ROCKY
HOT WATER HEAT PUMP
INSTALLATION AND OPERATION
INSTRUCTIONS
Please read this user's manual carefully before operate the unit.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROCKY and is the answer not in the manual?

Questions and answers

Summary of Contents for RedWing RC ROCKY

  • Page 1 ROCKY HOT WATER HEAT PUMP INSTALLATION AND OPERATION INSTRUCTIONS Please read this user’s manual carefully before operate the unit.
  • Page 2: Table Of Contents

    CONTENTS A. IMPORTANT REMARKS AND INFORMATION --------------------------------------------------- 1-2 B. DESCRIPTION OF HOT WATER CYLINDER------------------------------------------------------- 3 C. INSTALLATION INSTRUCTION----------------------------------------------------------------------- 4-7 D. OPERATION PANEL INSTRUCTION-------------------------------------------------------------- 8-11 E. MAINTENANCE AND SERVICE------------------------------------------------------------------- 12-13 F. UNIT CIRCUIT DIAGRAM --------------------------------------------------------------------------- 14-15 G. SPECIFICATIONS AND DIMENSIONS --------------------------------------------------------- 16-18 H.
  • Page 3 Rocky Hot Water Heat Pump – Save Up to 75% on Heating Your Water! The Rocky hot water cylinder is powered by a heat pump which is integral to the unit and is located on top of the cylinder. It works up to 30% more efficiently than Solar powered hot water panels and is significantly cheaper to purchase and install.
  • Page 4: Important Remarks And Information

    A. Important remarks and Information Thank you for choosing our products. Before installation, it is strongly recommended to read the instructions first. This manual includes the information of installation, debugging, running and maintenance of the products. Every unit of product has passed strict tests to ensure safe and high efficiency in operation. The manufacturer of this product will not be held responsible if someone is injured or the unit is damaged, as a result of improper installation, debugging, and unnecessary maintenance which is not in line with this manual.
  • Page 5: A. Important Remarks And Information

    A. Important remarks and Information Examination before trial run 1. Check the water tank is filled with water, and open the water outlet tap till water flows out. 2. Check the water pressure is normal (1.5 - 7 bar). 3. Check the air inlet or outlet is well connected; and the air outlet pipe heat insulation is completed.
  • Page 6: Description Of Hot Water Cylinder

    B. Description of water cylinder Unit constructions (outside): 顶盖 Top Cover Air Inlet / Outlet Screen Panel 操作面板 Upper Cover 主机上壳 Condensate Overflow Hole Decoration Bar 流溢孔 装饰条 Electric Board 电器盒 Vent Pipe Compressor 出风管 压缩机 Ventilation Fan Evaporator 风机 蒸发器...
  • Page 7: Installation Instruction

    C. Installation instruction How it’s works The heat pump uses ambient air temperature from the building and this can be taken from a bathroom or kitchen etc. The pump takes the heat from the air, compresses it to a higher temperature and transfers this heat directly into the water.
  • Page 8 C. Installation instruction (Fig. 3) Option 1: Exhaust air to outside through the roof, ambient air from another room. Option 2: Exhaust air to outside through the wall, ambient air from another room. 9. Fig 3 shows the inlet air duct taking air from another room and the exhaust air being dumped outside either through the roof or external wall.
  • Page 9 C. Installation instruction . The working pressure of this water heater tank must be ≤7 bar. The water inlet must be connected to the safety valve with an operating pressure of 7 bar. 19. Water inlet pressure should be greater than 1 bar, if the pressure is lower than this connect the pressure pump on inlet pipe to get a higher water flow.
  • Page 10: C. Installation Instruction

    C. Installation instruction Installation Diagram: Air Outlet Air Inlet 进风 出风 风管 Vent Tube C LO C K O N / O FF TI M E R M O D E Hot Water Outlet 溢流水管 Condensate Overflow drain 热水出 ( 用水端) (Hot Water use) 热循环进水...
  • Page 11: D. Operation Panel Instruction

    D. Operation (Panel Instruction 1)
  • Page 12 2. Panel - Display: 设定水温显示 Set Temperature High Temperature 水温高温提示 Alarm 机器报警指示 Auxiliary Heater 辅电加热指示 Status 机器状态指示 HTG: Heating DEF: Defrost WARM: Keep warm Working Mode 工作模式指示 Time adjustment 调节时钟指示 Time 当前时间显示 Timer On 定时开显示 Timer Off 定时关显示 Timer Period 定时时段显示...
  • Page 13: Parameter Setting

    D. Operation panel instruction 3. Parameter Setting: Press “MODE” button for 5 seconds; enter the Parameter setting status, the main parameter code as below sheet: Type Code Parameter Name Setting Range Factory Setting Unit Remark Setting temperature 5-70 °C Difference in Temp. 1 - 30 °C Determine Heat pump stop...
  • Page 14: D. Operation Panel Instruction

    D. Operation panel instruction 4. Error Handling: ERROR CODE ERROR STATUS REASONS ERROR HANDLING 1. Check the water temp. sensor Water temp. sensor open circuit Thermal sensor alarm connection. or short circuit. 2. Change the water temp. sensor. 1. Check the condenser coil temp. Condenser coil sensor Condenser coil temp.
  • Page 15: Maintenance And Service

    E. Maintenance and service Maintenance and service 1 . For, first time installation or moving of installation, and connecting of water pipes and filling the tank with water. The machine should be allowed to rest for 1-2 hours before starting trial run. 2.
  • Page 16: E. Maintenance And Service

    E. Maintenance and service Heat Pump main unit disassembly To check and maintain the top main parts of the unit, to disassembly the cover of the unit follow the steps below (Fig.5, 6) CLO CK O N/ O FF TI M ER M O DE Fig.5 Fig.6...
  • Page 17: Unit Circuit Diagram

    F. Unit circuit diagram The following is a unit circuit diagram (for user’s reference); the unit practical connection should be as the circuit / wiring diagram on the machine. 1). Heat pump without auxiliary electric heater:...
  • Page 18: F. Unit Circuit Diagram

    F. Unit circuit diagram 2). Heat pump WITH auxiliary electric heater: W ATER TEM P. SEN SO R O PER ATI O N PAN EL C O I L TEM P. SEN SO R 时钟 开/ 关 AM BI EN T TEM P. SEN SO R 定时...
  • Page 19: Specifications And Dimensions

    G. Specification and Dimensions Hot water cylinder (Air Ducts on Top) Diameter 568mm Model Rocky 80L-E-3.6 Rated Input Power 0.80 KW Rated Heating 3.6 KW Capacity Heating ampere 4.0A Power Supply 220V~50Hz Outlet water 55 degrees temperature Water output 77L/H...
  • Page 20 G. Specification and Dimensions Hot water cylinder (Air Ducts on Top) Diameter 650mm Model Rocky 150L-E-3.6 Rocky 190L-E-3.6 Rated Input Power 0.88KW 0.88KW Rated Heating 3.6KW 3.6KW Capacity Heating ampere 4.0A 4.0A Power Supply 220V-50Hz 220V-50Hz Outlet water 55 degrees...
  • Page 21: G. Specifications And Dimensions

    G. Specification and Dimensions Hot water cylinder (Air Ducts on Top) Diameter 650mm Model Rocky 260L-E-4.2 Rocky 300L-E-4.2-2C Rated Input Power 1.2 KW 1.2 KW Rated Heating 4.2 KW 4.2 KW Capacity 5.5A 5.5A Heating ampere Power Supply 220V-50Hz Outlet water...
  • Page 22 G. Specification and Dimensions Hot Water Cylinder (Air Ducts on Top) Model 80L-E-3.6 150L-E-3.6 190L-E-3.6 260L-E-4.2 300L-E-4.2-2C Rated input power .88KW 1.2KW Rated Heat capacity 3.6KW 4.2KW Outlet Water 55 degrees Temperature Capacity of Water 150L 190L 260L 300L Tank (Litres) Heating Cycle Time (Hours) 1.9H...
  • Page 23: Warranty

    H. Warranty The rocky heat pump comes with an 18 month warranty. The warranty begins from the day of purchase. During the warranty period, if the heat pump has quality problems, please provide the barcode number of the unit. (There is a barcode in each unit).
  • Page 24 Dublin Road Thomastown Co. Kilkenny Tel: 056 775 4004 Email: Sales@redwing.ie www.redwing.ie...
