Operator's Manual
18.0-Volt Lithium-Ion Worklight
241-0423
IMPORTANT :
WARNING! To reduce the risk of injury, user must read instruction manual.
Safety symbols in this manual are used to flag possible dangers. The safety
symbols and their explanations require your full understanding. The safety
warnings do not by themselves eliminate any danger, nor are they substitute
for proper accident prevention measures.
This Safety Alert Symbol indicates caution, warning, or danger. Failure to
obey a safety warning can result in serious injury to yourself or others. To reduce
the risk of injury, fire, or electric shock, always follow the safety precautions. .
CHARGE BATTERY
BEFORE FIRST USE
Advertisement
Related Manuals for MasterForce 18.0-Volt Worklight
Summary of Contents for MasterForce 18.0-Volt Worklight
- Page 1 Operator’s Manual 18.0-Volt Lithium-Ion Worklight 241-0423 CHARGE BATTERY BEFORE FIRST USE IMPORTANT : WARNING! To reduce the risk of injury, user must read instruction manual. Safety symbols in this manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not by themselves eliminate any danger, nor are they substitute for proper accident prevention measures.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols ....................Page 3 Safety Instructions..................Page 5 Description ...................... Page 10 Assembly ......................Page 11 Operation ......................Page 12 Maintenance....................Page 13 Warranty ......................Page 15 INTRODUCTION SAVE THESE INSTRUCTIONS! This cordless worklight has many features for making its use more pleasant and enjoyable. -
Page 3: Safety Symbols
SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures. - Page 4 SAVE THESE INSTRUCTIONS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. Volts Voltage Amperes Current Hertz Frequency (cycles per second) Watt...
-
Page 5: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTION INSTRUCTION PERTRAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. WARNING!When using electric appliances, basic precautions should always be followed, including the following. a) Read all the instruction before using the appliance. b) To reduce the risk of injury, close supervision is necessary when an appliance is used near children. - Page 6 When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.
- Page 7 Use battery only with charger listed. Battery pack Charger 252-8024 252-8028 252-8036 252-8032 Know your worklight. Read the operator’s manual carefully. Learn the applications and limitations, as well as the specific potential hazards related to this tool. Following this rule will reduce the risk of electric shock, fire or serious injury.
- Page 8 SAFETY RULES FOR CHARGER WARNING! Read and understand all instructions. Failure to follow all in- structions listed below may result in electric shock, fire, and/or serious per- sonal injury. Before using the battery charger, read all instructions and cautionary markings in this manual and on the battery charger, the battery, and the product using the battery to prevent misuse of the products a WARNING! Read and understand all instructions.
- Page 9 The pins on plug of extension cord are the same number, size and shape as those of the plug on charger. The cord is properly wired and in good electrical condition The size is large enough for AC ampere rating of charger as specified below: The Cord Length (Feet) 25’...
-
Page 10: Description
DESCRIPTION KNOW YOUR WORKLIGHT (Fig.1) Fig. 1 Head Adjustable Reflector focus loop Bulb Switch Handle pivot release Hand button(Three stops) WARNING! The safe use of this product requires an understanding of the information on the tool and in this operator’s manual as well as knowledge of the project you are attempting. -
Page 11: Assembly
PRODUCT SPECIFICATION Illumination source Incandescent lamp Run-time more than 2 hours Bulb power 18V DC 300mA Pivoting head 90 degrees Pivoting handle 130 degrees Battery Voltage 18 Volt DC Worklight Weight (without battery) 10OZ Charger Input 120-Volts, 60 Hz AC only ASSEMBLY WARNING! If any part is broken or missing, do not attempt to attach the bat- tery or operate the worklight until the broken or missing part is replaced. -
Page 12: Operation
OPERATION TO ATTACH BATTERY PACK (Fig. 2) Fig. 2 1. Align the raised portion on the battery pack with the grooves on the bottom of the worklight, and then attach the battery pack to the worklight as shown. 2. Make sure the latch on the battery pack snaps into place and the battery pack is secured to the worklight before beginning operation. -
Page 13: Maintenance
MAINTENANCE GENERAL MAINTENANCE The tool may be cleaned most effectively with compressed dry air. Always wear safety goggles when cleaning tools with compressed air. Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. - Page 14 WARNING! Upon removal of the battery pack for disposal or recycling, cover the battery pack’s terminals with heavy-duty adhesive tape. Do not attempt to destroy or disassemble battery pack or remove any of its components. Lithium- Ion batteries must be recycled or disposed of properly. Also, never touch both terminals with metal objects and/or body parts as short circuit may result.
-
Page 15: Warranty
WARRANTY If, during normal use, this MASTERFORCE power tool breaks or fails due to a defect in material or workmanship within three years from the date of original purchase, simply bring this tool and its sales receipt back to your...
