Summary of Contents for ActiSafety ASH-4
- Page 1 HUD Display User Manual User Manual ASH-4 The shape and color of the product may be a little different from the pictures. The picture is for a reference only. Please read this user manual carefully before using this product. 2540101...
-
Page 2: Main Features
ActiSafety HUD provides a lot of functions used in car. It makes you experience the speed and maintain the driving pleasure and driving Safety at the same time. - Page 3 HUD Display User Manual 7. Single-stage and four-stage alarm of car speed, facilitating the driving safety, 8. Engine speed alarm, facilitating timely shift and saving fuel consumption, especially for novice 9. Automatic and manual brightness adjustment mode, NOT dazzling, HUD Overall Structure Description Preparation Before Installation And Use 1.
- Page 4 HUD Display User Manual 3. Identify the car’s 16-pin diagnostic socket(Figure 2), connecting the OBD II cable to the 16-pin diagnostic socket if it has this socket. 4. Put the non-slip pad onto the instrument pane, then put HUD on the non-slip pad. You can adjust the angle an positon.
-
Page 5: Adjustment Methods
HUD Display User Manual HUD. If they are different, you need to adjust as follows: Adjustment Methods First switch off HUD and then switch on HUD when pressing function key A at the same time, Speed area displays setting parameter values and Fuel consumption area displays the function menu.(Figure 3) Car speed fine-tuning: Fuel consumption area displays ‘0’, That is, the menu position ‘0’, Adjustment range:75-125,... -
Page 6: Function Instructions
HUD Display User Manual (1) Using the function keys A to select menu, Each time you press the function keys A ,then select a menu; (2) Using the function keys B to adjust the parameter values (3) After adjustment, restart HUD. According to the automobile manufacturers comprehensive road fuel consumption or The MIIT（... - Page 7 27. Power and data line- Connect the OBD interface to power. Detailed Installation And Use Of The GPS Navigation 1. installation for a smart phone with OVI Maps(ASH-4-GPS only supports NOKIA smart phones OVI map): 2540101...
- Page 8 \ voices" ,then Run OVI map program, enter Options - Settings - Navigation - drive navigation and choose the voice package you want to install(Figure 4). Mandarin (Chinese)- Woman Download Add: http://www.xitern.com/actisafety/mandarin_chinese_f.zip Cantonese - Woman Download Add: http://www.xitern.com/actisafety/cantonese_f.zip English - Woman Download Add: http://www.xitern.com/actisafety/english_f.zip...
-
Page 9: Packing List
HUD Display User Manual Figure 4 Packing List 2540101... -
Page 10: Main Technical Specifications
HUD Display User Manual Common Breakdown, Possible Causes And Treatment Breakdown Possible causes Treatment No car speed alarm The set value is too high, or Cancel the staging alarm , or turned off the alarm microphone turn on the alarm microphone No engine speed The set value is too high, or Reset the value, or turn on the... -
Page 11: Company Information
D. damages caused by the professional maintenance staff. E. Damage due to force majeure. Company Information: 上海芯天电子有限公司 Xitern Electronics Co. Ltd TEL： 86-21-52600150 52540101 FAX： 86-21-52600150 52540101-808 Website: http://www.actisafety.com Add: Rm525,A building, N0.165,West Tianshan Rd, Changning District, Shanghai City, PR of China http://www.actisafety.com 2540101...
