Summary of Contents for JLC Solutions SR61
- Page 1 JLC Solutions Installation Manual SR61 Vehicle Mounted Holder / Charger Designed specifically for the Intermec SR61B...
- Page 2 Installation Detail Electrical Power Connection Attach the SR61 Charger power cable to the lift truck’s DC power source. The SR61 Charger is polarity independent so it does not matter which wire is positive or negative. The optimum place to connect to the lift truck power is between the battery and the ignition key.
- Page 3 Connector Connector Power Bus Negative Lift Truck Battery Power Bus Positive In-Line Fuse (supplied) JLC Solutions SR61 Charger Part # 761 Be sure that you have the correct voltage for your application To lift truck ignition switch JLC 761 v215.1...
