Falchney Medical 6112 Operating Instructions

Fahrenheit Digital Clinical Thermometer
Digital Display Window
Battery Cap
PLEASE READ CAREFULLY BEFORE USING

BODY TEMPERATURE

Normal body temperature can vary from 97
is 98.6 o F. Usually your temperature is lower in the morning than in the afternoon. Normal temperature
varies according to the location of the temperature reading. While the oral temperature follows the
guidelines previously described, a rectal temperature is generally 1.0
axillary (under the arm) temperature will be 1.0

GENERAL CARE AND USE

BEFORE USE PLEASE NOTE
1. The thermometer should be held during use. The patient should be seated or lying down.
2. TEMPERA TURES SHOULD BE TAKEN UNDER ADULT SUPERVISION.
SPECIAL PRECAUTIONS
3. Avoid exposure to temperature extremes, dust, excessive humidity and direct sunlight.
4. Do not soak the thermometer in water or other liquids. Keep parts other than the probe away
from moisture.
5. Do not attempt to sterilize with heat or by boiling.
6. Do not bend or drop the unit. It is not shock proof.
7. Do not allow the unit to come into contact with any thinners or chemical solvents.
8. Do not attempt to disassemble the unit except to replace the battery.
9. Do not bite the main body or sensor unit.

DIRECTIONS FOR CLEANING

Clean the Thermometer probe before and after use by wiping it with soap and water. Rinse with
70% Isoprophyl Alcohol, then rinse thoroughly in cold water.
CAUTION
NEVER SUBMERGE THIS THERMOMETER IN ANY LIQUID.
NEVER A TTEMPT TO STERILIZE WITH HEA T, BY BOILING OR IN A GAS OR STEAM
AUTOCLA VE.

SPECIFICATIONS

DISPLAY RESOLUTION 1/10 DEGREE FOR
MEASUREMENT RANGE 89.6
ACCURACY ±0.3
±0.2
±0.3
MEASUREMENT METHOD PEAK HOLD SYSTEM
BA TTERY ONE 1.5V DC ALKALINE MANGANESE BUTTON
SIZE LR41 TYPE OR EQUIV ALENT
BA TTERY LIFE UPTO 3 YEARS UNDER NORMAL USE
AUTOMA TIC SHUT-OFF AFTER APPROXIMA TELY 8 MINUTES
OPERA TING TEMPERA TURE 16 O
RELA TIVE HUMIDITY 15% to 95% NON CONDENSING
STORAGE TEMPERA TURE -20
RELA TIVE HUMIDITY 15% to 95% NON CONDENSING
Operating Instructions
1. Ensure that the thermometer has been turned off before taking temperature.
2. To start the unit - Press the blue colour ON/OFF button momentarily
once.
3. The following appear in quick sequence.
(a) This is the LCD display test (See Fig. 1). It appears for approximately
2 seconds and indicates all the segments of the LCD are functioning
properly.
(b) If the previous reading is between 89.6
display the last time measured temperature value for about 3 seconds
with symbol M (Fig.2.) If the last time measure temperature value is
less than 89.6 o F the unit will display Lo
seconds without symbol M and if the last meassured reading is greater
than 109.4 o F, the unit will display Hi (Fig. 4) without symbol M.
(c) The unit goes through the internal self cheching test procedure. If the
unit is good it will display 98.6
(d) When "Lo" appears with the flashing
ready to take temperature.
Faichney
On / Off Switch
o o
F to 99 F . The generally accepted "Normal" temperature
o F higher. Conversely, an
o
F lower.
O F
O F to 109.4 O F
O F (89.6 O F to < 95.0 O F )
O F (95.0 O F to < 104.0 O F )
O O O
F (>104.0 F to 109.4 F )
C to 40 O C (61 O F to 104 O F)
O O O O
C to 50 C (– 4 F to 122 F)
o o
F ~ 109.4 F, the unit will
o F (Fig. 3) for about 3
o
F (Fig. 5) for about one second.
o
F sign (Fig.6) the unit is

ORAL USE

1. Close mouth for about 5 minutes before measurement.
2. Place the thermometer tip under the tongue on a heat pocket (3) as shown in
Fig. 7.
3. Hold the thermometer in the same spot for about 40 seconds.
4. Readings will continue to increase and the
Sensor
surement (See Fig.8).
5. When peak temperature is reached, the
9) and
a) When the temperature is higher than 99.9
beep-beep" ten times to indicate a high temperature.
b) When the temperature is lower than or equal to 99.9
sound "beep" ten times.
6. After measurement, record the temperature, then turn off the unit to save the
battery life. If you forget to turn it off, the unit will power down automatically
after approximately 8 minutes.
NOTE : THE MOUTH MUST REMAIN CLOSED DURING THE MEASUREMENT TO ENSURE
ACCURATE READINGS.
Rectal Use
Rectal temperature should only be taken when oral and axillary temperatures are inconvenient. It is
recommended that axillary temperatures be taken on infants. LUBRICATE WITH LUBRICATING
JELLY AND INSERT THE PROBE NO MORE THAN 1/2 INCH INTO RECTUM. Hold thermometer
in place until you hear the beep signal and the
Axillary Use
Dry armpit before measurement. Place the tip of the probe under arm so that the tip is touching the skin.
This area is called axilla. Hold the thermometer so that it is parallel to the patient's body and fold the
arm over the chest. This ensures that the tip of the probe is well covered and not influenced by air. Hold
thermometer in place until you hear the beep signal and the

BATTERY REPLACEMENT

Replace battery with an alkaline LR41 or equivalent type whenever the low battery indicator " + - "
flashes.
DISPOSABLE PROBE COVER USE.
1. Insert the thermometer into probe cover. Take care not to push the
thermometer tip through the end of the probe cover.
2. Holding the thermometer and tab of the probe cover as shown, pull
away the covering from longer side.
3. Tilt thermometer to remove cover from shorter side.
4. Dispose off the probe cover after taking temperature.
NOTE : For rectal use, after applying probe cover lubricate thermometer
tip with a water soluble jelly.
Your new Faichney Dual Scale Digital Clinical Thermometer is guaranteed to be free from manufacturer's
defects for life under normal use.
However, if for any reason (other than abuse or normal battery replacement) your thermometer does
not function properly we will either repair or replace it free of charge for life. This warranty is valid
E only if unit returned for repair is properly packed to avoid damage in shipping. All parts are covered by
M
the warranty, except batteries and probe covers, where applicable.
Please check the battery before returning it. This is usually the source of the problem, should repair be
Fig. 1
needed, ship freight paid to :
F
M
Conforms to ASTM E 1112
Fig. 2
F
Fig. 3
F
Fig. 4
F
Fig. 5
F
Fig. 6
o
F symbol will flash during mea-
o F symbol will stop flashing (See Fig.
o F the beeper will sound "beep-
o F the beeper will
o
F sign stops flashing (about 40 seconds.)
o
F sign stops flashing (about 2 minutes)
1. Remove screw located on the back of the thermometer. Press
down on the battery cover and push in the direction show
by the arrow in the illustration.
2. Remove battery with a non-metallic probe.
3. Insert new battery. NOTE : The positive (+) side must face
outward.
4. Replace the cover.
5. Dispose off used battery properly.

LIFETIME GUARANTEE

Faichney Medical Company
17517, Fabrica Way Suite G
Cerritos CA 90703,
USA
Faichney Fahrenheit Thermometer
Fig.7
1.
2.
3.
Reorder No. 6112
2122308 Rev-02
