USER'S MANUAL FOR HCWB2 AND HCWP2 HUMIDIFIERS
Table Of Contents

Introduction

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Humidifier Operation

. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Instructions −− Manual Humidistat
Operating Instructions −− Universal Humidistat
Introduction
This manual includes information that will familiarize you
with your humidifier. It also details routine maintenance
required to keep the humidifier working properly.
!
WARNING
Electric shock hazard. Can cause injury
or death. Disconnect all electrical power
supplies before servicing. Shut off water
supply before disconnecting or tapping
into any water supply line.
!
CAUTION
Risk of Equipment Damage. After humidifier
installation is completed, turn water supply back
on.
IAQ −− HUMIDIFIERS
505,289M
09/2008
Supersedes 08/2007
KAZ # C.6046
1
1
. . . . . . .
2
. . . . . .
2
. . . . . . . . . .
3
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Humidifier Operation
Your new humidifier works with your central heating
system to increase indoor humidity as necessary. The
humidifier is typically wired to operate when the indoor
blower motor is on during the heating mode and the
indoor relative humidity (RH) is below the selected
comfort level. During a call for humidity, water flows into
the EquaFlot distribution tray, where it is distributed
evenly across the width of the pan. The humidifier pad is
saturated with water. Dry hot air moves through the pad
where evaporation takes place. The humidified air carries
moisture in vapor form throughout the home.
Risk of Equipment Damage. Do not use the saddle
valve to regulate water flow. The valve is designed
to be completely opened or closed.
Page 1
HCWB2 & HCWP2 SERIES
. . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
!
CAUTION
Litho U.S.A.
3
4
4
4
5
6
