Page 3: Attention
TTENTION: TTENTION: Thank you very much to choose our light! EXPOLITE TourSpot 60 is powerful in functions with“CE” Standard. It has been tested through frequent practice in deferent cases, and well recognized by professional designers in the filed of stage light. It fully shows the modern times light characteristic with good performance, it can be used in all kinds of scenes with need high quality lighting.
Page 4: Structure
5、Digital screen EXPOLITE TourSpot 60 moving head is a kind of very powerful computer light and it has gained a very popular approval by the professional light designer after numerous use and strict test on its stability and has already become one of the most successful computer light;...
Page 5: Dmx 512 Channels
CHANNELS CHANNELS: : : : DMX 512 512 CHANNELS CHANNELS CHANNEL 1: SHUTTER+STROBE+RESET CHANNEL 2: DIMMER CHANNEL 3: COLOR WHEEL CHANNEL 4: ROTATING GOBO WHEEL CHANNEL 5: GOBO ROTATION CHANNEL 6: FOCUS CHANNEL 7: PRISM+PRISM ROTATING CHANNEL 8: PAN CHANNEL 9: PAN FINE CHANNEL 10: TILT CHANNEL 11: TILT FINE CHANNEL 12: PAN &...
Page 6 192-255 Rainbow effect, anticlockwise, slow to fast CHANNEL 4 ROTATING GOBO WHEEL DMX512 signal 0-255 range Function 0-15 Open 16-31 Gobo 1 32-47 Gobo 2 48-63 Gobo 3 64-79 Gobo 4 80-95 Gobo 5 96-111 Gobo 6 112-127 Gobo 7 128-191 Rainbow effect, clockwise, fast to slow 192-255...
Page 7 ° 0-255 0-270 CHANNEL 11 TILT FINE DMX512 signal 0-255 range Function 0-255 ° 0-1.0 CHANNEL 12 PAN & TILT SPEED + VECTOR MODE DMX512 signal 0-255 range Function 0-251 Fast to slow 252-255 Vector mode...
Page 10: Install The Fixture
INSTALL FIXTURE INSTALL INSTALL INSTALL THE THE FIXTURE FIXTURE FIXTURE 1. Make sure that the point of fixing is stable before positioning the light, It must bear more than 10 multiple of the light weight 2. Use two special M10 bolts to fix the fixed-screw, which is in the projector’s soleplate, ensure projector can’t fall.
Page 11: Power Supply Mains
Power Supply Mains Power Power Power Supply Supply Supply Mains Mains Mains Use the provided plug to connect the main power to the projector paying attention to the voltage and frequency marked on the panel of the projector. It is recommended that each projector be supplied separately so that they may be individually switched on and off.
Page 12: Signal Input
Signal Input Signal Signal Signal Input Input Input Connecting to the DMX512 control signal line In case of disturbance during transmission of control signal , please use high-quality connecting line, and insert one terminal into the output socket of the last equipment for signal connecting. (solder one 1/4W120 ohm resistance to 3-pin canon plug on pin 2, pin 3 Connecting to the DMX512 control signal line Please use high-quality line for connecting in case of disturbance.
Page 13: Rigging (Optional)
Rigging Rigging（O O O O ptional ptional Rigging Rigging ptional ptional） This equipment can be positioned and fixed by clamp in every direction of the stage. Locking system makes it easy to fasten to the bracket. Attention! Two clamps are needed to fix the equipment. Every clamp is locked by fastener of 1/4 kind. Fastener can only be locked clockwise.
Page 14: Alarm
� Who to check this equipment must be well qualified. � If the functional controller is used to ignite light, be cautious that the voltage will fall down immediately when many lamps are lighted. The solution to this is lighting the lamps in every five seconds one by one. �...
