Summary of Contents for PLX Luxor
- Page 1 User Manual devices inc. Patents Pending © PLX Devices Inc. 2015 All Rights Reserved...
-
Page 2: Table Of Contents
About Luxor Menus Sleep Mode Charging Your Luxor Changing Your Battery Product Care and Maintenance Storage Battery Use and Safety Disposal Troubleshooting Resetting Luxor Problem Turning Your Luxor On Problem Charging Your Luxor Additional Support Technical Specifications devices inc. www.plxdevices.com... -
Page 3: Introduction
Always observe caution when Luxor is operated near maximum output. Never leave Luxor unattended when running at or near maximum output. Luxor uses high power LEDs that are capable of producing intense light. Never look directly into the light or shine into another person’s eyes. -
Page 4: Overview
Overview Accessories Included Accessories Charging Cable devices inc. www.plxdevices.com... -
Page 5: Intelligent Oled Display
Shows the beam projecting performance in meters. Shows the battery’s voltage, the amount of current in Amps being charged into or being consumed by Luxor, and the amount of power in Watts Luxor is currently using. Shows the health and temperature of your battery. Luxor keeps track of your battery’s wear and tear. -
Page 6: General Operation
Digital Focus Mode (DFS) DFS mode allows you to control the beam pattern of your Luxor easily with one hand. While in DFS mode, hold the Mode button down and press the Increase button to narrow the beam pattern or press the Decrease button to widen the beam pattern. -
Page 7: About Luxor Menus
During normal operation, the Time to Discharge will be displayed. Th is simply tells the user how much time is left before Luxor needs to be charged. If Luxor is being charged, Time to Charge will be displayed. Th is tells the user how much longer Luxor needs to be charged for it to reach full capacity. -
Page 8: Charging Your Luxor
NOTE: Luxor will still charge if it is off or locked. Changing Your Battery 1. Before changing your Luxor battery, always make sure that there is no moisture present on or around your Luxor unit. 2. Unscrew the tail cap seal and remove the tail cap. -
Page 9: Product Care And Maintenance
Product Care and Maintenance Your Luxor is a product of superior design and should be treated with care. Th e guidelines below will allow you to enjoy this product for years to come. Storage Luxor should be stored at room temperature in cool or shaded areas, ideally between 10°C (50°F) to 25°C (77°F). -
Page 10: Disposal
Disposal Proper disposal of your Luxor battery is an important aspect of product care and safety. To properly dispose the product, follow your municipal battery disposal guidelines. Visit your local electronics/hardware store for general instructions on proper disposal of mobile electronic devices with LiPo batteries. -
Page 11: Troubleshooting
2. If your screen does not turn on when you plug it in to charge, remove the tail cap and check to make sure the battery connector is completely clipped into place. 3. If you fi nd that the battery connector was connected, reset your Luxor (follow the “Reset Procedure” above). -
Page 12: Problem Charging Your Luxor
LiPo batteries. Using an inappropriate charging cable can be dangerous, and may result in product malfunction and fire. 2. Once you have confirmed that you have a working cable and power source, try charging your Luxor again. -
Page 13: Technical Specifications
Microprocessor Controlled High Efficiency Solid State PWM Temperature Monitoring, Overcharge Protection, Short Circuit and Current Over- Fail Safe draw Protection, Automatic Consistent Brightness, Ultra Low Current Standby PLX Proprietary LED Digital Focus and Intelligent Battery Monitoring and Intellectual Properties Metering devices inc. - Page 14 PLX products with any other device(s) must be done at your own risk. LIMITED WARRANTY – PLX Devices Inc. warrants this product to be free from defects for 1 year from the date of purchase. If applicable, non-serviceable items are excluded from stated warranty. Serviceable goods must be determined by PLX Devices to be defective before any warranty or replacement is issued.
