Summary of Contents for IBM ThinkPad 560z
- Page 1 Repairing IBM ThinkPad 560z Speakers Repairing IBM ThinkPad 560z Speakers Tools used in this guide Fingers © 2010 iFixit — CC BY-NC-SA www.iFixit.com Page 1 of 7...
- Page 2 Repairing IBM ThinkPad 560z Speakers Step 1 - installation Battery Slide the button to the right and hold. Step 2 Slide the battery out. © 2010 iFixit — CC BY-NC-SA www.iFixit.com Page 2 of 7...
- Page 3 Repairing IBM ThinkPad 560z Speakers Step 3 - disassembly Upper Case Remove the 7 mm Philip screws. Remove the 10 mm Philip screws. Remove the 14 mm Philip screw. Step 4 Open the flap on the left hand side. © 2010 iFixit — CC BY-NC-SA www.iFixit.com...
- Page 4 Repairing IBM ThinkPad 560z Speakers Step 5 Insert the iPod opening tools between the right and left sides of the latch to pry open and release the clips. Step 6 Open the flap on the right side. © 2010 iFixit — CC BY-NC-SA www.iFixit.com...
- Page 5 Repairing IBM ThinkPad 560z Speakers Step 7 Use the iPod opening tools to pry open the latch and release the clips. Step 8 Lift the keyboard slowly. The keyboard is attached to the computer via a cable which can be damaged if not careful.
- Page 6 Repairing IBM ThinkPad 560z Speakers Step 9 Use your fingers or a spudger to detach the connector. Step 10 Remove the keyboard cover. © 2010 iFixit — CC BY-NC-SA www.iFixit.com Page 6 of 7...
- Page 7 Repairing IBM ThinkPad 560z Speakers Step 11 - Speakers Slowly lift the speaker with your fingers. The speaker's wires are attached to a connector which can come off easily. Step 12 Use your fingers to unplug the wires from the connector.
