Summary of Contents for Soundweb Contrio

Page 1 Installation Guide...
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING FOR YOUR PROTECTION READ THE FOLLOWING: READ THESE INSTRUCTIONS. KEEP THESE INSTRUCTIONS. HEED ALL WARNINGS. FOLLOW ALL INSTRUCTIONS. The symbols shown above are internationally accepted symbols that warn of potential hazards with electrical products. The lightning flash with DO NOT USE THIS APPARATUS NEAR WATER.
Page 3: Electromagnetic Compatibility
Product name: BSS Contrio Sever Operation of this unit within significant electromagnetic fields should be Note: Product name may be suffixed by the EU. avoided.
Page 4 CONSIGNES DE SÉCURITÉ IMPORTANTES AVERTISSEMENT POUR VOTRE SÉCURITÉ LIRE ATTENTIVEMENT : LIRE CES CONSIGNES. CONSERVER CES CONSIGNES. RESPECTER TOUS LES AVERTISSEMENTS. SUIVRE TOUTES LES CONSIGNES. Les symboles illustrés ci-dessus sont des symboles acceptés NE PAS UTILISER CET APPAREIL PRÈS DE L’EAU. internationalement qui avertissent des dangers potentiels relatifs à...
Page 5 à son fonctionnement. Nom du produit : BSS Contrio Sever L’utilisation de cet appareil à proximité de champs électromagnétiques Remarque : Le nom du produit peut être suivi des lettres UE.
Page 6: Table Of Contents
Table of Contents Product Registration/Warranty ��2 Important User Information ��2 Included Items ��2 Introduction ��2 Rack Installation ��3 Front/Rear Panel ��4 Cable Recommendations ��5 Specifications ��6...
Page 7: Product Registration/Warranty
The Soundweb Contrio Server allows processor-intensive, non-audio processing tasks to be offloaded from BSS Soundweb London devices on the network and managed on a single, more capable, centralized HiQnet™ device. This frees up processing power on the Soundweb London devices so they can focus on audio processing tasks.
Page 8: Rack Installation
3. Once the rails have been installed per the rack installation instructions, slide the Soundweb Contrio Server into the rack rails through the front of the rack. 4. Install the 2 additionally supplied screws and washers into the upper holes in the front of the rack (these are the holes where the screws were ommitted in step 2 above).
Page 9: Front/Rear Panel
Use this switch to turn the Soundweb Contrio Server on and off. 2. BLU link Ports (BLU link Model Only) These ports are available on the BLU link version of the Soundweb Contrio Server only and allow for audio interfacing with other BLU link enabled audio devices with up to 64 x 64 BLU link I/O channels.
Page 10: Cable Recommendations
Cable Recommendations Network Connections For Gigabit speeds, use Cat 5e or Cat 6 cables for all network connections. Cat 5 cable may be used for networks running at a speed of 10/100Mbps. BLU link Connections (BLU link Model Only) Cat 5e or Cat 6 cables should be used throughout the BLU link audio bus network.
Page 11: Specifications
Specifications Computer Model: Dell PowerEdge R220 XL Hard Drive: 100GB SSD OS Storage Size: 40GB partition Data Storage Size: 60GB partition...
Page 12 Phone: (801) 566-8800 Website: bssaudio�com Support: bssaudio�com/en-US/support Soundweb Contrio Server Installation Guide PN: 5047991-A BSS Audio is a registered trademark of Harman © 2015 Harman All rights reserved Printed in USA...
