Summary of Contents for Voxx XG3000
-
Page 1: Instruction Manual
XTREME GAMING SURROUND SOUND SYSTEM Instruction Manual I N P U T I N P U T AV I N P U T I N P U T Please read the instruction manual carefully before using your unit. -
Page 2: Table Of Contents
GENERAL Table of Contents Introduction Thank you for purchasing this Home Theater System..........1 PRECAUTIONS Please read this instruction manual for best results. IMPORTANT SAFETY INSTRUCTIONS ....2 Manufactured under license from Dolby FUNCTION CONTROL ......... 3 Laboratories.‘Dolby’,‘Dolby Digital’,‘Pro Logic’ and the double-D symbol are trademarks of Front Panel .............. -
Page 3: Precautions
PRECAUTIONS The lightning flash with an arrowhead symbol, within the equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to cause an electric shock. The exclamation point within the equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. -
Page 5: Function Control
FUNCTION CONTROL Front Panel 3 4 5 6 1. STANDBY/ON button PRO LOGIC indicator Turns the unit ON, or puts the unit into STANDBY mode. Lights when Dolby Pro Logic is active . 2. AV1/2/3 buttons DIGITAL indicator Press AV1 or AV2 to enter “auto-detected/auto-switching” Lights when Dolby Digital is active. -
Page 6: Remote Control
FUNCTION CONTROL (Continued) Remote Control 1. STANDBY/ON button 6. VOL +/- buttons Turns the unit ON, or puts the unit into Adjust the volume and the level of STANDBY mode. corresponding function. 2. SURROUND button 7. TEST button Change the output channels or the output Test and adjust the volume of each speaker. -
Page 7: Connections
CONNECTIONS Power Connection Notes: • Before you plug in the unit, make sure that the rated voltage of your unit matches your local voltage. • Keep your hands dry when you are connecting the power cord to the wall outlet to avoid electric shock. •... -
Page 8: Positioning The Speakers & Subwoofer
CONNECTIONS (Continued) Positioning the Speakers & Subwoofer FRONT SPEAKERS CENTER Place on both sides of the TV, Place on the top of or equal distances apart. below the TV. BUILT-IN SUBWOOFER REAR SPEAKERS Place right beside or slightly behind your listening position, and a little higher than your ears. -
Page 9: Video & Audio Input/Output Setting
CONNECTIONS (Continued) Video & Audio Input/Output Setting AV1 (SAT/VCR) Connect the audio and video output jacks of the AV equipment (VCR, Satellite receiver, etc.) to the audio and video input jacks on the unit with an audio/video cable. If the AV equipment has a bitstream/PCM coaxial audio out jack, connect the equipment to the unit by using a coaxial cable. -
Page 10: Video & Audio Input/Output Setting
CONNECTIONS (Continued) Video & Audio Input/Output Setting (Continued) AV3 / DIGITAL (OPTICAL) IN AV3: Connect the audio and video output jacks of the AV equipment (Video game console, etc.) to the audio and video input jacks on the unit. DIGITAL (OPTICAL) IN: Connect the Digital (Optical) out jack of the AV equipment (DAT deck/MD deck, etc.) to the Digital (Optical) in jack on the unit. -
Page 11: Sound Adjustment
SOUND ADJUSTMENT Adjusting the Balance Adjust the speaker balance with the remote control. 1. Press the TEST button on the remote control once, and you will hear PINK NOISE from the left front speaker. The L light on the front panel will illuminate. 2. -
Page 12: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE The following checks will assist in the correction of most problems which you may encounter with your system. PROBLEMS SOLUTIONS No power. • Check that the AC power cord is connected. No sound. • Rotate the VOLUME + button to increase volume. •...
