Summary of Contents for ALLO 3CX
- Page 2 ....................... ALLO Analog Card configuration with 3CX Phone System This document describes a typical deployment scenario of ALLO Analog Card with 3CX Phone System in an Office Telephony environment. The Analog Card provides the following functionalities. FXS Modules – connectivity to analog phones and fax machines, analog trunking to legacy PBX FXO–...
- Page 3 The destination of calls that are received by the channel – These values are pre-populated, but may be changed at this point based on your need. 3CX configuration file will be generated using the parameters supplied in this page.
- Page 4 6) Click on Edit gateway and Go to Inbound parameters. Make the Following Call source Identification: SIP Field: “Contact: Host Part” Variable: “Custom IP Range” Custom Value: Enter the Gateway IP Address (Analog card IP) (Eg: 192.168.0.68) ALLO Analog Card Configuration Guide for 3CX – V1.0 Page 4...
- Page 5 7) Click finish and Go to Port/Trunks Status 8) Double click on the 10005 and note down the username and password details, which need to be configured in Analog gateway as a SIP trunk. ALLO Analog Card Configuration Guide for 3CX – V1.0 Page 5...
- Page 6 If you want DID routing, you can check the DID Routing Check Box. All the calls coming inside the gateway through this 3CX trunk will go to DID routing table. 3) Click SAVE and APPLY CHANGES. You can see the registered Status in the System Status page.
- Page 7 ....................... 4) Create Outgoing Calling Rule for the gateway to reach the 3CX PBX and add it to Dial Plan. 5) Creating Incoming Calling Rules in Analog gateway. Go to Incoming calling rules and Create New incoming Calling Rule Click Update and Apply Changes. All the calls are coming from 3CX PBX to gateway will land on extension 1000.
- Page 8 ....................... Thank you ALLO Analog Card Configuration Guide for 3CX – V1.0 Page 8...
