Page 1: Operating Instructions
OPERATING INSTRUCTIONS Before operating the units, please read this manual thoroughly and retain it for future reference. SUPER CLASS-D SERIES POWER AMPLIFIER S1000.1D / S2000.2D / S1000.4D / S2000.5D... -
Page 2: Planning Your System
UPER LASS- ERIES MPLIFIER INTRODUCTION Amplifiers provide high-performance sound reinforcement for your mobile audio equipment. Its versatility enables compatibility with optional Equalizers, Frequency Dividing Network Crossovers, and other audio processors in a customized system. The Multi-Mode bridging capabilities allow flexibility in hosting several different speaker configurations. -
Page 3: Mounting Your Amplifier
UPER LASS- ERIES MPLIFIER c) Are your components matched? The peak power rating of your speakers must be equal or greater than the Amplifier’s. They also must be 2-8 Ohms impedance (This information is normally printed on the speaker magnet). d) Consider both the length of your leads, and routing when determining the mounting location. - Page 4 UPER LASS- ERIES MPLIFIER S1000.1D : 80A S2000.2D : 80A x 2 S1000.4D : 80A S2000.5D : 80A x 2 (3) Remote Turn-On Input : To Power Antenna output of car Stereo This Amplifier is turned “ON” remotely when the vehicle’s stereo is turned “ON”...
- Page 5 NOTE : DO NOT USE IN CONJUNCTION WITH LOW LEVEL INPUT JACKS. CAUTION : NOTE THAT ONLY POSITIVE (+) WIRES ARE USED. DO NOT CONNECT SPEAKER NEGATIVES (-) FROM CAR STEREO. INSULATE ANY BARE WIRES. : S1000.1D / S2000.2D ODEL LINE INPUT HIGH INPUT...
-
Page 6: Power Indicator Led
UPER LASS- ERIES MPLIFIER F) CONNECTING LOW LEVEL INPUTS NOTE : DO NOT USE CONJUNCTION WITH HIGH LEVEL INPUT WIRES. Wire routing is CRITICAL for NOISE FREE PERFORMANCE. Observe the following: 1. Always use high quality RCA type shielded cables. 2. - Page 7 UPER LASS- ERIES MPLIFIER : S1000.1D ODEL LINE INPUT HIGH INPUT BASS EQ LEVEL LOW PASS 18dB 40Hz 400Hz REMOTE Sensitivity Control : S2000.2D ODEL LINE INPUT HIGH INPUT LEVEL LOW PASS BP FULL HI HI PASS X-OVER 0.2 50Hz...
-
Page 8: Connecting The Speakers
UPER LASS- ERIES MPLIFIER CONNECTING THE SPEAKERS : S1000.1D ODEL Basic application BASS EQ : 0 to +18dB These sub bass amplifiers can be used any of the bi-amplification systems described in this manual, Level control checklist : replacing the 2 channel amplifiers as per the illustrations. -
Page 9: Full Range Stereo
UPER LASS- ERIES MPLIFIER : S2000.2D ODEL FULL RANGE STEREO This is the most basic application for the 2 channel amplifiers. 1. Interconnect cable checklist : Connect the LINE INPUTS to the Radio/CD with good quality RCA cables. 2. Crossover Switch : The X-OVER switch must be in the FULL position. 3. - Page 10 UPER LASS- ERIES MPLIFIER : S2000.2D ODEL FULL RANGE MONO This application illustrates the basic mono bridging N/A for full range operation. TIP : If you are using the mono sub bass output of an method for all 2 channel amplifiers. active crossover, there is nothing wrong with Interconnect cable checklist : switching in the low pass filter in these...
- Page 11 UPER LASS- ERIES MPLIFIER : S1000.4D ODEL 4 CHANNEL FULL RANGE SYSTEM Level control checklist : Here we show how to use the 4 channel amplifiers as - Refer to the section Setting up systems after straightforward discrete 4 channel full range units. installation for best performance.
- Page 12 UPER LASS- ERIES MPLIFIER : S1000.4D ODEL 2 way active, or bi-amplified system with mono bass This application shows how easily a 2 way active system can be implemented using a 4 channel amplifier. Crossover frequency control checklist : Channels 1 and 2 will e used for highs, and channels 3 Channels 1/2 : and 4 for mono bass.
- Page 13 UPER LASS- ERIES MPLIFIER : S2000.5D ODEL 3 way active, with mono bass The S2000.5D channel amplifier contains all the functions Note that the HIGH and LOW PASS controls of necessary to set up a completely self contained 3 way channels 3 &...
- Page 14 UPER LASS- ERIES MPLIFIER : S2000.5D ODEL Front/rear high pass, with constant sub bass Please note that these frequency points are Another obvious application for the S2000.5D is to use 4 suggestions only. Refer to the loudspeaker channels for front/rear satellites, and the mono channel manufacturer specifications and the section Setting for constant non faded sub bass.
-
Page 15: Troubleshooting Guide
UPER LASS- ERIES MPLIFIER TROUBLE SHOOTING GUIDE SYMPTOMS CHECK POINTS CURE Check fuses in amplifier. NO SOUND Is the power LED illuminated? Be sure Turn-on lead is connected No power to power wire Repair power wire or connections AMP NOT No power to remote wire with SWITCHING Check connections to radio... - Page 16 UPER LASS- ERIES MPLIFIER WARNINGS Investigate the layout of your automobile thoroughly before drilling or cutting any holes. Take care when tou work near the gas tanks, lines, or hydraulic lines, and electrical wiring. Don’t use power amplifier unmounted. Attach this system securely to the automobile to prevent damage, particulary in the event of an accident.
-
Page 17: Specifications
UPER LASS- ERIES MPLIFIER SPECIFICATIONS S1000.1D 3200W MAXIMUM POWER OUTPUT @ 2 Ohm 800W TOTAL CAHNNEL OUTPUT POWER @2 Ohm(RMS) 560W TOTAL CAHNNEL OUTPUT POWER @4 Ohm(RMS) 280W TOTAL CAHNNEL OUTPUT POWER @8 Ohm(RMS) <0.1% >95dB S/N Ratio(A-Weight) 20Hz-400Hz FREQUENCY RESPONSE : 1.0 dB... - Page 18 UPER LASS- ERIES MPLIFIER S1000.4D MAXIMUM POWER OUTPUT @ 4 Ohm 720W x 4 TOTAL CAHNNEL OUTPUT POWER @2 Ohm(RMS) CH3 CH4: 300W x 2 TOTAL CAHNNEL OUTPUT POWER @4 Ohm(RMS) 180W x 4 or CH3 CH4: 600W(Mono) TOTAL CAHNNEL OUTPUT POWER @8 Ohm(RMS) 100W x 4 or 360W x 2(Mono) <0.1% >95dB...
- Page 19 UPER LASS- ERIES MPLIFIER Owner’s Manual / Installation Guide 19...
- Page 20 UPER LASS- ERIES MPLIFIER OPERATING INSTRUCTIONS www.sndei.com 20 Owner’s Manual / Installation Guide...
