Summary of Contents for Paralinx Triton

Page 1 USER MANUAL...
Page 3: Table Of Contents
TABLE OF CONTENTS PARALINX TRITON Important Notice LCD Screen Safety Instructions Indicators Overview Specifications Package Contents Troubleshooting Transmitter Available Frequency Channels Receiver Triton Accessories Quick-Start Guide...
Page 4: Important Notice
Customers should license from Paralinx to use such products or services or obtain the latest relevant information before placing a warranty or endorsement thereof. Use of such informa-...
Page 5: Safety Instructions
Warranty. Refer to qualified service personnel. Do not install near any heat sources such as radiators, All repairs must be performed by a Certified Paralinx heat registers, stoves, or other apparatus (including am- Technician. Contact Support@paralinx.net for more infor- plifiers) that produce heat.
Page 6: Overview
OVERVIEW PARALINX TRITON OVERVIEW The Paralinx Triton System is a compact HD Video Transmission system offering realtime uncompressed wireless HD with robust long range, capable of sending full-HD video with a range of up to 450 feet (140m) while maintaining less than 1ms latency.
Page 7: Package Contents
Mounting Bracket CONTENTS antennas for Tx Please verify the following items are in the shipping box, prior to installation of the Triton transmitter or Triton HDMI wireless video 18” PTap power 1x Antenna Mounting receiver: receiver cable Tool Please contact sales@paralinx.net...
Page 8: Transmitter
TRANSMITTER PARALINX TRITON TRANSMITTER DC IN LCD SCREEN Model No. TR888T Connect to power adapter Displays the operating status of transmitter (network video status, channel, mode, battery charge) HDMI IN Connect to HD video device for signal input POWER INDICATOR...
Page 9 TRANSMITTER PARALINX TRITON...
Page 10: Receiver
RECEIVER PARALINX TRITON RECEIVER DC IN POWER INDICATOR Model No. TR888R Connect to power adapter On: power supply is normal Off: power supply is OFF or abnormal HDMI OUT Connected to HD display devices for video output. LOW BATTERY INDICATOR...
Page 11 RECEIVER PARALINX TRITON...
Page 12: Quick-Start Guide
QUICK-START GUIDE PARALINX TRITON QUICK-START TRANSMITTER Install antennas and rotate clockwise to tighten. Do not over-tighten. GUIDE Connect LP-E6 battery or external 6-17V DC power source. Connect a video source via HDMI cable Press ON/OFF button to turn on transmitter...
Page 13: Lcd Screen
LCD SCREEN PARALINX TRITON LCD SCREEN BATTERY CHARGE INDICATOR SIGNAL STRENGTH INDICATOR CURRENT CHANNEL SELECTION NETWORK STATUS ‘LINK’ means unit is linked VIDEO STATUS ‘VIDEO’ means video is transmitting B MEANS BROADCAST MODE MICROPHONE INPUT INDICATOR (WHEN EXTERNAL AUDIO IS BEING USED]...
Page 14: Indicators
INDICATORS PARALINX TRITON INDICATORS BATTERY INDICATOR Battery charge is normal FLASH Battery charge is low Unit is Powered on POWER INDICATOR FLASH Power source is insufficient TRANSMITTER Unit is OFF Battery charge is normal BATTERY INDICATOR FLASH Battery charge is low...
Page 15: Specifications
SPECIFICATIONS PARALINX TRITON SPECIFICATIONS Transmission Frequency 5.10-5.80GHz Transmitter Video Communication MIMO Modulation Mode OFDM Frequency Stability ±20PPM Both units should be stored Bandwidth 40MHz between -40~80˚C (-40~176˚F) Standard Protocol HMDI 1.3, HDCP 1.2 Both units have an operating ≤ 1ms...
Page 16 SPECIFICATIONS PARALINX TRITON SPECIFICATIONS Transmission Frequency 5.10-5.80GHz Receiver Video Communication MIMO Modulation Mode OFDM Frequency Stability ±20PPM Bandwidth 40MHz ≤-70dBm Receiving Sensitivity ≤ 1ms System Latency Antennas Built-in Antenna Standard Protocol HDMI 1.3, HDCP 1.2 Transmission Distance Up to 450ft / 140m, line of sight Power Supply 1.
Page 17: Troubleshooting
TROUBLESHOOTING PARALINX TRITON TROUBLE- “LINK” Icon is Not Displaying - Make sure transmitter and receiver are powered ON SHOOTING - Make sure both units are on the same channel - Make sure the transmitter and receiver are within range. Ideal range for linking is...
Page 18 TROUBLESHOOTING PARALINX TRITON TROUBLE- Abnormal Color/Tint on Video Signal - Unplug the HDMI cables on the transmitter & receiver and plug them back in again. SHOOTING - Power cycle the transmitter and receiver - Try different HDMI cables Digital Noise on the Image IMPORTANT NOTE: - Make sure the transmitter and receiver are within range (maximum 450 ft/140m).
Page 19: Available Frequency Channels
AVAILABLE FREQUENCY CHANNELS PARALINX TRITON SUPPORTED 1080/60p 1080/23.98p 1080/59.94i 576i FRAMERATES/ 1080/50p 720/60p 1080/50i 480i 1080/30p 720/59.94 576i RESOLUTIONS 1080/29.97p 720/50p 480i 1080/25p 480p 720/59.94i 1080/24p 1080/60i 720/50i AVAILABLE 1 - 5150mhz FREQUENCY 2 - 5190mhz CHANNELS 3 - 5210mhz...
Page 20: Triton Accessories
TRITON ACCESSORIES PARALINX TRITON OPTIONAL GO TO PARALINX.NET/STORE TO CHECK OUT ALL TRITON ACCESSORIES AND BUILD YOUR OWN CUSTOMIZED KIT ACCESSORIES CONTACT US AT SALES@PARALINX.NET SHOULD YOU REQUIRE ANY ASSISTANCE WITH YOUR PURCHASE CONTACT SUPPORT@PARALINX.NET SHOULD YOU REQUIRE ASSISTANCE WITH TROUBLESHOOTING YOUR SYSTEM...
Page 21 TABLE OF CONTENTS PARALINX TRITON...
