Summary of Contents for Multi Channel Systems TC01
- Page 1 Temperature Controller TC01/02 Manual...
- Page 2 © 2015 Multi Channel Systems MCS GmbH. All rights reserved. Printed: 16. 07. 2013 Multi Channel Systems MCS GmbH Aspenhaustraße 21...
-
Page 3: Table Of Contents
General User Interface 3.3.3 TC01/02 Menus 3.3.4 Setting a Temperature 3.3.5 Channel Configuration 3.3.6 Hardware Diagnosis Controlling the TC01 / TC02 via TCX-Control Software 13 Appendix Control via Front Panel 4.1.1 Version: Standard 4.1.2 Version: Customer II 4.1.3 Version: Customer III... -
Page 5: Introduction
This manual comprises all important information about the first installation and the proper usage of the temperature controller TC01 and TC02. It is assumed that you have a basic understanding of technical terms, but no special skills are required to read this manual. -
Page 7: Important Information And Instructions
Important Information and Instructions 2.1 Operator's Obligations The operator is obliged to allow only persons to work on the device, who are familiar with the safety at work and accident prevention regulations and have been instructed how to use the device; ... - Page 8 Temperature Controller TC01/02 Manual High Voltage Electrical cords must be properly laid and installed. The length and quality of the cords must be in accordance with local provisions. Only qualified technicians may work on the electrical system. It is essential that the accident prevention regulations and those of the employers' liability associations are observed.
-
Page 9: Guarantee And Liability
Important Information and Instructions 2.3 Guarantee and Liability The General conditions of sale and delivery of Multi Channel System MCS GmbH always apply. The operator will receive these no later than on conclusion of the contract. Guarantee and liability claims in the event of injury or material damage are excluded when they are the result of one of the following. -
Page 11: Installation And Operation
TC01/ TC02 does not interfere with the experimental setup. The TC01/02 is a general purpose temperature controller for use of almost any kind of heating element. The PI coefficients are preset in the channel configuration defaults for MCS products. -
Page 12: Setting Up And Connecting The Tc01/02
3.2 Setting Up and Connecting the TC01/02 Provide a power supply in the immediate vicinity of the installation site. 1. Place the TC01/02 on a dry and stable surface, where the air can circulate freely and the device is not exposed to direct sunlight. -
Page 13: Operating The Tc01/02
6 W in standby mode is used by the power supply unit. In the main menu on the display, select On / Off. The TC01/02 starts to control the temperature on the selected channels immediately. If the TC01/02 is connected properly, the actual temperature and the setpoint temperature are displayed in the Temperature Control view. -
Page 14: Tc01/02 Menus
MCS Defaults. For safety reasons, the Edit menu is locked each time the TC01/02 is switched off. You need to unlock it first by selecting Unlock Edit in the Setup menu. -
Page 15: Hardware Diagnosis
Cable resistance low side of sensor, see also chapter "D-Sub9 Pin Assignment". Sensor resistance plus cable resistance Resistance X Resistance S Sensor resistance Board Temp Board temperature (The TC01/02 will switch off the channel outputs and go into stand-by mode when the board temperature reaches 90 °C.) - Page 16 Temperature Controller TC01/02 Manual Diagnosis 2: Controller settings This diagnose screen view is used for reviewing and checking the user settings. Setpoint Temp Setpoint temperature P Gain Proportional gain I Gain Integrator gain Max Power Maximum output power Diagnosis 3: Controller output This diagnose screen view is used for checking the operation of the internal controller.
-
Page 17: Controlling The Tc01 / Tc02 Via Tcx-Control Software
PC with standard USB 2.0 cable and use the software TCX-Control. With this software, you can control all functions of one or more TC01/02 and it is also possible to read out the actual temperature values on your computer and save the data as a ".txt" file. Then you can import this file into your custom evaluation software, for example, to plot a temperature curve. - Page 18 Temperature Controller TC01/02 Manual Two windows show the temperature on the two channels. The scaling of the y-axis is adjusted automatically. The x-axis shows the absolute time taken from the system clock. The scale of the time axis can be altered in the "Scale" drop down menu. Find in each channel window a "Power"...
- Page 19 24 hours will be saved. The frequency is fixed to 1 second. The extension of the file is "*.txt". Extended Information It is possible to display the extended information with all parameters from the TC01/02. Click "Show extended information" button in the main menu.
- Page 20 Temperature Controller TC01/02 Manual These values can be saved to an ASCII file by pressing "Export diagnostics". The default settings for P and I coefficients and maximum power for the different devices can be modified under Device configuration. Use of the OP Table The OP Table consist of a heating plate for keeping the animal warm, and a rectal thermometer for measuring the body temperature of the animal.
- Page 21 Installation and Operation Firmware Upgrade If you like to use a device from Multi Channel Systems MCS GmbH, which is not available in the settings of your temperature controller ( for example, the TCW ), you probably need to the software and the firmware, and you have to reset in the TCX.
-
Page 23: Appendix
Appendix 4.1 Control via Front Panel 4.1.1 Version: Standard... -
Page 24: Version: Customer
Temperature Controller TC01/02 Manual 4.1.2 Version: Customer II... -
Page 25: Version: Customer Iii
Index 4.1.3 Version: Customer III... -
Page 26: D-Sub9 Pin Assignment
7 and 8 to the heating element. The other three pins are not needed for operation. TC01 / TC02 : D-Sub Pin Assignment Note: A four-wire circuit is required for use with Pt100 sensors. Each of the two pairs assigned to pins 1/2 and 3/4 have to be connected together in close proximity to the PT100 sensor for proper operation. -
Page 27: Parameter Ranges
Index 4.3 Parameter Ranges The setpoint temperature and the PI coefficients can be modified in the following ranges. The maximum power of the TCX is 30 W. If you connect a device with a maximum power less than 30 W, please decrease the maximum power to protect the device against destruction. Parameter Range 0.0 to 105.0... -
Page 28: Technical Specifications
Temperature Controller TC01/02 Manual 4.5 Technical Specifications Operating temperature 10 °C to 40 °C Storage temperature 0 °C to 50 °C Dimensions (W x D x H) 170 mm x 224 mm x 66 mm Weight 1.5 kg Supply voltage and current... -
Page 29: Contact Information
Local retailer Please see the list of official MCS distributors (sales info) on the web site User forum The Multi Channel Systems User Forum provides the opportunity for you to exchange your experience or thoughts with other users worldwide. News Letter If you have subscribed to the newsletter, you will be automatically informed about new software releases, upcoming events, and other news on the product line. -
Page 30: Index
Temperature Controller TC01/02 Manual Index... - Page 31 Index...
- Page 32 Extended information ...... 12 High voltage........3 Firmware upgrade ......12 Requirements ........3 General user interface...... 12 Select device........12 Setpoint temerature......12 MEA1060-INV Technical Specification MEA1060-UP Temperature Controller proportional-integrator technology ..7 MEA2100 TC01 ............ 7 TC02 ............ 7 OP Table Operator's Obligations...
