Summary of Contents for HIMAC HBS50
- Page 1 Saw Bench Owners Manual Giving you Productivity HBS50 HBS120B • • HBS100H HBS160—PTO • • HBS100B HBS180 • • HBS120H • 1800 888 114...
-
Page 2: Operating Instructions
HIMAC BENCH SAW OPERATING INSTRUCTIONS SECTION 1 Before attempting to operate saw, please check the following: • All guards are in place and secure. • Machine is on level ground. • Blade is in good condition. • Blade securing nut is tight. - Page 3 SECTION 3 While operating saw, observe the following procedures: • Always wear safety glasses. • Always wear ear protection. • Always wear protective clothing. • Always cut straight logs. • Always push bench with one hand on handle and the other on log. •...
- Page 4 PTO DRIVE MACHINES Please note: PTO shaft must be disconnected before raising machine or damage could result to the shaft and/or gearbox. Once sawbench is coupled to three point linkage you may need to adjust shaft length. This must be measured and cut with machine lowered to working position.
- Page 6 HIMAC INDUSTRIES HBS 50, 100, 140, 160 & KOB Firewood Docking Saws RISK ASSESSMENT HAZARD DANGERS YOU LEVELOF POSSIBILITY CONSEQUENCES IF MEASURES IN PLACE TO CONTROL OR AVOID DANGER INJURY OCCURS HAZARD BE EXPOSED TO PERSONEL INJURY OPERATIING Exposed and...
- Page 7 FATIGUE MEDIUM MEDIUM Possibility of Appropriate PPE to be worn (Gloves) from severe overwork bruising, Do not continue to operate if fatigues. laceration, squashing or Operator training and associated safety issues have been well addressed by administrative control in the operator’s amputation of manual.
- Page 8 Burns from contact VERY VERY The individual relief valves on all machines are set at the factory and the with oil system is tested for leaks at peak pressure. Rotating Parts NONE NONE It is the nature of this machine that the oil will not heat up enough to burn if contact is made with it.
-
Page 9: Warranty
The exclusive remedy to the purchaser in the event that the product does not meet its express warranty shall be the repair or the replacement of the product at the option of HIMAC without charge to the purchaser when the product is returned to HIMAC INDUSTRIES or designated location advised by HIMAC.
