SPRAY-GUN WASHER IWK H2O
For manual washing with water
Mod. H20
Before use, adjustment or maintenance, it is important to
GB
read this instruction manual very carefully. The manual
must be stored in a safe place for any future reference that may
be necessary.
ANEST IWATA Europe S.r.l.
46, Corso Vigevano
10155 Torino - Italia
Tel. +39 011-22 74 408/2
Fax +39 011-22 74 406
www.anest-iwataeu.com
e-mail: info@anest-iwataeu.com
Instruction Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Anest Iwata IWK H2O
-
Page 1: Instruction Manual
Instruction Manual SPRAY-GUN WASHER IWK H2O Mod. H20 For manual washing with water Before use, adjustment or maintenance, it is important to read this instruction manual very carefully. The manual must be stored in a safe place for any future reference that may be necessary. -
Page 2: Table Of Contents
For any claims, accidents or the like, the legally approved text will be one in the manufacturer's language. ANEST IWATA EUROPE WAIVES any and all liabilities for damages by misinterpretations or incorrect use caused by imper- fect or imprecise translations. -
Page 3: Introduction
This manual contains instructions for the installation, use and maintenance of the IWK H2O. In the following manual, the IWK H2O will be referred to as Spray-gun washer. This manual is an integral part to the product and should be kept with due care in order to allow for its use and consultation during the life of the Spray-gun washer. -
Page 4: Application
The Spray-gun washer has been designed and built by ANEST IWATA EUROPE in order to guarantee a high level of protection, efficient operations and conformity with the working parameters provided for devices group II, category 2 in explosive atmosphe- res caused by gas, vapour or mist in compliance with Directive 94/9/CE (ATEX). -
Page 5: Washing Products
SPRAY-GUN WASHER IWK H2O Mod. H2O 1.2.1 WASHING PRODUCTS Spray guns and accessories can be washed with: • Clean water. • Water-based solvent. In this case, the mixture must have the following characteristics: pH between 6.5 and 12; absence of inflammable components; if present, their concentration must not exceed 8%. -
Page 6: Description
SPRAY-GUN WASHER IWK H2O Mod. H2O 1.3 DESCRIPTION The Spray-gun washer basically consists of a steel container (see fig.1) housing: • A stainless steel tank to collect the used water (pos.2 fig.1). • A grill (pos. 6G fig 1) positioned on the stainless steel tank. - Page 7 SPRAY-GUN WASHER IWK H2O Mod. H2O Figure 1 NB. When ordering spare parts, always indicate the: Model, Serial Number and Construction Year.
-
Page 8: Identification
SPRAY-GUN WASHER IWK H2O Mod. H2O 1.4. IDENTIFICATION (See fig. A). Every Spray-gun washer has a CE identification plate that shows A - Manufacturer's brand. B - Manufacturer's name and address. C - CE Mark. D - Danger Group, Class, Type in compliance with the “ATEX” Directive E - Amount of washing product. -
Page 9: Sound Level
SPRAY-GUN WASHER IWK H2O Mod. H2O 1.6. SOUND LEVEL The sound level emitted by the Spray-gun washer has been measured under working conditions using a sound level meter with integrator. Measures were taken by a skilled laboratory technician in accordance with EN ISO standard 3746: 1995. Results are as follows: •... -
Page 10: General Safety And Accident-Prevention Regulations
Read the following instructions carefully. Failure to apply them can cause harm to persons, animals or damage to property. ANEST IWATA EUROPE declines all liability for damage caused by failure to comply with the following safety and accident-prevention rules and regulations. ANEST IWATA EUROPE also declines all liability for damage caused by improper use of the Spray-gun washer and/or caused by changes to the machine made without the manufacturer's authorisation. -
Page 11: Clothing
SPRAY-GUN WASHER IWK H2O Mod. H2O • AREA 1: An area in which the formation of an explosive atmosphere, consisting of a mixture of air and flammable substances in the form of gas, vapour or mist, is likely to occur in normal operation occasionally (Attachment I, EC directive 1999/92). -
Page 12: Standards For Safe Operation
SPRAY-GUN WASHER IWK H2O Mod. H2O 2.4 STANDARDS FOR SAFE OPERATION • The Spray-gun washer was designed and built to be used in an environment in which an explosive atmosphere, consisting of a mixture of air and flammable substances in the form of gas, vapour or mist, is likely to occur in normal operation occasionally: the Spray-gun washer guarantees a normal level of protection in conformity with equipment group II, category 2, in accordance with EC directive 94/9. -
Page 13: Demolition And Decomissioning
SPRAY-GUN WASHER IWK H2O Mod. H2O DANGER It is forbidden to spray and/or blow with the gun aimed at the operator or other persons: THIS COULD CAUSE SERIOUS DAMAGE TO HEALTH. Before using the Spray-gun washer, ensure that the following measures are taken: •... -
Page 14: Checks Before Installation
SPRAY-GUN WASHER IWK H2O Mod. H2O 4.1 CHECKS BEFORE EQUIPMENT INSTALLATION Before installation, check that the air supply pressure to the Spray-gun washer is at least 8 bar. If not, install a storage tank to ensu- re sufficient autonomy for the Spray-gun washer. -
Page 15: Instructions For Use
SPRAY-GUN WASHER IWK H2O Mod. H2O 5. INSTRUCTIONS FOR USE Remove the spray gun cover, empty the remaining contents in an external recipient, remove the paint cup and set the parts on the grill (pos.6G fig.1). Operate as follows: •... -
Page 16: Hydropneumatic System
SPRAY-GUN WASHER IWK H2O Mod. H2O 7. HYDROPNEUMATIC SYSTEM (see fig 3) 1. Air filter. 8. Clean water tank. 2. Bottle neck.(1.8 mm) 9. Control ball valve. 3. Air gun. 10. Nebulizer. 4. Flow regulator. 11. Control ball valve. 5. Air distributor. -
Page 17: Maintenance And Periodical Checks
SPRAY-GUN WASHER IWK H2O Mod. H2O 8. MAINTENANCE AND PERIODICAL CHECKS The following ordinary maintenance procedures must be performed. Extraordinary maintenance (repair of basic machine compo- nents) must be carried out by qualified personnel only, according to the listed instructions in this manual. -
Page 18: Cleaning The Small Venturi Pump
SPRAY-GUN WASHER IWK H2O Mod. H2O 8.1 CLEANING THE SMALL VENTURI PUMP 1. Ensure that the discharge hose A is not obstructed. 2. Unscrew the nut B. 3. Dismantle the hose C. 4. Dismantle the fitting D. 5. Clean the nozzle E with an iron thread. -
Page 19: List Of Spare Parts
SPRAY-GUN WASHER IWK H2O Mod. H2O 9. LIST OF SPARE PARTS When ordering spare parts, cite as well as the code number, the CE plate data: Model - Serial Number - Year of Manufacture. Code Description Flow regulator Lower door magnet... - Page 20 ANEST IWATA Europe S.r.l. 46, Corso Vigevano 10155, Torino Italy Direct Tel. +39 011 - 24 80 868 Fax +39 011 - 22 74 406 info@anest-iwataeu.com European Sales Branches: www.anest-iwataeu.com ANEST IWATA Italia S.r.l. ANEST IWATA Scandinavia AB. 46, Corso Vigevano 10155, Torino (Italy) Ögärdesvägen 6C, 433 30 PARTILLE...
