by pressing the “SND” key once, and the call can be placed by Quick-dialing pressing the “SND” key a second time. The last dialed telephone number is shown on the display.
Page 197: Turbo-Dialing
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Express-dialing Accepting incoming call in telephone mode Press one of the number buttons for more With an incoming call, a O P R than 1 second.
Page 198: Terminating Call
Failure of one of the components can lead to malfunctions of the other components. Please contact Muting a call your authorized Mercedes-Benz Center or call the Pressing the “MUT” key will Mercedes-Benz Customer Assistance Center (in the silence the call. The caller can USA) at1-800-FOR-MERCedes, or Customer Service (in no longer hear you.
Page 199 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Emergency call Emergency calls may not be possible with all telephone networks or if certain network services and/or Important! telephone functions are active. Check with your local network operating company.
Page 200: Power Windows
Power windows Switches for: left, front right, front left, rear right, rear There are individual switches in the front passenger door and the rear doors for the respective windows. Turn electronic key in starter switch to position 1 or 2. Opening the windows: Press the switch to resistance point.
Page 201 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Express opening and closing Warning! Press or pull switch past resistance point and release – When closing the windows, be sure that there is no window opens or closes completely.
Page 202 Blocking of rear door window operation Synchronizing power windows If the power supply was interrupted, (battery disconnected or low), the windows cannot be opened or closed by the express feature. To resynchronize the express feature, pull switch until the window is completely closed and hold for approximately 1 second.
Page 203: Sliding/Pop-Up Roof
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Sliding/pop-up roof Turn the electronic key in starter switch to position 1 or 2. To open, close, raise or lower the sliding/pop-up roof: Move the switch to resistance point in the required direction.
Page 204 Opening or closing the sliding/pop-up roof With the roof closed or tilted open, a screen can be slid automatically into the roof opening to guard against sun rays. When sliding the roof open, the screen will also retract. Move the switch past resistance point in the direction required and release.
Page 205 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Synchronizing the sliding/pop-up roof The sliding/pop-up roof must be resynchronized if the power supply has been interrupted (battery disconnected or low), the sliding/pop-up roof has been closed manually or the sliding/pop-up roof does not open smoothly or malfunctions.
Page 206: Interior Lighting
Interior lighting The interior lighting remains switched off, even when centrally unlocking the vehicle or opening a door or the electronic key is removed from the starter switch. To select automatic function: Press the rocker switch to the center position. Interior lamps are switched on in darkness, when unlocking the vehicle, opening a door or removing the electronic key from starter switch.
Page 207 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Notes: Door entry lamps The time delay for the interior light to switch off after The appropriate entry lamp switches on if a door is the electronic key is removed from the starter switch opened in darkness and if the interior lighting is can be adjusted in the individual setting menu...
Page 208: Rear Window Sunshade
Rear window sunshade (optional) Always raise the sunshade fully for its support against the window frame. Warning! When operating the rear window sunshade, be sure that there is no danger of anyone being harmed by the raising or lowering procedure. The raising or lowering procedure can be immediately halted by briefly pressing the upper or lower half of the switch.
Page 209: Sun Visors
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Sun visors Vanity mirrors Illuminated vanity mirror Swing sun visors (2) down (arrow 3) to protect against sun glare. With the visor engaged in its inner mounting (2), If sunlight enters through a side window, disengage sun the lamp (4) can be switched on by opening the visor (2) from the inner mounting (1) and pivot to the...
Page 210: Interior
Interior Storage compartments and armrests Warning! Warning! To help avoid personal injury during a collision or Keep compartment lids closed. This will help to sudden maneuver, exercise care when stowing prevent stored objects from being thrown about things. Put luggage or cargo in the trunk if and injuring vehicle occupants during an accident.
Page 211: Glove Box
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Glove box Notes: Prior to closing the glove box, close the compartment for glasses first. The glove box can be locked and unlocked with the mechanical key.
Page 212 Storage compartment in front of armrest To open: Slide cover (5) rearward. To close: Slide cover (5) forward. Note: The compartment contains a lighter (see page 215), a coin holder, and a cup holder (see page 211). Storage compartment in front of armrest Interior equipment Instruments Instrument...
Page 213 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Storage compartment below the front armrest To change inclination of armrest: Pull up on armrest. To lower armrest: Pull handle (7). Notes: The storage compartment can be heated or cooled, see page 171.
Page 214: Cup Holder
Cup holder P 6 8 . 0 0 - 2 7 1 5 - 2 6 P 6 8 . 0 0 - 2 7 1 5 - 2 6 Cup holder in front seat armrest Close cup holder: Push (arrow) until cup holder engages. Open cup holder: Push button (1) the cup holder slides out.
Page 215 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment To open: Push front of sliding compartment – the cup holder slides out. To close: Push the sliding compartment back until it engages. Warning! Keep the cup holder closed while traveling.
Page 216: Ashtrays
Ashtrays Center console To open: Briefly touch the mark on the cover, the ashtray opens automatically. To remove ashtray insert from center console: Warning! Remove front ashtray only with vehicle standing still. With the gear selector lever in position “N”, turn off the engine and set the parking brake.
Page 217 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Rear seats To open ashtray: Pull at top of cover. To remove insert: Press latch (2) and remove insert. To replace insert: Install insert and close the ashtray.
Page 218: Lighter
Lighter Turn the electronic key in starter switch to position 1 or 2. Push in lighter in (1); it will pop out automatically when hot. Warning! Never touch the heating element or sides of the lighter, they are extremely hot, hold at knob only. When leaving the vehicle always remove the electronic key from the starter switch.
Page 219: Parcel Net In Front Passenger Footwell
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Parcel net in front passenger footwell Ski sack (optional) A small convenience parcel net is located in the front passenger footwell. It is for small and light items, such as road maps, mail, etc.
Page 220 3. Open hook and loop strap (2) and pull ski sack into 4. Open flap in trunk by pulling handle (3). passenger compartment and unfold. Interior equipment Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 221 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment 6. Wrap strap around ski sack and armrest. 5. From trunk, slide skis into ski sacks 7. Close clasp (arrows 4 and 5) and pull strap tight to Warning! immobilize skis.
Page 222 8. Connect snap hook (6) of front strap to eye (7) Unloading and folding located on center tunnel in front of rear seat bench. 1. Loosen strap, open clasp by pressing tabs (arrows) together, and unload skis. 2. Close flap in trunk. 3.
Page 223 Interior equipment Removal of ski sack For removal of the ski sack we recommend that you contact an authorized Mercedes-Benz Center. Warning! Never drive vehicle with trunk lid open while the ski sack is removed. Deadly carbon monoxide (CO) gases may enter vehicle interior resulting in unconsciousness and death.
Page 224: Enlarged Cargo Area
Enlarged cargo area (optional) Split folding rear seat bench 2. Pull handle (2) and fold seat cushion (3) forward. 1. Pull handle (1) located in trunk to unlock backrest. 3. Fully retract and fold down head restraints, see On vehicles with optional split folding rear seat backrest page 60.
Page 225 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Setting up rear seat bench 1. Pull backrest (4) up until it locks in its upright Warning! position. Check for secure locking by pushing and Always lock backrest in its upright position when pulling on the backrest.
Page 226: Loading Instructions (Vehicle With Enlarged Cargo Area)
Loading instructions The handling characteristics of a fully loaded vehicle (Vehicle with enlarged cargo area) depend greatly on the load distribution. It is therefore recommended to load the vehicle according to the illustrations shown, with the heaviest items being placed towards the front of the vehicle. Always place items being carried against front or rear seat backrests, and fasten them as securely as possible.
Page 227: Cellular Telephone
In an accident, during hard braking or sudden maneuvers, loose items will be thrown around telephone. For further information and installation inside the vehicle and can cause injury to vehicle contact your authorized Mercedes-Benz Center. occupants unless the items are securely fastened in the vehicle. Warning!
Page 228: Telephone, General
Telephone, general Bear in mind that at a speed of just 30 mph (approximately 50 km/h), your vehicle is covering a distance of approximately 50 feet (approximately Warning! 14 m) every second. A driver’s attention to the road must always be his/ Never operate radio transmitters equipped with a her primary focus when driving.
Page 229: Garage Door Opener
If you should experience difficulties with programming the transmitter, contact Signal transmitter keys your authorized Mercedes-Benz Center, or call Mercedes-Benz Customer Assistance Center (in the USA Indicator lamp only) at 1-800-FOR-MERCedes, or Customer Service (in Portable remote control transmitter...
Page 230 For operation in the USA only: This device complies Programming or reprogramming the integrated with Part 15 of the FCC Rules. Operation is subject to remote control: the following two conditions: 1. Turn electronic key in starter switch to position 1 (1) This device may not cause harmful interference, and or 2.
Page 231 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Garage door opener 3. Using both hands, simultaneously push the hand- Rolling code programming: held transmitter button and the desired integrated To train a garage door opener (or other rolling code remote control button.
Page 232 3. Firmly press and release the programmed Operation of remote control: integrated remote control transmit button. Press 1. Turn electronic key in starter switch to position 1 and release same button a second time to complete or 2. the training process. (Some garage door openers may required you to do this procedure a third time 2.
Page 234 Driving Driving instructions ...... 261 Cruise control .........272 Drive sensibly – Save Fuel ..261 Brake assist system (BAS) ....275 Control and operation of Drinking and driving ....261 Antilock brake system radio transmitters .....232 (ABS) ........... 276 Pedals .......... 261 The first 1 000 miles Electronic stability program Power assistance ......
Page 235: Control And Operation Of Radio Transmitters
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Control and operation of radio transmitters Control and operation of radio transmitters COMAND, radio and telephone Telephones and two-way radio Warning! Warning! Please do not forget that your primary Never operate radio transmitters equipped with a responsibility is to drive the vehicle.
Page 236: The First 1 000 Miles (1 500 Km)
We strongly recommend that you have your vehicle break-in period, the more satisfied you will be with its serviced by your authorized Mercedes-Benz Center, in performance later on. Therefore, drive your vehicle accordance with the Service Booklet at the times called during the first 1 000 miles (1 500 km) at moderate for by the FSS.
Page 237: Tele Aid
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tele Aid Tele Aid The speaker volume of a Tele Aid call can be adjusted when using the volume control on the multifunction steering wheel, for raising press button æ and for Important! lowering press button ç.
Page 238 If a malfunction is indicated as outlined above, have the (determined by the GPS satellite location system), system checked at the nearest Mercedes-Benz Center as vehicle model, identification number and color are soon as possible.
Page 239 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tele Aid The Tele Aid system is available if: Warning! • it has been activated and is operational. Activation If the indicator lamp in the “SOS” button is requires a subscription for monitoring services and illuminated continuously and there was no voice cellular air time...
Page 240 Initiating an emergency call manually Briefly press on cover (1) – the cover will open. Press the SOS button (2) briefly. The indicator lamp in the SOS button (2) will flash until the emergency call is concluded. Wait for a voice connection to the Response Center.
Page 241 The nature of the need for button. Carefully leave the vehicle and move to a assistance can then be described. The Mercedes-Benz safe location. The Response Center will Roadside assistance dispatcher will either dispatch a automatically contact local emergency officials with the vehicle’s approximate location if they...
Page 242 Roadside Assistance calls can be terminated using the operation of your vehicle, the nearest Mercedes-Benz ì button on the multifunction steering wheel. Center or Mercedes-Benz USA products and services is available to you. For more details concerning Tele Aid, please visit www.mbusa.com and use your ID and password, sent to...
Page 243 “SOS” button and the Roadside Assistance button •). initiate a call. Visit your Mercedes-Benz Center and have the system See system self-check on page 234 when the indicator checked or contact the Response Center at 1-800-756-...
Page 244 COMAND) is muted and the selected mode (radio, 1-800-756-9018 (in the USA) or 1-888-923-8367 (in tape or CD) pauses. The optional cellular phone (if Canada), or Mercedes-Benz Customer Assistance at installed) switches off. If you must use this phone, the 1-800-FOR-MERCedes (1-800-367-6372) in the USA or vehicle must be parked.
Page 245 In the case you have your vehicle locked unintentionally relevant cellular phone network is available. (e.g. key inside vehicle), and no other key is available, contact the Mercedes-Benz Response Center at The SOS button will flash and the message 1-800-756-9018 (in the USA) or 1-888-923-8367 (in “EMERGENCY CALL –...
Page 246 Select “Yes”. With the vehicle stopped in a safe to the police who will issue a numbered incident report. location press SVC, then select “View Info Service of Pass this number on to the Mercedes-Benz Response mm.dd.yyyy hh.mm”. Messages will be retained for Center.
Page 247: Catalytic Converter
Catalytic converter Catalytic converter Warning! Your Mercedes-Benz is equipped with monolithic type As with any vehicle, do not idle, park or operate catalytic converters, an important element in this vehicle in areas where combustible materials conjunction with the oxygen sensors to achieve...
Page 248: Emission Control
Mercedes-Benz Center authorized technicians. Engine and corrected immediately. If you must drive under adjustments should not be altered in any way. Moreover,...
Page 249: Starter Switch
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Starter switch Starter switch key or with the electronic key in starter switch position 0 or 1 the selector lever is locked in position “P”. Most electrical consumers can be operated.
Page 250 Important! Notes: If the electronic key is left in the starter switch A warning sounds when the driver’s door is opened with the electronic key is in starter switch position 1 position 0 for a extended period of time, it can no longer be turned in the lock.
Page 251: Starting And Turning Off The Engine
(-20 ° C) we recommend that an engine block heater be starter switch clockwise to the stop and release. The installed. Your authorized Mercedes-Benz Center will starter will engage until the engine is running. advise you on this subject, see page 269.
Page 252: Manual Transmission
Downshifting gears leading to overrevving the engine can result in engine damage that is not covered by the Mercedes-Benz Limited Warranty. Do not exceed engine speed limits, see page 101. See illustration for gearshift lever positions corresponding to the individual gears.
Page 253 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Manual transmission Warning! Warning! For vehicles equipped with a manual transmission, When leaving the vehicle always remove the key getting out of your vehicle with the gearshift lever from the steering lock, and lock the vehicle.
Page 254: Automatic Transmission
Automatic transmission The automatic transmission selects individual gears automatically, dependent upon • Selector lever position • Program mode selector • Accelerator position • Vehicle speed The gear shifting process is continuously adapted, dependent on the driving style, the driving situation and the road characteristics.
Page 255 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic transmission Driving Important! The selector lever is automatically locked while in After selecting any driving position from “N” or “P”, position “P”. To move the selector lever out of wait a moment to allow the gear to fully engage before position “P”, the service brake pedal must be firmly accelerating, especially when the engine is cold.
Page 256 Stopping Rocking a vehicle free in this manner may cause the ABS or traction system malfunction indicator lamp to For brief stops, e.g. at traffic lights, leave the come on. Turn off and restart the engine to clear the transmission in gear and hold vehicle with the service malfunction indication.
Page 257 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic transmission Selector lever position Program mode indicator, Light emitting gear range indicators see page 258 There is an additional indication of the current selector Gear range indicators lever position on the cover of the shifting-gate.
Page 258 “P”. With the electronic key removed, the transmission damage that is not covered by the selector lever is locked in position “P”. Mercedes-Benz Limited Warranty. Reverse gear The transmission automatically upshifts through 5th gear. Position “D” provides optimum driving...
Page 259 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic transmission Gear selection for special circumstances Briefly press selector lever in the “D +” direction: The transmission will shift from the current gear range The transmission gear ranges for special circumstances to the next higher gear range.
Page 260 malfunction. However, neither the engine nor Gear ranges: transmission are negatively affected by this mode of Upshift through 4th gear only. Suitable for operation. performance driving. The delayed upshift is effective with vehicle speeds Upshift through 3rd gear only. Suitable for below 31 mph (50 km/h) at partial throttle and engine moderately steep hills.
Page 261 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic transmission Program mode selector switch Standard mode Press switch. “S” is displayed in the gear range indicator display, see page 254. Use this mode for all regular driving.
Page 262 Have the transmission checked at your authorized Dependent on the program mode selector switch Mercedes-Benz Center as soon as possible. position “S” or “W” and the gear selector lever in position “R”, the ratio of power transmission changes.
Page 263: Parking Brake
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Parking brake Parking brake To engage, firmly depress parking brake pedal. When the electronic key is in starter switch position 2, the brake warning lamp in the instrument cluster should come on brightly.
Page 264: Driving Instructions
• avoid frequent acceleration and deceleration, Pedals • have all maintenance work performed at regular intervals by an authorized Mercedes-Benz Center. Warning! Keep driver’s foot area clear at all times. Objects Fuel consumption is also increased by driving in cold stored in this area may impair pedal movement.
Page 265: Power Assistance
It can also result in the brakes overheating thereby Have the brake system inspected at an authorized significantly reducing their effectiveness. It may not be possible to stop the vehicle in sufficient time Mercedes-Benz Center immediately. to avoid an accident.
Page 266: Driving Off
When starting off on a slippery surface, do not allow one drive wheel to spin for an extended period with the ESP switched off. Doing so may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. Driving instructions...
Page 267: Parking
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving instructions Parking Important! It is advisable to set the parking brake whenever Warning! parking or leaving the vehicle. In addition, move selector lever to position “P” (manual transmission: first To reduce the risk of personal injury as a result of vehicle movement, before turning off the engine or reverse gear).
Page 268: Tires
Inspect the tires and under the vehicle for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for repairs. Warning! Tread wear indicators (TWI) are required by law. These Do not allow your tires to wear down too far.
Page 269 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving instructions Specified tire pressures must be maintained. This Tire traction applies particularly if the tires are subjected to high The safe speed on a wet, snow covered or icy road is loads (e.g.
Page 270: Snow Chains
Use only snow chains that are tested and recommended Your vehicle is factory equipped with “H”-rated tires, by Mercedes-Benz. Your authorized Mercedes-Benz which have a speed rating of 130 mph (210 km/h). Center will be glad to advise you on this subject.
Page 271: Instructions
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving instructions Winter driving instructions If the vehicle is parked after being driven on salt treated roads, the braking efficiency should be tested as soon as The most important rule for slippery or icy roads is to possible after driving is resumed while observing the drive sensibly and to avoid abrupt acceleration, braking...
Page 272: Winter Driving
In winter operation, the maximum effectiveness of the antilock brake system (ABS) and electronic stability Mercedes-Benz Center before the onset of winter. program (ESP) can only be achieved with M+S rated • Change the engine oil if the engine contains an oil radial-ply tires and/or snow chains recommended by which is not approved for winter operation.
Page 273: Deep Water
If you must drive through deep water, drive slowly to prevent water from entering the engine compartment or passenger compartment, being ingested by the air intake, possibly causing damage to electrical components or wiring, to engine or transmission that is not covered by the Mercedes-Benz Limited Warranty.
Page 274: Passenger Compartment
Abroad, there is a widely-spread Mercedes-Benz service Warning! network at your disposal. If you plan to travel into areas which are not listed in the index of your Mercedes-Benz Always fasten items being carried as securely as Center directory, you should request pertinent possible.
Page 275: Cruise Control
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems Cruise control Accelerate and set: Lift lever briefly to set speed. Hold lever up to accelerate. Decelerate and set: Depress lever briefly to set speed. Hold lever down to decelerate.
Page 276 If the cruise control cancels by itself and remains position 1 or 0. inoperative until the engine is restarted, have the system checked at your authorized Mercedes-Benz Important! Center as soon as possible. Moving gear selector lever to position “N” switches the cruise control off.
Page 277 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems Vehicles with automatic transmission: Warning! Downshift occurs (max. to 3rd gear) to maintain the set Only use the cruise control if the traffic and cruise controlled speed by using the engine’s braking weather conditions make it advisable to travel at a steady speed.
Page 278: Brake Assist System (Bas)
If a BAS warning message is displayed, have the BAS which could jeopardize the user’s safety or the checked at your authorized Mercedes-Benz Center as safety of others. soon as possible. The BAS is designed to maximize the vehicle’s braking...
Page 279: Antilock Brake System
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems Antilock brake system (ABS) At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode.
Page 280 The ABS malfunction indicator lamp - in the Mercedes-Benz Center as soon as possible. instrument cluster comes on with the electronic key in starter switch position 2 and should go out with the Warning! engine running.
Page 281: Electronic Stability Program
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems Electronic stability program (ESP) Important! If the ESP warning lamp v flashes: Warning! • During take-off apply as little throttle as possible. ESP cannot prevent the natural laws of physics •...
Page 282 In winter operation, the maximum effectiveness of the If the ESP warning message is displayed, a malfunction ESP is only achieved with Mercedes-Benz recommended has been detected in the system. Only partial engine M+S rated radial-ply tires and/or snow chains.
Page 283 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems ESP control switch To improve the vehicle’s traction when driving with snow chains, or starting off in deep snow, sand or gravel, switch off ESP by pressing the upper half (1) of the ESP switch.
Page 284 • During take-off, apply as little throttle as possible. by the Mercedes-Benz Limited Warranty. • While driving, ease up on the accelerator. The ESP warning lamp, located in the speedometer dial, starts to flash at any vehicle speed as soon as the tires lose traction and the wheels begin to spin.
Page 285: At The Gas Station
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data What you should know at the gas station What you should know at the gas station Open flap by pushing near front (arrow). Turn fuel cap to the left and hold on to it until possible pressure in Fuel supply tank has been released, then remove cap.
Page 286 Fuel tank capacity approximately 16.4 US gal (62.0 l). Spark plugs This includes approximately 2.1 US gal (8.0 l) reserve. Approved spark plugs, refer to “Technical Data”. Use premium unleaded gasoline: Air conditioner Posted Octane Index 91 (Average of 96 RON/86 MON). R-134a refrigerant and special PAG lubricant, refer to Engine oil “Technical Data”.
Page 287: Before A Long Trip
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Check regularly and before a long trip Check regularly and before a long trip Windshield washer and headlamp cleaning system For refilling reservoir see page 323. Coolant level, see “Coolant level”...
Page 288: Instrument Cluster Display
Instrument cluster display Malfunction and COOLANT indicator lamp in (coolant level) ......301 Malfunction and indicator lamps the center console ....292 COOLANT in the instrument cluster ..286 AIRBAG OFF indicator lamp ..292 (coolant temperature) ....302 On-board diagnostic system ..286 Malfunction and ENGINE OIL LEVEL ....303 Check engine malfunction...
Page 289: Malfunction And Indicator Lamps
Engine malfunction indicator lamp. If the therefore, be carried out only by authorized “CHECK ENGINE” malfunction indicator Mercedes-Benz Center qualified technicians. Engine lamp comes on when the engine is running, adjustments should not be altered in any way. Moreover, it indicates a malfunction of the fuel management...
Page 290 If the “CHECK ENGINE” malfunction indicator lamp recommend that you have the system checked at your comes on, have the system checked at your authorized authorized Mercedes-Benz Center as soon as possible. Mercedes-Benz Center as soon as possible. If the “CHECK ENGINE” lamp comes on continuosly With some exceptions, the control module switches off and/or the vehicle is not driving normally (e.g.
Page 291: Brake Warning Lamp
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and indicator lamps Brake warning lamp Warning! Driving with the brake warning lamp illuminated Except Canada can result in an accident. Have your brake system checked immediately if the brake warning lamp stays on.
Page 292: Supplemental Restraint System (Srs) Indicator Lamp
If no fault is detected, the lamp will go recommend that you visit an authorized out when the engine is running. Mercedes-Benz Center immediately to have the system checked; otherwise the “SRS” may not be The operational readiness of the airbag system is activated when needed in an accident, which could verified by the indicator lamp “SRS”...
Page 293: Fuel Reserve Warning
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and indicator lamps Fuel reserve warning After refueling the vehicle, the message “1 MALFUNCTION” appears in the multifunction display when turning the electronic key in starter switch to position 2.
Page 294: Abs Malfunction Indicator Lamp
See page 276 for notes on antilock brake system (ABS). the operation of other systems (e.g. Navigation, Automatic transmission). Be guided accordingly with respect to the use of those systems and have the system checked at your authorized Mercedes-Benz Center as soon as possible. Malfunction and indicator lamps Instruments...
Page 295: Electronic Stability Program (Esp) - Warning Lamp
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and indicator lamps Electronic stability program (ESP) — warning lamp Malfunction and indicator lamp in the center console The yellow ESP warning lamp in the speedometer dial comes on with the AIRBAG OFF indicator lamp electronic key in starter switch position 2.
Page 296: Multifunction Display
Malfunction and warning messages in the Warning! multifunction display The BabySmart airbag deactivation system will Malfunction and warning messages for the following ONLY work with a special child seat designed to operate with it. It will not work with child seats systems will be displayed immediately in the which are not BabySmart compatible.
Page 297 Failure to repair condition noted may cause Temporary messages such as “TRUNK OPEN!” will not damage not covered by the Mercedes-Benz Limited be stored in the malfunction message memory. Warranty, or result in property damage or personal...
Page 298: Display Defective
DISPLAY DEFECTIVE (engine control unit) DISPLAY DEFECTIVE (several systems) Line 1 Line 2 Line 1 Line 2 VISIT WORKSHOP! DISPLAY FAULTY VISIT WORKSHOP! DISPLAY FAULTY * C = Category, see page 293 * C = Category, see page 293 This message is displayed to indicate that the The displays for several systems have failed.
Page 299: Battery /Alternator
Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is Line 1 Line 2 not covered by the Mercedes-Benz Limited Warranty. BATTERY/ALTERNATOR VISIT WORKSHOP! * C = Category, see page 293...
Page 300: Antilock Brake System
ANTILOCK BRAKE SYSTEM BRAKE ASSIST Line 1 Line 2 Line 1 Line 2 ABS SYSTEM VISIT WORKSHOP! BRAKE ASSIST NOT AVAILABLE! DISPLAY DEFECTIVE VISIT WORKSHOP! BRAKE ASSIST VISIT WORKSHOP! DISPLAY DEFECTIVE VISIT WORKSHOP! * C = Category, see page 293 * C = Category, see page 293 See page 276 for notes on the antilock brake system (ABS).
Page 301: Brake Pad Wear
Driving with this message displayed can result in Have the brake system checked at your authorized an accident. Have your brake system checked Mercedes-Benz Center as soon as possible. immediately. Don’t add brake fluid before checking the brake system. Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire.
Page 302: Parking Brake
PARKING BRAKE SEAT BELT SYSTEM Line 1 Line 2 Line 1 Line 2 PARKING BRAKE ENGAGE BRAKE! SEAT BELT SYSTEM VISIT WORKSHOP! PARKING BRAKE RELEASE BRAKE! PASSENGER SEAT BELT FASTEN SEAT BELT! DRIVER SEAT BELT FASTEN SEAT BELT! * C = Category, see page 293 * C = Category, see page 293 Malfunction and warning messages Instruments...
Page 303: Elec. Stabil. Prog
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages ELEC. STABIL. PROG. (Electronic stability program) 1 The enhanced vehicle stability offered by ESP and the torque reduction feature are unavailable. 2 This message may be displayed if the power supply was interrupted (battery disconnected or empty).
Page 304: Coolant (Coolant Level)
Mercedes-Benz Limited Warranty. In cases of major or frequent minor coolant loss, have the cooling system checked at your authorized Mercedes-Benz Center as soon as possible. Note: Do not drive without coolant in the cooling system. The engine will overheat causing major engine damage.
Page 305: (Coolant Temperature)
Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. 2 The cooling fan for the coolant is faulty. Observe the coolant...
Page 306: Engine Oil Level
1 The engine oil level must be checked immediately. See Engine oil result in serious engine damage that is not covered by level indicator on page 141. the Mercedes-Benz Limited Warranty. 2 There is no oil in the engine. There is a danger of engine damage. Malfunction and warning messages...
Page 307: Lighting System
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages LIGHTING SYSTEM Line 1 Line 2 TURN SIGNAL F, R CHECK LAMPS! BRAKE LIGHT VISIT WORKSHOP! BRAKE LIGHT, L CHECK LAMPS! BRAKE LIGHT, R CHECK LAMPS! 3RD STOP LAMP...
Page 308 In the case of bulb failures in certain lamps, other lamps Line 1 Line 2 will substitute. See page 351 for instructions on replacing bulbs. REAR FOGLAMP SWITCH OFF SUBSTITUTE LAMP ON! * C = Category, see page 293 REVERSE LIGHT, L CHECK LAMPS! 1 The display or the system is malfunctioning.
Page 309: Lamp Sensor
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages LAMP SENSOR DOOR Line 1 Line 2 Line 1 Line 2 LAMP SENSOR VISIT WORKSHOP! DOOR OPEN! * C = Category, see page 293 * C = Category, see page 293.
Page 310: Trunk Open
TRUNK OPEN HOOD Line 1 Line 2 Line 1 Line 2 TRUNK OPEN! HOOD OPEN! * C = Category, see page 293 * C = Category, see page 293. See page 318 for hood. Malfunction and warning messages Instruments Instrument Technical Operation Driving...
Page 311: Telephone - Function
See page 234 for notes on the Tele Aid. If a malfunction is indicated as outlined above, have the system checked at the nearest Mercedes-Benz Center as soon as possible.
Page 312: Washer Fluid
WASHER FLUID When this message appears while the engine is running, the level of the reservoir has dropped to approximately of the total volume. The reservoir should be refilled with the prescribed mixture of MB Windshield washer concentrate and water or the concentrate and commercially available premixed windshield washer solvent/antifreeze, depending on ambient temperature, at the next opportunity.
Page 313: Restraint System
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages RESTRAINT SYSTEM Line 1 Line 2 Line 1 Line 2 RESTRAINT SYSTEM VISIT WORKSHOP! REPLACE KEY VISIT WORKSHOP! AUTOM. LIGHT ON REMOVE KEY! * C = Category, see page 293.
Page 314: Fuel Reserve
FUEL RESERVE UNDERVOLTAGE Line 1 Line 2 Line 1 Line 2 RESERVE FUEL VISIT FILLING STATION! UNDERVOLTAGE ENGINE ON! UNDERVOLTAGE CONSUMER DEFECTIVE! * C = Category, see page 293. * C = Category, see page 293. Malfunction and warning messages Instruments Instrument Technical...
Page 315: Steer. Wheel Adjust
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages STEERING WHEEL ADJUST Line 1 Line 2 STEERING WHEEL ADJUST LOCK! * C = Category, see page 293. For locking the manual steering wheel adjustment, see page 88.
Page 316 Practical hints TIREFIT, vehicle tools, Towing the vehicle ......347 storage compartment Transmission selector lever, First aid kit ........314 (C 32 AMG only) ....... 326 manually unlocking ....350 Stowing things in the vehicle ..314 Vehicle jack ........327 Exterior lamps ........ 351 Fuses ..........
Page 317: First Aid Kit
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data First aid kit First aid kit Stowing things in the vehicle Warning! To help avoid personal injury during a collision or sudden maneuver, exercise care when stowing things.
Page 318: Fuses
Fuses Fuse box in the passenger compartment Most of your vehicle’s electrical components are fused with safety fuses. With the exception of the brake lights, all individual lighting system components are electronically fused. Before replacing a blown safety fuse, determine the cause of the short circuit. Always observe amperage and color of fuse.
Page 319 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Fuses Fuse box in engine compartment Cover Fuse box in engine compartment, left-hand side Screw Clamps Retainer To gain access to fuse box: Release clamps (6) and remove the cover. To remove cover: Twist screws (3) 90˚...
Page 320 Auxiliary fuse box in the trunk To open: Pull trim panel (1) away. Remove the cover (2) of auxiliary fuse box. Note: In the cover (2) of the auxiliary fuse box the special fuse puller (3) is positioned. To close: Put the cover (2) of auxiliary fuse box on.
Page 321: Hood
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Engine compartment Hood The engine is equipped with a transistorized ignition system. Because of the high voltage it is dangerous to touch any components (ignition coils, Warning! spark plug sockets, diagnostic socket) of the To help prevent personal injury, stay clear of...
Page 322 To open: Pull handle (2) to its stop out of radiator grill and open To unlock the hood, pull release lever (1) under the hood (do not pull up on the handle). driver´s side of the instrument panel. At the same time a handle will extend out of the radiator grill.
Page 323 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Engine compartment To close: Lower the hood and let it drop into lock from a height of approximately 1 ft. (30 cm), assisting with hands placed flat on edges of hood (3).
Page 324: Adding Engine Oil
Re-install oil filler cap. Do not overfill the engine. Excessive oil must be drained or siphoned. It could cause damage to engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. See malfunction and warning messages on page 293 if an engine oil level display appears on the multifunction indicator when the engine is running.
Page 325: Automatic Transmission Fluid Level
For this reason the dipstick is omitted. If you notice fluid leaks or gear shifting malfunctions, have your authorized Mercedes-Benz Center check the transmission fluid level. P 2 0 . 3 0 - 2 1 3 3 - 2 6...
Page 326: Adding Coolant
Adding coolant Windshield and headlamp washer system If coolant has to be added, a 50/50 mixture of water and MB anticorrosion/antifreeze should be added. Warning! • In order to avoid possibly serious burns: Use extreme caution when opening the hood if there are any signs of steam or coolant leaking from the cooling system, or if the coolant temperature gauge indicates that the coolant is...
Page 327 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Engine compartment Vehicles without headlamp cleaning system: Windshield and headlamp washer fluid mixing ratio Capacity approximately 3.2 US qt (3.0 l) For temperatures above freezing: Vehicles with headlamp cleaning system: MB Windshield Washer Concentrate “S”...
Page 328: Spare Wheel, Vehicle Tools, Storage Compartment
Spare wheel, vehicle tools, storage compartment Lift trunk floor and engage handle in upper edge of trunk. Always lower trunk floor before closing trunk lid. To remove the spare wheel: Take out the vehicle tool kit tray. Turn the luggage bowl counterclockwise and remove the spare wheel.
Page 329: Tirefit, Vehicle Tools, Storage Compartment (C 32 Amg Only)
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data TIREFIT TIREFIT, vehicle tools, storage compartment Jack (C 32 AMG only) TIREFIT Air pump Vehicle tool kit Towing eye bolt For notes on the TIREFIT and air pump, see page 337. The TIREFIT, vehicle tools and the storage compartment are located below the trunk floor.
Page 330: Vehicle Jack
Vehicle jack To prepare the jack for use: Storing the jack in the trunk: Remove the jack from the spare wheel well under the Before storing the jack, it should be fully collapsed, with trunk floor. handle folded in (storage position). Push the crank handle up and turn clockwise until it engages (operational position).
Page 331: Wheels
To help avoid personal injury, See your authorized Mercedes-Benz Center for further use the jack only to lift the vehicle during a wheel information.
Page 332: Rotating Wheels
Notes: When replacing rims, use only genuine Mercedes-Benz wheel bolts specified for the Thoroughly clean the inner side of the wheels any time particular rim type. Failure to do so can result in you rotate the wheels or wash the vehicle underside.
Page 333: Spare Wheel
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels Spare wheel Important! The spare wheel rim is mounted with a full size tire of the same type as on the vehicle, and is fully functional. For additional information, refer to page 378.
Page 334: Changing Wheels
Changing wheels Move vehicle to a level area which is a safe distance from the roadway. Warning! 1. Set parking brake and turn on hazard warning The jack is designed exclusively for jacking up the flasher. vehicle at the jack take-up brackets built into either side of the vehicle.
Page 335 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels P 4 0 . 1 0 - 2 4 2 6 - 2 6 P 4 0 . 1 0 - 2 4 2 7 - 2 6 4.
Page 336 P 4 0 . 1 0 - 2 4 2 8 - 2 6 7. Place jack on firm ground. Position jack (1) under 9. Unscrew upper-most wheel bolt and install the take-up bracket (2) so that it is always vertical alignment bolt (1) supplied in the tool kit.
Page 337 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels P 4 0 . 1 0 - 2 4 2 9 - 2 6 Wheel bolt for light alloy rims 11. Clean contact surfaces of wheel and wheel hub. Install wheel on wheel hub.
Page 338 P 4 0 . 1 0 - 2 4 3 0 - 2 6 P 4 0 . 1 0 - 2 4 3 1 - 2 6 12. Lower vehicle and remove jack. 13. Using the wrench, tighten the five bolts evenly, following the sequence illustrated, until all bolts are tight.
Page 339 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels Notes: Before storing the jack, it should be fully collapsed, with handle folded in. For proper storage of vehicle jack see page 325. Warning! Always replace wheel bolts that are damaged or rusted.
Page 340: Tirefit
TIREFIT should not be used in such circumstances. Do not drive the vehicle under such circumstances. Contact your nearest Mercedes-Benz Center for assistance. Take care not to allow the contents of TIREFIT to come in contact with hair, eyes or clothing.
Page 341 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels P 4 0 . 1 0 - 2 1 5 8 - 2 6 5. Unscrew valve tire cap. Remove tire valve (2) using Sealing tire with TIREFIT valve stem removal tool (3).
Page 342 6. Remove plug (4) from end of hose (1) and push hose (1) onto valve stem. 7. Hold container upside down (hose down) and squeeze entire contents of container into tire. 8. Pull hose (1) off and screw tire valve (2) using valve stem tool (3) into the valve stem.
Page 343 26 psi (1.8 bar). Do not exceed the maximum pressure Do not drive the vehicle. of 36 psi (2.5 bar)! Contact the nearest Mercedes-Benz Center or call If pressure is not attained, drive vehicle Roadside Assistance. approx. 394 in (10 m), so that the sealing material is evenly distributed inside the tire.
Page 344: Tire Inflation Pressure
Warning! A table (see fuel filler flap) lists the tire inflation Do not exceed vehicle speed of 50 mph (80 km/h). pressures specified for Mercedes-Benz recommended A TIREFIT repair is not designed to operate at higher speeds. tires as well as for the varying operating conditions.
Page 345: Battery
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Battery warm tires only if pressure has dropped below the Battery pressure listed in the table and the respective operating conditions are taken into consideration. Warning! An underinflated tire due to a slow leak (e.g.
Page 346 Therefore, we strongly recommend that you have the battery charge checked frequently, and corrected if necessary, especially if you use the vehicle less than approximately 200 miles (300 km) per month, mostly for short distance trips, or if it is not used for long periods of time.
Page 347: Jump Starting
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Jump starting Note: Jump starting The gear selector lever will remain locked in Warning! position “P” and the electronic key can not be turned in the starter switch, if the vehicle battery is disconnected Failure to follow these directions will cause or discharged.
Page 348 Only use 12 V battery to jump start your vehicle. Jump starting with more powerful battery could damage the vehicle’s electrical systems, which will not be covered by the Mercedes-Benz Limited Warranty. The battery is located in the engine compartment on the right hand side.
Page 349 (+) terminal starting attempts, have it checked at the nearest of the charged battery. Make sure the cable clamps authorized Mercedes-Benz Center. do not touch any other metal parts. Excessive unburned fuel may damage the catalytic 4.
Page 350: Towing The Vehicle
Towing the vehicle Important! When towing the vehicle, please, note the following: Warning! With the automatic central locking activated and the Prior to towing the vehicle with all wheels on the electronic key in starter switch position 2, the vehicle ground, make certain that the electronic key is in doors lock if the left front wheel as well as the right rear starter switch position 2.
Page 351 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Towing the vehicle Cover on right side of front bumper Cover on right side of rear bumper To remove cover: To remove cover: Press mark on cover in direction of arrow and lift cover Press mark on cover in direction of arrow and lift cover off to reveal threaded hole for towing eye bolt.
Page 352 We recommend that the vehicle be transported using Warning! flat bed equipment. This method is preferable to other With the engine not running, there is no power types of towing. assistance for the braking and steering systems. In this case, it is important to keep in mind that a Important! considerably higher degree of effort is necessary to brake and steer the vehicle.
Page 353: Transmission Selector Lever, Manually Unlocking
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Towing the vehicle Transmission selector lever, manually unlocking To do so, open storage compartment in front of center armrest. Using a small coin, release the coin holder (1) and swing it aside.
Page 354: Exterior Lamps
If the newly installed bulb does not light up, switch the Wear eye and hand protection. lamp off and on again. If the bulb still does not light up, have the system checked at an authorized Mercedes-Benz Center. Exterior lamps Instruments Instrument...
Page 355 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamps Headlamp assembly Headlamp cover for low beam headlamp Bulb socket for turn signal lamp Headlamp cover for parking and standing lamp, and Electrical connector for low beam headlamp bulb high beam headlamp (Halogen type) Electrical connector for high beam headlamp bulb...
Page 356 Bulbs for high and low beam Turn signal lamp H7 (55 W) 1156 NA (26.9/5 W/32/4 cp) Open hood. Open hood. Press the clamp and remove headlamp cover (1 or 2). Twist bulb socket (3) counterclockwise and pull out. Push bulb into socket, turn counterclockwise and Pull electrical connector off.
Page 357 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamps Taillamp assemblies Driver’s side: Open trunk lid. rear fog lamp Fold trim to the side. (P 21 W/32 cp bulb) Turn locking lever (1) to vertical position and remove Backup lamp (P 21 W/32 cp bulb) bulb carrier.
Page 358 License plate lamp Side marker lamp, front (5 W/4 cp bulb) Loosen both securing screws (1), remove lamp and Carefully slide lamp towards rear (arrow 1), and remove replace tubular lamp (C 5 W/4 cp). front end first (arrow 2). Twist bulb socket counterclockwise and pull out.
Page 359: Standby Bulb Function
Have the system checked at an authorized The respective fog lamp, dimmed, will act as a Mercedes-Benz Center if a malfunction occurs. replacement lamp, if the left or right standing lamp stops working. Notes: The multifunction display will indicate that a bulb has failed.
Page 360: Changing Batteries In The
Changing batteries in the electronic key P 8 0 . 2 0 - 2 2 0 1 - 2 6 P 8 0 . 3 5 - 2 0 2 9 - 2 6 Transmit buttons Changing batteries Lamp for battery check and function control Move locking tab (3) in direction of right arrow and remove mechanical key (4, left arrow).
Page 361 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Electronic key P 8 0 . 3 5 - 2 0 2 5 - 2 6 P 8 0 . 3 5 - 2 0 2 7 - 2 6 Insert mechanical key (4) in side opening (5) to open Change batteries (7), inserting new ones under contact latch.
Page 362: Synchronizing Remote Control
Important! Emergency engine shut-down Batteries contain materials that can harm the If the engine can no longer be stopped using the environment if disposed of improperly. Recycling of electronic key, the engine can be turned off by removing batteries is the preferred method of disposal. For two fuses.
Page 363: Fuel Filler Flap, Manual Release
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Fuel filler flap, manual release Fuel filler flap, manual release Emergency operation of sliding/pop-up roof Open the trunk lid and fold right-side taillamp trim The sliding/pop-up roof can be opened or closed aside.
Page 364 Slide both locking tabs (2) in direction of arrow, lower Obtain crank (3) (supplied with vehicle) and insert rear of cover and remove. through hole. To slide roof closed or to raise the roof at the rear: Note: turn crank clockwise. Do not disconnect electrical connectors.
Page 365: Replacing Wiper Blade Insert
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Replacing wiper blade insert Replacing wiper blade inserts For safety reasons, remove electronic key from steering lock before replacing the wiper blades, otherwise the motor can suddenly turn on and cause injury. Notes: Do not open engine hood with wiper arm folded forward.
Page 366: Roof Rack
Only mount roof racks to the fastening bolts (see arrows) and slide (direction of arrow) the wiper blade insert out located under the door weatherstrips. of the retainer claws. Use only those roof racks approved by Mercedes-Benz to Installation: avoid damage to the vehicle. Follow manufacturer’s installation instructions.
Page 368 Vehicle care Ornamental moldings ....369 Cup holder ........370 Headlamps, taillamps, Seat belts ........371 Cleaning and care turn signal lenses ...... 369 Headliner and of the vehicle ......366 Window cleaning ....... 369 shelf below rear window ... 371 Power washer ......367 Wiper blade ........
Page 369: Cleaning And Care Of The Vehicle
Post-production treatment is neither necessary nor recommended by Mercedes-Benz Such damage is caused not only by extreme and varying because of the possibility of incompatibility between...
Page 370: Power Washer
The following topics deal with the cleaning and care of Paintwork, painted body components your vehicle and give important “how-to” information as well as references to Mercedes-Benz approved car-care Mercedes-Benz approved Paint Care should be applied products. when water drops on the paint surface do not “bead up”,...
Page 371: Engine Cleaning
Use only a mild car wash detergent, such as intrusion of water and cleaning agents. Mercedes-Benz approved Car Shampoo. Corrosion protection, such as MB Anticorrosion Wax Thoroughly spray the vehicle with a diffused jet of should be applied to the engine compartment after water.
Page 372: Ornamental Moldings
Note: Headlamps, taillamps, turn signal lenses For safety reasons, switch off wipers and remove Use a mild car wash detergent, such as Mercedes-Benz electronic key from starter switch before cleaning the approved Car Shampoo, with plenty of water. windshield, otherwise the wiper motor can suddenly To prevent scratches, never apply strong force and use turn on and cause injury.
Page 373: Light Alloy Wheels
Cleaning and care of the vehicle Light alloy wheels Instrument cluster Mercedes-Benz approved Wheel Care should be used for Use a gentle dishwashing detergent or mild detergent regular cleaning of the light alloy wheels. for delicate fabrics as a washing solution. Wipe with a cloth moistened in lukewarm solution.
Page 374: Seat Belts
Clean with soft bristle brush, or use a dry-shampoo MB Tex Upholstery cleaner in case of excessive dirt. Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure. Hard plastic trim items Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure.
Page 376 Technical data Engine oil additives ...... 383 Air conditioner refrigerant ..383 Spare parts service ......374 Brake fluid ........383 Warranty coverage ......374 Premium unleaded gasoline ..384 Identification labels .......375 Fuel requirements ......384 Layout of poly-V-belt drive .... 376 Gasoline additives ......
Page 377: Spare Parts Service
Replacement parts and accessories are covered by the Mercedes-Benz Spare Parts and Accessories warranties, Important! copies of which are available at any Mercedes-Benz The use of non-genuine parts and accessories not Center. authorized by Mercedes-Benz could damage the vehicle...
Page 378: Identification Labels
Identification labels Certification label Vehicle Identification Number (VIN) (below right front passenger seat) Technical data Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 379: Layout Of Poly-V-Belt Drive
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Technical data Layout of poly-V-belt drive P 0 1 . 0 0 - 2 2 2 0 - 2 6 VIN, visible (lower edge of windshield) Automatic belt tensioner Engine number Crankshaft...
Page 380: Technical Data
1-4-3-6-2-5 1-4-3-6-2-5 Poly-V-belt 2390 mm 2390 mm 2390 mm 1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Technical data Instruments Instrument Technical...
Page 381 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Technical data Rims — Tires Model C 240 (203.061) C 320 (203.064) C 240 (Canada only) C 32 AMG (203.065) Rims (light alloy) 7J x 16 H2 7J x 16 H2 (steel rims) 7J x 16 H2 Front axle: 7...
Page 382 Electrical system Model C 240 (203.061) C 320 (203.064) C 32 AMG (203.065) Generator (alternator) 14 V/120 A 14 V/120 A 14 V/120 A Starter motor 12V/1.7 kW 12V/1.7 kW 12V/1.7 kW Battery 12V/100 Ah 12V/100 Ah 12V/74 Ah Spark plugs Bosch F 8 DPER Bosch F 8 DPER NGK IFR 6 D 10...
Page 383 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Technical data Main Dimensions Model C 240 (203.061) C 32 AMG (203.065) C 320 (203.064) Overall vehicle length 178.2 in (4526 mm) 178.2 in (4526 mm) Overall vehicle width 68.0 in (1728 mm) 68.0 in (1728 mm)
Page 384: Fuels, Coolants, Lubricants Etc. - Capacities
Fuels, coolants, lubricants etc. - capacities Vehicle components and their respective lubricants must match. Therefore use only brands tested and recommended by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center. Capacity Fuels, coolants, lubricants etc.
Page 385 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Fuels, coolants, lubricants etc. - capacities Capacity Fuels, coolants, lubricants etc. Air conditioner system R-134a refrigerant and special PAG lubricant (Never R-12) Windshield washer and Vehicles without headlamp cleaning MB Windshield washer concentrate headlamp cleaning...
Page 386: Engine Oils
The brake fluid must therefore be replaced every two Damage or malfunctions resulting from blending oil years, preferably in the spring. additives are not covered by the Mercedes-Benz Limited It is recommended to use only brake fluid approved by Warranty.
Page 387: Premium Unleaded Gasoline
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Fuels, coolants, lubricants etc. - capacities Premium unleaded gasoline Fuel requirements Use only Premium unleaded meeting ASTM Caution! standard D 439: To maintain the engine’s durability and performance, The octane number (posted at the pump) must be premium unleaded gasoline must be used.
Page 388: Gasoline Additives
Gasoline additives Coolants A major concern among engine manufacturers is carbon The engine coolant is a mixture of water and build up caused by gasoline. Mercedes-Benz anticorrosion/antifreeze, which provides: recommends the use of only quality gasoline containing • corrosion protection, additives that prevent the build up of carbon deposits.
Page 389 The coolant is also regularly checked each time you bring If the coolant level is low, water and MB anticorrosion/ your vehicle to your authorized Mercedes-Benz Center antifreeze should be used to bring it up to the proper for service.
Page 390: Consumer Information
Consumer information may depart significantly from the norm due to variations in driving habits, service practices and This has been prepared as required of all manufactures differences in road characteristics and climate. of passenger cars under Title 49, Code of U.S. Federal Regulations, Part 575 pursuant to the “National Traffic Traction and Motor Vehicle Safety Act of 1966”.
Page 391 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Consumer information Temperature Warning! The temperature grades are A (the highest), B, and C, The temperature grade for this tire is established representing the tire‘s resistance to the generation of for a tire that is properly inflated and not heat and its ability to dissipate heat when tested under overloaded.
Page 392 Index Audio systems ..............108 Cassette player ............110 CD Player ..............109 Radio ................108 Automatic central locking ..........40 Adding engine oil ............321 Automatic climate control ..........160 Airbags ................73 Activated charcoal filter ...........168 ANTILOCK BRAKE SYSTEM Adjustable air outlets, Malfunction and warning message ......297 rear passenger compartment ......172 Antilock brake system (ABS) ........
Page 393 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index Summer opening/convenience feature ....35 Vehicle keys ..............28 BabySmart airbag deactivation system ..... 70 Check regularly and before a long trip ...... 284 Battery ................342 Child seat Block heater ..............270 See Infant and child restraint systems ....83...
Page 394 Cruise control ..............272 Emergency tensioning retractor (ETR) ................72 Cup holder ..............211 Emergency trunk lid release button ......44 Emergency unlocking in case of accident ....40 Engine oil consumption ..........142 Engine oil level indicator ..........141 Dashboard .................22 Enlarged cargo area ............221 Door control panel ............
Page 395 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index First aid kit ..............314 Hazard warning flasher switch ........151 Flat tire Head restraints See Changing wheels ..........331 Rear seat ...............60 Flexible service system Head restraints, front seats (FSS) ................
Page 396 Information call See Tele Aid ...............234 Keys, changing battery ..........357 Instrument cluster ............98 Keys, vehicle ..............28 Instruments and controls ..........18 Center console .............24 Dashboard ..............22 Door control panel ............20 Overhead control panel ..........21 Lamps, exterior Interior ................207 Side marker lamp, front ..........
Page 397 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index Maintenance ..............233 Navigation system ............116 Malfunction/warning message memory .....119 Night security illumination ..........146 Manual seat ............... 52, 56 Manual transmission ............249 Mechanical key ............28, 36 Memory function .............95 On-board diagnostic system ........
Page 398 Unfastening ..............67 Warning lamp ............292 Radio Seat belts and integrated restraint system ....63 See Radio mode ............179 Seats Rain sensor ..............149 Front seat adjustment ..........49 Rear passenger compartment adjustable air outlets 172 Heated seat ..............58 Rear window defroster ..........170 Manual seat ..............52 Rear window sunshade ..........205 Multicontour seat ............57...
Page 399 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index Starter switch ..............246 Roadside Assistance ..........238 Starting and turning off the engine ......248 Telephone .................111 STEER. WHEEL ADJUST. - Incoming call ............. 115 malfunction and warning messages ......
Page 400 Trunk lid Emergency release ............. 44 Warning lamps Trunk lid emergency release .........43 See Malfunction and indicator lamps in the instrument cluster ..........286 What you should know at the gas station ....282 Wheels ................328 Unlocking the vehicle with remote control ....33 Where to find it ..............
Page 404 If you have any question about carrying out some service, turn to the advice of an authorized Mercedes-Benz Center.
Page 405 Order No. 6515 0070 13 Part No. 203 584 29 82 USA Edition A 2002...
Page 406 Please observe the following: BOOKSPINE for Operator’s Manual in. (1.6 cm) 3.5“ (8.9 cm) Operator’s Manual C-Class Please ensure the correct position of model code and model name...

Mercedes-Benz C-Class Operator's Manual

Introduction

Instruments and Controls

Operation

Driving

Instrument Cluster Display

Practical Hints

Vehicle Care

Technical Data

Quick Links

Related Manuals for Mercedes-Benz C-Class

Summary of Contents for Mercedes-Benz C-Class
