Summary of Contents for VIPA 67S-PNJ0
- Page 1 VIPA HMI Panel PC PPC | 67S-PNJ0 | Manual HB160 | PPC | 67S-PNJ0 | GB | 14-36...
- Page 2 VIPA GmbH Ohmstr. 4 91074 Herzogenaurach Telephone: +49 9132 744-0 Fax: +49 9132 744-1864 email: info@vipa.com Internet: www.vipa.com 67S-PNJ0_000_PPC021CE,1,GB - © 2014...
-
Page 3: Table Of Contents
5.1 Basic rules for the EMC-equitable assembly of installa- tions.................. 49 5.2 EMC-equitable assembly..........51 5.3 EMC-equitable cabling............. 52 5.4 Special precautions providing high noise immunity..55 5.5 Checklist for the EMC-compliant installation of control- lers................... 57 HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 4: General
General 1.1 Copyright © VIPA GmbH All Rights Reserved This document contains proprietary information of VIPA and is not to be disclosed or used except in accordance with applicable agree- ments. This material is protected by the copyright laws. It may not be repro-... -
Page 5: About This Manual
EMail: support@vipa.de 1.2 About this manual Objective and contents This manual describes the Panel PC 67S-PNJ0-... from VIPA. It con- tains a description of the structure, project engineering and deploy- ment. This manual is part of the documentation package with order... -
Page 6: Safety Information
Supplementary information and useful tips. 1.3 Safety information Applications con- The Panel PCs are constructed and produced for: forming with specifica- VIPA CPUs 01x, 11x, 21x, 31x, 51x and S7-300/400 from Sie- tions mens communication and process control industrial applications... - Page 7 – The national rules and regulations of the respective country must be satisfied (installation, safety, EMC ...) Disposal National rules and regulations apply to the disposal of the unit! HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 8: Hardware Description
Hardware description 2.1 Safety information for users Handling of electro- VIPA modules make use of highly integrated components in MOS- static sensitive modules Technology. These components are extremely sensitive to over-vol- tages that can occur during electrostatic discharges. The following symbol is attached to modules that can be destroyed by electrostatic discharges. -
Page 9: Properties
2.2 Properties General The VIPA Panel PC is a combination of industrial PC with state of the art performance features and a touch panel with ideal display capabil- ities. The Panel PC is a compact and modular embedded PC based Ò... -
Page 10: Structure
RJ45 jack for Ethernet communication LAN 2 RJ45 jack for Ethernet communication LAN 1 3.5mm Audio Line out 10 Power switch (pushbutton) 11 Slot for CFast storage media 12 Display with touch sensitive area (touch screen) HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 11 But you can change the configuration in the BIOS setup so that the Panel PC has to be switched on by the power switch. Ä ‘Restore AC Power Loss’ on page 45 HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 12: Interfaces
RS485 interface Logical conditions as voltage difference between 2 twisted lines Serial bus connection half-duplex two-wire operation Line length: 250m at 115.2kbit/s ... 1200m at 19.2kbit/s Data transfer rate up to 115.2kbit/s HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 13 VIPA HMI Panel PC Hardware description Structure > Interfaces HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 14: Memory Management
Flashdisk at My Device. USB storage media The Panel PC has got four USB 2.0 interfaces. The connection of USB sticks and USB drives are supported by the Panel PC. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 15: Dimensions
Prior to removing the CFast card, make sure the unit's power is off and disconnected from the power supply. 2.4 Dimensions Installation dimensions For the installation of the Panel PC in control cabinets and desks the following dimensions are necessary: HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 16 – The material thickness of the installation cut-out is 3 ... 12mm. £ – The deviation from the plane for the panel cut-out is 0.5mm. – Permissible surface roughness in the area of the seal: £ 120µm (friction coefficient 120) HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 17: General Data
Air humidity EN 60068-2-30 RH1 (without condensation, rel. humidity 10… 95%) Pollution EN 61131-2 Degree of pollution 2 Mechanical Oscillation EN 60068-2-6 1g, 9Hz ... 150Hz Shock EN 60068-2-27 15g, 11ms HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 18: Technical Data
1920 x 1080 Aspect ratio 16:9 Type of display TFT color (16.7M colors) MTBF Backlights (25°C) 50000 h System properties Processor Intel Atom Dualcore 1.86 GHz Operating system Windows embedded Compact 7 HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 19 USB-B connector Number of ethernet interfaces Ethernet Ethernet 10/100/1000 MBit Ethernet connector 2 x RJ45 Integrated ethernet switch Video connectors VGA SubD HD15 Audio connections Line out, stereo jack 3.5 mm HB160 | PPC | 67S-PNJ0 | GB | 14-36...
- Page 20 Minimum 3 mm Maximum front panel thickness 12 mm Weight 9.1 kg Environmental conditions Operating temperature 0 °C to 50 °C Storage temperature -20 °C to 75 °C Certifications UL508 certification HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 21: Deployment Panel Pc
Frontplattenausschnitt [1], bis dieses mit der Dichtung [2] auf- liegt. Drehen Sie die Drehebel um 90 Grad nach außen [4]. Schrauben Sie nun die Schrauben mit dem Kreuzschlitzschrau- bendreher [5] fest. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 22: Installation Of The Cfast Card
Push the CFast card to remove the card. Reinstall the cover plate. CAUTION! Prior to removing the CFast card, make sure the unit's power is off and disconnected from the power supply. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 23: Commissioning
– Signal cables must not be let within the same cable shaft as high voltage cables. 3.3.1 VIPA Startup-Manager As soon as the Panel PC is provided by power supply, the VIPA Startup-Manager will be loaded. Start screen At the first startup of the VIPA Startup-Manager the following start screen appears. - Page 24 With [Autostart] you define which runtime and which project will be started automatically together with the panel startup. With [...] at "Runtime path" res. "Project path" all existing runtimes res. projects on the panel and the storage media will be listed. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
- Page 25 The VIPA Startup-Manager will be closed by [Exit] and the system Ò returns to the Windows screen. Back With [Back] you get back to the start screen of the VIPA Startup-Man- ager. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 26: Connection To A Plc System
Windows CE operating systems designed for innovative and small- footprint devices. Features File viewer for Word, Excel, PowerPoint and PDF ftp, Telnet and VNC server RDP (Remote Desktop Protocol) Internet Explorer Registry Editor WordPad USB keyboard driver VIPA Startup-Manager HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 27 For manual storage please use the "WriteReg" function via ‘Start è Programs è Tools’ Soft reset To reboot the operating system (soft reset) please use the "Restart- Tool" via ‘Start è Programs è Tools’. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 28: Structure
Keyboard layout If you’ve connected a keyboard you can choose the requested language layout via this button. Time This area shows the time that you can change via double click. HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 29 The software keyboard allows you to enter key entries without con- necting an external keyboard. As soon as an entry is required the software keyboard is automatically shown. Hide Input Panel hides the keyboard again. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 30: Integrated Server
A client is an application that uses the service of a server within a net- work. For example, a web browser is a client because at every call of a website it sends a request to a web server and receives an answer. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 31: Ftp Server
PC with Windows Explorer as ftp client and your Panel PC. Connect your Panel PC with the network where your PC is a member via an Ethernet cable. Switch on your Panel PC. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 32: Telnet Server
Start a Telnet client like for example "MS-DOS console" at your PC and enter the following into the address bar: telnet IP address. ð When the connection is established, the Panel PC asks for the user name and the password. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 33: Vnc Server
VNC communication is, that the VNC server is started on the Panel PC and a VNC client on the PC. You can download a VNC client as freeware from internet. HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 34 Because you can deactivate all safety attitudes with the VNC server, you should use these exclusively for start-up! For this reason the VNC server is on delivery deactivated. Due to software reasons VIPA does not support the VNC server function! Establishing a VNC con-...
-
Page 35: Access To The Network Resources
You may terminate already assigned network resources via: nections \> net use local_name /d Example: \> net use data /d deletes the network connection to the drive "archive" of "test server". HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 36: Bios Setup
If the error occurs after the display device is initialized, the screen will display the error message. Powering on the computer and immediately pressing [Del] allows you to enter Setup. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 37: Main
Security - Security settings Save and Exit - Save and exit 4.2 Main The Main menu is the first screen that you will see when you enter the BIOS setup utility. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 38: Advanced
4.3 Advanced This menu allows you to configure the system's extended functions. Here you can configure the CPU and the periphery. CAUTION! Setting incorrect field values may cause the system to malfunction. HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 39 Enabled - Permit the switching on of the execute disable function by the OS. Disabled - Prevents the switching on of the execute disable function by the OS; it will force the XD feature flag to always return to 0. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
- Page 40 ATA features which will increase storage performance. Submenu "USB Config- This section is used to configure USB devices, such as keyboard, uration" mouse and hub. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
- Page 41 This section is used to configure serial ports 0 to 1. Configuration" Super IO Chip Displays the Super I/O chip used on the board. Submenu "Serial Port 0 This section is used to configure serial port 0. Configuration" HB160 | PPC | 67S-PNJ0 | GB | 14-36...
- Page 42 Enabels or disables the terminal resistor for RS422 and RS485. Disabled - Terminal resistor not activated Enabled - (default) Terminal resistor activated H/W Monitor This section "PC Health Status" is used to configure the hardware temperature and voltages. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 43: Chipset
Setting incorrect field values may cause the system to malfunction. Host Bridge Display the memory information. Ò Ò Submenu "Intel This section is used to configure the Intel IGD graphic configuration. Configuration" HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 44 The options are ‘Tact Switch’ , ‘Manual’ and ‘Light Sensor’ . The Control Select default setting is ‘Manual’ and the Backlight option below will be con- figurable. Backlight Adjust the brightness of the backlight. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 45: Boot
Power On the system. Power On - (default) The system will automatically Power On. Beep Enables or disables ‘Beep’ . 4.5 Boot This section is used to configure the boot features. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 46: Security
4.6 Security If ONLY the Administra- If only the Administrator's password is set, then this only limits access tor's password is set to setup and is only asked for when entering setup. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 47: Save And Exit
To save the changes and exit the setup utility, select this field then press [Enter]. A dialog box will appear. Confirm by selecting [Yes]. You can also press [F4] to save and exit setup. HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 48 To bypass the boot sequence from the boot option list and boot from a particular device, select the desired device and press [Enter]. Launch EFI Shell from To launch EFI shell from a filesystem device, select this field and filesystem device press [Enter]. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 49: Installation Guidelines
The components of VIPA are developed for the deployment in indus- trial environments and meets high demands on the EMC. Neverthe- less you should project an EMC planning before installing the compo- nents and take conceivable interference causes into account. - Page 50 (e.g. walkie-talkie) wave meets a line circuit. The Sparking lines (sparking hit of the wave inducts currents plugs, collector of electric and voltages. motors, welding devices) HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 51: Emc-Equitable Assembly
A correctly done grounding sup- inactive metal parts ports an unambiguous reference potential for the control and reduces the impact of coupled interferences. HB160 | PPC | 67S-PNJ0 | GB | 14-36... -
Page 52: Emc-Equitable Cabling
>400V Group D Lines for H1 respectively TCP/IP Combination of groups Following the table you may see the conditions for the cabling of the line groups by combining the single groups: HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 53 – Install these protective elements at the location where the cables enter the building. Any lightning protection system must be based on an indi- vidual assessment of the entire plant. For questions please contact VIPA GmbH. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
- Page 54 The one-sided grounding of screens may provide advantages when: It is not possible to install an equipotential bonding conductor Analogue signals (a few mV or mA) must be transmitted Foil-type screening (static screening) is employed. HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 55: Special Precautions Providing High Noise Immunity
(e.g. relay contacts). In this case the integrated suppressors on the module are also disabled. You can connect diodes to suppress back-emc, varis- tors or RC-networks to the inductors. HB160 | PPC | 67S-PNJ0 | GB | 14-36... - Page 56 Suppression of fluores- cent lamps in cubicles 1 Fluorescent lamp 2 Screen above the lamp 3 Screened cable 4 Switch with metallic cover 5 Line filter or screened power cable HB160 | PPC | 67S-PNJ0 | GB | 14-36...
-
Page 57: Checklist For The Emc-Compliant Installation Of Controllers
Have the screens been connected by means of large-surface and low- impedance cable clamps? Cable screens grounded both-sided where possible? Inductors Have the coils of contactors controlled by means of contacts been connected to snubber networks? HB160 | PPC | 67S-PNJ0 | GB | 14-36...
